INSTALLATION AND OPERATION MANUAL
Please read these instructions completely before
installing or operating the E-one fireplace.
NetZero Kalfire E-one Electric Fireplace
Models: AA-11-05386 – E-one 130B
IMPORTANT
Please read these instructions carefully before installation.
Failure to follow them could result in serious injury.
This appliance must be installed by a qualified installer.
The installation and wiring connections must be done in accordance with the
national and local codes having jurisdiction.
For use with 120V 60Hz electrical supply only.
This appliance must be grounded.
The heater outlet becomes hot while in operation.
Never cover the heater outlet or any other part of the appliance.
SAVE THESE INSTRUCTIONS
85-03-01293
NetZero Fireplace ©2023 All rights reserved. 0623
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for NetZero Kalfire E-one 130B
Summary of Contents for NetZero Kalfire E-one 130B
- Page 1 For use with 120V 60Hz electrical supply only. This appliance must be grounded. The heater outlet becomes hot while in operation. Never cover the heater outlet or any other part of the appliance. SAVE THESE INSTRUCTIONS 85-03-01293 NetZero Fireplace ©2023 All rights reserved. 0623...
-
Page 2: Table Of Contents
Table of contents 1 INTRODUCTION 1.1 Receiving Inspection 1.2 Certification 2 GENERAL SAFETY REGULATIONS 2.1 Additional General Safety Regulations for Atmos Heating 2.2 Disposal 2.3 California Proposition 65 Warning 3 ASSEMBLY OF THE FIREPLACE 3.1 Required Tools 3.2 Included Hardware 3.3 Removal of Covers 3.4 Adjustable Feet 3.5 Rear Screen Assembly... -
Page 3: Introduction
This product generates, uses, and NetZero Fire stands for innovation and quality. This is why can radiate radio frequency energy and, if not installed and we work continuously on the further development of our used in accordance with the instructions, may cause harmful products. -
Page 4: Additional General Safety Regulations For Atmos Heating
Do not install electronics, artwork, or any other humidity must be <85%. item that can be damaged from heat rising from the heater above the heater. NetZero Fire will not • Do not place the fireplace directly under a wall be responsible for any damage to these items. -
Page 5: Assembly Of The Fireplace
ASSEMBLY OF THE FIREPLACE Rear Screen Assembly Install the rear screen bracket to the top LED rear screen Required Tools bracket. Use 2 (M5 x 10) screws. - 8mm Nut Driver or Socket - 5mm Allen Wrench - 3mm Allen Wrench - 12mm Wrench - 17mm Wrench - Level... - Page 6 Install the rear screen assembly in the back of the fireplace. Connect the rear screen: 1. HDMI The bracket fits into slots at the back of the fireplace and will rotate forward into the spring clips at the top. 2. Power WARNING: When rotating the screen forward move slowly.
-
Page 7: Top Screen Assembly
Top Screen Assembly Replace the rear and top panels with 8 (M5 x 10) screws. The fireplace in now ready to be installed into your wall. Remove the protective film from the top screen before installing it into the fireplace. The pegs at the front of the screen rest on brackets as shown below. -
Page 8: Installing The Fireplace
INSTALLING THE FIREPLACE Ventilation Openings The chase the fireplace is installed in must have sufficient ventilation for the fireplace to function correctly. A Light / Illumination minimum of 15 ½ in (100 cm ) of free area is required. The E-one functions on the basis of hologram technology. One way to accomplish the required ventilation is to cut a This involves the use of a glass reflector that is placed at an hole in the chase and install a 10”... -
Page 9: Wall Dimensions
Temperatures above the heat outlet on the fireplace can reach temperatures up to 175°F. Materials used in this area must be rated for these temperatures. NetZero Fire is not responsible for damage to walls because of the use of improper materials or installation. -
Page 10: Setting Up The Fireplace
SETTING UP THE FIREPLACE Installing Side Cover Plates Place the fireplace in its final position before continuing to Install the two side cover plates into the fireplace. The covers attach by magnets. set up the fireplace. Level the fireplace using the adjustable legs. Once you have levelled the fireplace, it is strongly recommended that you attach it to the wall using the wall brackets for added stability and safety. -
Page 11: Log Set Installation
Log Set Installation The logs are made of fragile material. Therefore, proceed with extreme caution when installing the logs. NOTE: Log set instructions are shown with the flat bottom floor installed in the fireplace. When installing the log set it is important that the logs are places exactly as shown in these instructions. If logs are not placed correctly the projected flame will not line up with the logs. - Page 12 Place the next three logs on the ember bed as shown. Next place log “K” on the right side of the ember bed. Log “O” is placed so that it is resting on log “P”. The placement of logs “P” and “O”...
-
Page 13: Placing Glass Reflector
Placing Glass Reflector Placing Post Covers After the glass reflector is installed place the post covers at the front corners of the glass. The post covers have cutouts to fit between the extrusion on the glass and the L-brackets. The glass reflector is susceptible to stains and fingerprints. For this reason, always use the supplied gloves for installation. -
Page 14: Placing Front Window
Placing Front Window 5.10 Front Window Adjustment Loosen the screws to slide the retaining clips up. Do not If the edges of the front window and side windows are not remove the screws. straight the tilt of the front window can be adjusted to line up with the side window. -
Page 15: One Operation
E-ONE OPERATION Remote Control Pairing With the E-one you can create your own fire experience When the fireplace is used for the first through the various functions and/or options. time, the remote control will connect to the fireplace automatically. If the Main On/Off Switch following symbol is projected on the Power to the fireplace can be switched On/Off using the... -
Page 16: E-One Remote And Symbols
Anti-Reflect Function E-One Remote and Symbols When the fireplace is on briefly press the power button to turn the fireplace off with the anti-reflect mode activated. In this standby mode, the fireplace will be attractively lit. This provides a nice view of the logs, even when the fire is Atmos Heating (ON/OFF switch) not burning. -
Page 17: Maintenance
MAINTENANCE Lean the top of the glass down and carefully remove it from the fireplace. The glass reflector can now be accessed and CAUTION: Before cleaning, make sure the power has been cleaned. turned off at the circuit breaker panel and that the heating element of the heater is cool. -
Page 18: Warranty
NetZero Fire dealer if pre-approved by NetZero Fire, is fireplace. responsible for all infield diagnosis and service work related to all warranty claims. NetZero Fire is not responsible for results or costs of workmanship of unauthorized NetZero Fire dealers or agents in the negligence of their service work. -
Page 19: Wire Diagram
Wire Diagram Dimension Drawing For framing the fireplace follow the framing dimensions and instructions given in this manual. Warning: The ceiling of the enclosure must be at least 6” above the top of the heater or 11 ½” above the top of the fireplace. - Page 20 1155 Sherman Rd, Hiawatha, IA 52233 (800)553-5422 NetZero is a distributor of these products, which are designed and manufactured by Kalfire B.V. THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF AND SUPPLIED MANUALS. IMPLIED WARRANTIES OF MERCHANTABILITY, IMPLIED WARRANTIES OF FITNESS, IMPLIED...
