INSTALLATION AND OPERATION MANUAL

Please read these instructions completely before

installing or operating the E-one fireplace.

NetZero Kalfire E-one Electric Fireplace

Models: AA-11-05386 – E-one 130B

AA-11-05551 – E-one 160B

AA-11-05552 – E-one 190B

Please read these instructions carefully before installation.

Failure to follow them could result in serious injury.

This appliance must be installed by a qualified installer.

The installation and wiring connections must be done in accordance with the

national and local codes having jurisdiction.

For use with 120V 60Hz electrical supply only.

The heater outlet becomes hot while in operation.

Never cover the heater outlet or any other part of the appliance.

IMPORTANT

This appliance must be grounded.

SAVE THESE INSTRUCTIONS

85-03-01328

Table of Contents

Need help?

Do you have a question about the Kalfire E-one and is the answer not in the manual?

Questions and answers

Summary of Contents for NetZero Kalfire E-one

Page 1 For use with 120V 60Hz electrical supply only. This appliance must be grounded. The heater outlet becomes hot while in operation. Never cover the heater outlet or any other part of the appliance. SAVE THESE INSTRUCTIONS 85-03-01328 NetZero Fireplace ©2024 All rights reserved. 0425...
Page 3: Table Of Contents
6.20 Adding Fireplace to the App 6.22 Fireplace Connected to App 6.24 Connecting other Users 8 MAINTENANCE 8.1 Cleaning The Fireplace 8.2 Cleaning The Glass Reflector WARRANTY Table of contents TECHNICAL DATA 1 INTRODUCTION 11.1 Specifications 1.1 Receiving Inspection 11.2 Serial Number Label 1.2 Certification 11.3 130B Wire Diagram 2 GENERAL SAFETY REGULATIONS...
Page 4: Introduction
(2) This device must accept any interference received, including interference that may cause undesired operation. NetZero Fire stands for innovation and quality. This is why we work continuously on the further development of our Note: This product has been tested and found to comply products.
Page 5: Additional General Safety Regulations For Atmos Heating
The relative item that can be damaged from heat rising from humidity must be <85%. the heater above the heater. NetZero Fire will not Do not place the fireplace directly under a wall •...
Page 6: Assembly Of The Fireplace
Note: Before installing the feet place the fireplace on a MOUNT WLDMNT protected surface such as carboard or a rug. HA-143-00136 BAY SIDE PANEL 85-03-01325 NetZero E-one 130B-190B Manual 40-03-00109 GLOVE, DISPOSABLE FOOD SERVICE, PK 100, 9737T28 65-06-01574 E ONE REMOTE...
Page 7: Rear Screen Assembly
E160B/E190B Rear Screen Assembly Install the rear screen bracket to the top LED rear screen bracket. Use 2 (#8-18 X ½”) screws for E130B and 4 (#8-18 X ½”) screws for E160B and E190B as shown below. E130B Remove the protective film from the rear screen mask. This is the plexiglass sheet with three tabs at the top.
Page 8 For the 130B, connect the rear screen by connecting the Install the rear screen assembly in the back of the fireplace. The bracket fits into slots at the back of the fireplace and wires below to the outside left. For the 160B and 190B, will rotate forward into the spring clips at the top.
Page 9: Top Screen Assembly
INSTALLING THE FIREPLACE Top Screen Assembly Remove the protective film from the top screen before installing it into the fireplace. The pegs at the front of the Light / Illumination screen rest on brackets as shown below. When installing be The E-one functions on the basis of hologram technology.
Page 10: Setting Up The Fireplace
Setting up the fireplace Place the fireplace in its final position before continuing to set up the fireplace. Level the fireplace using the adjustable legs. Once you have levelled the fireplace, it is strongly recommended that you attach it to the wall using the wall brackets for added stability and safety.
Page 11: Framing Dimensions
Framing Dimensions Recommended framing is shown below. Minimum space requirement to fit the fireplace are: 130B: Width- 52” Height- 23” Depth- 19” 160B: Width- 64” Height- 23” Depth- 19” 190B: Width- 76” Height- 23” Depth- 19” The ceiling of the enclosure must be at least 6” above the top of the heater or 11 ½”...
