INSTALLATION AND OPERATION MANUAL
Please read these instructions completely before
installing or operating the E-one fireplace.
NetZero E-one Electric Fireplace
Models: AA-11-05384 – NZ E-one 100
Description of the remote control: Page 13
IMPORTANT
Please read these instructions carefully before installation.
Failure to follow them could result in serious injury.
This appliance must be installed by a qualified installer.
The installation and wiring connections must be done in accordance with the
national and local codes having jurisdiction.
For use with 120V 60Hz electrical supply only.
This appliance must be grounded.
The heater outlet becomes hot while in operation.
Never cover the heater outlet or any other part of the appliance.
SAVE THESE INSTRUCTIONS
85-03-01271
NetZero Fireplace ©2022 All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E-one 100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for NetZero E-one 100

  • Page 1 INSTALLATION AND OPERATION MANUAL Please read these instructions completely before installing or operating the E-one fireplace. NetZero E-one Electric Fireplace Models: AA-11-05384 – NZ E-one 100 Description of the remote control: Page 13 IMPORTANT Please read these instructions carefully before installation.
  • Page 2: Table Of Contents

    Table of contents 1 Introduction 1.1 Receiving inspection 1.2 Certification 2 General safety regulations 2.1 Additional general safety regulations for Atmos Heating 2.2 California proposition 65 warning 3 Warranty 4 Assembly of the fireplace 4.1 Removal of covers 4.2 Rear screen assembly 4.3 Top screen assembly 4.4 Installing the fireplace 4.5 Placing design bottom plates...
  • Page 3: Introduction

    Introduction Changes or modification not expressly approved by the party responsible for compliance could void the user’s NetZero Fire stands for innovation and quality. This is why authority to operate the equipment. NetZero Fire works continuously on the further development of its products. We reserve the right to make...
  • Page 4: Additional General Safety Regulations For Atmos Heating

    three to seven years old must not clean the fireplace or perform user maintenance. • If the power lead becomes damaged, it must be replaced by the supplier or another qualified service provider to avoid danger. Additional general safety regulations for Atmos Heating •...
  • Page 5: Warranty

    Warranty We stand behind the quality of our products and therefore the warranty period on our electric fireplace is five years or up to 10,000 burning hours. For the Atmos Heating function of the fireplace we offer a two-year warranty. Assembly of the fireplace Do not use tie wraps to re-fasten cables during installation.
  • Page 6: Top Screen Assembly

    Top screen assembly Installing the fireplace Place the fireplace in its final position before continuing to fill from the front. Once you have levelled the fireplace, it is strongly recommended that you attach it to the wall using the wall brackets for added stability and safety.
  • Page 7: Placing Design Bottom Plates

    Placing design bottom plates Placing lower sidewalls Please note: If a flat bottom plate was chosen, this step can be skipped. The flat base plate is pre-installed during production. The design bottom plates are made of vulnerable material. Therefore, proceed with extreme caution when installing the bottom plates.
  • Page 8: Log Set Installation

    Log set installation...
  • Page 10: Placing Glass Reflector

    4.10 Placing front window Placing glass reflector The glass reflector is susceptible to stains and fingerprints. For this reason, always use the supplied gloves for installation. To clean the glass reflector, follow the cleaning instructions provided in chapter 7. Placing upper side walls When placing the front window, make sure the front window is parallel to the frame of the fireplace.
  • Page 11: Connecting Fireplace To Power

    4.11 Connecting fireplace to power Installing the fireplace This fireplace must be hardwired to a 120V, 60Hz, 15Amp electric supply. Install on a dedicated 15Amp (or higher) breaker. Light / illumination This appliance must be grounded. The E-one functions on the basis of hologram technology. Wiring procedures and connections shall be in accordance This involves the use of a glass reflector that is placed at an with the national and local codes having jurisdiction.
  • Page 12: Fireplace Finishing In Combination With Atmos Heating

    Fireplace finishing in combination with Atmos Heating Maintain a minimum clearance of 1/16 in. (2 mm) between the surround and the fireplace for heat transfer and expansion. Too little space will result in temperatures above 176 °F (80 °C) and unwanted material stresses.
  • Page 13: One Operation, Design Your Own Experience

    E-one operation, design your own Power Button This button has three functions: On, Anti-Reflect, Off. experience Switching the fireplace On With the E-one you can create your own fire experience Briefly press the power button. It takes about 30 seconds through the various functions and/or options.
  • Page 14: Main On/Off Switch

    Main on/off switch Power to the fireplace can be switched off using the on/off switch (0/I) on the front. The button is located at the top right, behind the metal flap (see figure). Lift the metal flap a little towards you. If the unit is completely disconnected from power, the unit will be reset to the factory settings.
  • Page 15: Maintenance

    Maintenance CAUTION: Before cleaning, make sure the power has been turned off at the circuit breaker panel and that the heating element of the heater is cool. Cleaning the fireplace Use a microfiber cloth or other soft cloth to clean the black powder-coated parts of the stove.
  • Page 16: Technical Data

    Technical data Specifications Model: NetZero E-one 100 Input: 120V – 60Hz – 15Amp Power: 1350 Watt Heater output: 4,350 Btu/hr Energy consumption per operating mode standby mode (W) standby mode, incl. anti-reflect function (W) full operating mode, excl. Atmos Heating (W) full operating mode, incl.
  • Page 17: Wire Diagram

    Wire diagram Dimension drawing...
  • Page 18 NETZEROFIRE.COM NetZero is a distributor of these products, which are designed and manufactured by Kalfire B.V. THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF AND SUPPLIED MANUALS. IMPLIED WARRANTIES OF MERCHANTABILITY, IMPLIED WARRANTIES OF FITNESS, IMPLIED...
