Please read the manual before using the product. The manual and
carton contain important information, please keep them properly
for later references. If failure to following the instruction in the
manual, it might be dangerous for your child.
In order to improve the product and quality, we may change the
parts of structure, appearance, packing method, assembly method
and function of the product without any notice. When there is any
difference between the manual and the product, please subject to
the actual product. We are sorry for any inconvenience.
The assembly manual of
battery operated car
Model:SX2028
Products should be assembled by an adult. Protective equipment
should be worn. Not to be used in traffic. Not suitable for children
under 3 years. Choking hazard- small parts. In unassembled
state, contains potentially hazardous small parts. Please keep
out of the reach of small children. Pay attention to the potential
hazards of using the toy in areas other than private grounds.
Executive standard：
EN71-1
EN71-2
EN71-3
EN62115

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SX2028 and is the answer not in the manual?

Questions and answers

Related Manuals for HOLLICY SX2028

Summary of Contents for HOLLICY SX2028

  • Page 1 EN71-2 battery operated car EN71-3 EN62115 Model:SX2028 Products should be assembled by an adult. Protective equipment should be worn. Not to be used in traffic. Not suitable for children under 3 years. Choking hazard- small parts. In unassembled state, contains potentially hazardous small parts. Please keep out of the reach of small children.

  • Page 2: Parts List

    PARTS LIST PICTURE QTY PICTURE QTY PARTS NAME PARTS NAME Windshield Car body Seat Steering wheel Spoiler 2PCS Mirror 4PCS 4PCS Wheel Wheel cover 2PCS Motor (optional) (optional) (optional) Remote control Charger Manual Disclaimer: The pictures in this instruction are for assembly reference only. Please refer to the actual product.

  • Page 3: Product Specifications

    PRODUCT SPECIFICATIONS 12V7AH / 12V10AH / 12V12AH / 12V14AH Battery 12V7AH*2 12V9AH*2 Main material Suitable age 37-95 Months weight limit 60kg for the car 1350X807X515mm Product size Speed 3-8 KM/H (10-15KM/H for drift functon) Runtime 1-2 hours after charging for 8-12 hours, based on ride on conditions Input AC 110 -220V Output DC 12V500 -1000mA Charger Input AC 110 -220V Output DC 24V500 -1000mA...

  • Page 4: Assembly Instruction

    Assembly instruction Car assembling should be done by the adults. Take care of small parts. To avoid choking hazard, keep children away while assembling. Children under 36 months are prohibited to use. Please count all the parts carefully before assembling and dispose the plastic bag properly.
  • Page 5 Attention: Please make sure the rear axle is in the middle, and the axle holding out of both sides is in the same distance. 3.Rear wheel assembly A. Check whether the rear axle is in the middle of the car body, and make sure the axle length that extend out on both sides are same.
  • Page 6 4.Windshield assembly Align the windshield with the corresponding openings on the car body, insert them into place. 5.Steering wheel assembly Match two connectors of the wires from steering wheel and steering column, align the steering wheel with steering column, press two pins on steering wheel and insert them into the holes on steering column.
  • Page 7 6.Seat assembly Align the seat diagonally with the corresponding position on the car body, insert the hook into the corresponding position, fix with self tapping screws at the back of the seat. 7.Spoiler assembly Insert the spolier into the correspond- ing position at the rear o the car and push them into...
  • Page 8 9. Drift switch operation Remove the screw (a) on the rear trunk, pull inward the two hooks (b) together, remove the trunk cover. There is a drift switch beside the battery. FUSE This car has a auto-reset fuse, if the car stops suddenly during driving, it is mainly caused by instantaneous current exceeds ,which makes the fuse to trip.

  • Page 9: Security Warning

    SECURITY WARNING 1.The installation and charging of vehicle should be under adult supervi- sion at all times. 2.This product is limited to the children from 37 to 95 months, 60 kg weight limit. 3.This product is ideal for driving on a hard flat surface. 4.It is strictly prohibited in the streets or the road, pot holes, and slopes.
  • Page 10 WARINING: When changing the gears, the accelerator should be released and the car has completely come to stop. Electronic steering wheel is an optional function, it can be self position. Prohibit to change the gear while the car is still moving, because that can damage the wire and other transmission parts.
  • Page 11 MP3 Optional MP3/ Mode/ Electric capacity display Wireless name B: Wireless streaming MP3 balance waveform T: Small memory U: Big memory Power capacity : Flash Wireless steraming R: Radio M: Mode Music Volume + Volume – Story Previous Next Play/ Pause Microphone input Big memory Small memory / Audio input...

  • Page 12: Remote Control Instruction

    Remote control instruction Speed indicator Stop Forward Right Speed Reverse Left Code 2.4G Remoter Control Instructions For the first time using, please match the remote control with the car, this product has a memory function, battery replacement does not need to match the code once again. ①.Long press "code"...
  • Page 13 WARNING: 1. When operating the car, the distance between the car which kid sit in and the remote control which operated by adults should not be more than 10 meters. 2. The remote is only for adults to use, keep far away from child. 3.

  • Page 14: Maintenance And Service

    Charging port Removable battery WARNING: 1 The toy is to be assembled by an adult. In unassembled state, it contains potentially hazardous sharp points & small parts, so please keep out of baby's reach. 2 CHOCING HAZARD – Small parts. 3 Not for children under 3 yrs.

  • Page 15: Troubleshooting

    4. The car should be kept away from hot items, such as stoves or heaters, or the plastic parts will melt. When charging, the car should be kept away from inflammable materials to prevent it from catching fire. 5. Charge in time after use. Charging should be done by adults. If the product is going to be unused for a long time, it must be fully charged.
  • Page 16 PINGHU SHUANGXI BABY CARRIER MANUFACTURE CO.,LTD. PINGHU BABY CARRIER INDUSTRY CITY, ZHEJIANG, CHINA...