Page 12 After the fireplace has been leveled and fastened to the framing a front board needs to be installed under the bottom guide as shown in the image below. Once the fireplace is in position and level, secure it by screwing the flanges into the framing.
Page 13: Wall Dimensions
150°F. Materials used in this area must be rated Mantel and TV Height for these temperatures. NetZero Fire is not responsible for If mantel made of combustible material, it must be installed damage to walls because of the use of improper materials at a 1:1 ratio from the top of the guide of the fireplace to or installation.
Page 14: Tv Installation
The recess in the wall must comply with the framing dimensions and be at least 6” above the fireplace heater. Attention: NetZero Fireplace is not responsible for any damage to electronics or sensitive materials installed above the fireplace.
Page 15: 4.1 E130B Log Set Installation
4.1 E130B Log Set Installation The logs are made of fragile material. Therefore, proceed with extreme caution when installing the logs. NOTE: Log set instructions are shown with the flat bottom floor installed in the fireplace. When installing the log set it is important that the logs are placed exactly as shown in these instructions. If logs are not placed correctly the projected flame will not line up with the logs.
Page 16 Place the next three logs on the ember bed as shown. Next, place log “K” on the right side of the ember bed. Log “O” is placed so that it is resting on log “P”. The placement of logs “P” and “O”...
Page 17: 4.2 160B And 190B Log Set Installation
4.2 160B and 190B Log Set Installation The logs are made of fragile material. Therefore, proceed with extreme caution when installing the logs. NOTE: Log set instructions are shown with the flat bottom floor installed in the fireplace. When installing the log set it is important that the logs are placed exactly as shown in these instructions. If logs are not placed correctly the projected flame will not line up with the logs.
Page 18 Place the next three logs “K”, “D”, and “Q” on the ember bed grooves as shown. Next place log “G” on top of log “D”. Once “G” is place, add “S”, “T”, “J”, and “F” in their groove as shown below. Next place logs “R”, “V”, and “U”...
Page 19 To finish the installation, sprinkle the vermiculite and lava stones over the ember bed. First place the lava stones between and around the logs. Then sprinkle vermiculite over the entire ember bed as well as on the floor plate around the ember bed. If too much vermiculite is placed on the ember bed the light of the ember bed will not be visible.
Page 20: Placing Glass Reflector
Placing Post Covers Placing Glass Reflector After the glass reflector is installed place the post covers at the front corners of the glass. The post covers have cutouts to fit between the extrusion on the glass and the L-brackets. The glass reflector is susceptible to stains and fingerprints. For this reason, always use the supplied gloves for installation.
Page 21: Placing Front Window
The side window glass slides into the glass holders on the Center the front glass between the side glass pieces so that floor of the fireplace and trim side of the glass in a channel the edges line up with the side glass. Then tighten the at the top of the fireplace.
Page 22: One Operation
E-ONE OPERATION Remote Control Pairing With the E-one you can create your own fire experience When the fireplace is used for the first through the various functions and/or options. time, the remote control will connect to the fireplace automatically. If the Main On/Off Switch following symbol is projected on the Power to the fireplace can be switched On/Off using the...
Page 23 0 to 5. Moods The flame image and heat output (when opting for the Atmos Heating option) of the Kalfire E-one can be tailored to your individual needs, preferences, and circumstances. Kalfire has pre-set and recorded 3 moods under the respective Mood buttons.
Page 24: Kalfire Connected App
KALFIRE CONNECTED APP Creating Account Open Kalfire Connected app and select skip/next on the The Kalfire Connected app offers more and extended images below. possibilities compared to the remote control. Installing the Kalfire Connected App Before installing the Kalfire Connected app, Please Check: •...
Page 25 Select One of the options and enter your information as prompted on the screen. Once you have entered your information in you will need to verify your email to create your account.
Page 26: Connecting App To Fireplace
Connecting App to Fireplace Wifi Connection After creating your account, it’s time to connect your Once on the Wi-Fi connection screen, make sure that the fireplace to the app. Wi-Fi connection is the same as the Wi-Fi that your phone is connected to.
Page 27: Adding New Fireplace To Connected App
Adding New Fireplace to Connected App Select “E-one” for the fireplace type. To add a new fireplace to the app. You need to select “connect a new fireplace”.
Page 28: Activate Bluetooth
6.10 Activate Bluetooth 6.11 Bluetooth Mode Make sure Bluetooth is enabled. Once Bluetooth is enabled Put the fireplace remote into Bluetooth mode by pressing and you have the green check marks. Select “Continue” the flame appearance button for 7-10 seconds as shown in the image below.
Page 29: Selecting Bluetooth Device
6.13 Selecting Bluetooth Device Once your remote is in Bluetooth mode your fireplace will appear on the Bluetooth devices. Select the device, then select the device again to confirm your fireplace.
Page 30: Connecting The Fireplace To The Network
6.15 Connecting the Fireplace to the network After connecting your fireplace via Bluetooth, you will need to connect the fireplace to your network. On the screen you should see your network on the connected app as shown below. Enter your network password and select “connect fireplace to a network.”...
Page 31: Pairing Fireplace To Connected App
6.17 Pairing Fireplace to Connected App Once in Bluetooth mode the screen will switch to the image below. Hold the flame appearance for 3 seconds, then press next on the Connected app. A green check mark will appear once you have successfully connected your fireplace to the app.
Page 32: Failure To Connect
6.19 Failure to connect 6.20 Adding Fireplace to the App If the red check mark appears on the connect app. Select Confirm the name or change the name of your fireplace and “Go Back” and repeat step 3.8 until the green check mark confirm to add your fireplace to the app as shown below.
Page 33: Fireplace Connected To App
6.22 Fireplace Connected to App Once the app is connected to the app the screen should appear as shown below. Now you will be able to control the fireplace with your app.
Page 34: Connecting Other Users
6.24 Connecting other Users To connect other users to the app repeat steps 3.1-3.2. Once you confirmed you’re on the same network. Select the fireplace name that applies to your fireplace. Repeat steps 3.8 until you have successfully connected the fireplace to the app and have the green check mark.
Page 35: Maintenance
MAINTENANCE CAUTION: Before cleaning, make sure the power has been turned off at the circuit breaker panel and that the heating element of the heater is cool. Cleaning The Fireplace Use a microfiber cloth or other soft cloth to clean the black powder-coated parts of the fireplace.
Page 36: Warranty
NetZero Fire dealer if pre-approved by NetZero Fire, is jurisdiction. responsible for all infield diagnosis and service work related to all warranty claims. NetZero Fire is not responsible for 11.2 Serial Number Label results or costs of workmanship of unauthorized NetZero...
Page 37: 130B Wire Diagram
11.3 130B Wire Diagram...
Page 38: 160B And 190B Wire Diagram
11.4 160B and 190B Wire Diagram...
Page 39: Dimension Drawing
11.5 Dimension Drawing For framing the fireplace follow the framing dimensions and instructions given in this manual. Warning: The ceiling of the enclosure must be at least 6” above the top of the heater or 11 ½” above the top of the fireplace.
Page 40 1155 Sherman Rd, Hiawatha, IA 52233 (800)553-5422 NetZero is a manufacturer and distributor of these products, which are designed by Kalfire B.V. THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF AND SUPPLIED MANUALS. IMPLIED WARRANTIES OF MERCHANTABILITY, IMPLIED WARRANTIES OF FITNESS, IMPLIED...
