IBASE Technology IB839 User Manual

Intel atom processors x7000re series, 3.5" disk-size sbc
Hide thumbs

Advertisement

Quick Links

Download this manual
User Manual
IB839
3.5" Single Board Computer
Intel® Atom® Processors x7000RE Series
The information contained in this document has been carefully researched and is, to the best of our knowledge,
accurate. However, we assume no liability for any product failures or damages, immediate or consequential,
resulting from the use of the information provided herein. Our products are not intended for use in systems in
which failures of product could result in personal injury. All trademarks mentioned herein are property of their
respective owners. All specifications are subject to change without notice.

Advertisement

loading
Need help?

Need help?

Do you have a question about the IB839 and is the answer not in the manual?

Questions and answers

Related Manuals for IBASE Technology IB839

Summary of Contents for IBASE Technology IB839

  • Page 1 User Manual IB839 3.5" Single Board Computer Intel® Atom® Processors x7000RE Series The information contained in this document has been carefully researched and is, to the best of our knowledge, accurate. However, we assume no liability for any product failures or damages, immediate or consequential, resulting from the use of the information provided herein.
  • Page 2 IB839 Intel® Atom® x7000RE Intel® N Series Processors 3.5" Disk-Size SBC User’s Manual Version 1.0 (January 2025)
  • Page 3 No part of this publication may be reproduced, copied, stored in a retrieval system, translated into any language or transmitted in any form or by any means, electronic, mechanical, photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc. (hereinafter referred to as “IBASE”). Disclaimer IBASE reserves the right to make changes and improvements to the products described in this document without prior notice.
  • Page 4 • Cadmium: 100 ppm • Mercury: 1,000 ppm • Lead: 1,000 ppm • Bis(2-ethylhexyl) phthalate (DEHP): 1,000 ppm • Butyl benzyl phthalate (BBP): 1,000 ppm • Dibutyl phthalate (DBP): 1,000 ppm • Diisobutyl phthalate (DIBP): 1,000 ppm IB839 User’s Manual...

  • Page 5: Important Safety Information

    There is danger of explosion if the internal lithium-ion battery is replaced by an incorrect type. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions or recycle them at a local recycling facility or battery collection point. IB839 User’s Manual...

  • Page 6: Warranty Policy

    Software in use (such as OS and application software, including the version numbers) If repair service is required, please visit the IBASE’s website to read the warranty and RMA policy, before logging in to the eRMA System. IB839 User’s Manual...

  • Page 7: Table Of Contents

    2.5.9 M.2 B-Key 3052 Connector (J3) ..........26 2.5.10 DC Power Input Connector (J4) ..........26 2.5.11 USB 2.0 Connector (J5) ............27 2.5.12 SPI Flash Tool Connector (J6) ..........27 2.5.13 Audio Connector (J7) ............. 28 IB839 User’s Manual...
  • Page 8 Save & Exit Settings ................65 Appendix ..................67 I/O Port Address Map ................68 Interrupt Request Lines (IRQ) .............. 70 Watchdog Timer Configuration ............71 Onboard Connector Reference Types ..........75 USB Power Control Mapping ............... 75 IB839 User’s Manual...

  • Page 10: Chapter 1 General Information

    Chapter 1 General Information The information provided in this chapter includes: • Features • Packing List • Optional Accessories • Specifications • Block Diagram • Board Pictures • Board Dimensions...

  • Page 11: Introduction

    SATA III. Three M.2 sockets (M-Key, E-Key and B-Key) provide expansion flexibility, while +12 to +24V DC input and -40°C to 85°C operating temperature ensure durability in harsh conditions. Security and control are enhanced with dTPM, watchdog timer, and Digital I/O, making the IB839 ideal for demanding industrial applications. Features ●...

  • Page 12: Packing List

    General Information Packing List Your IB839 package should include the items listed below. If any of the items below is missing, contact the distributor or dealer from whom you purchased the product. • IB839 SBC Optional Accessories IBASE provides the following optional accessories: •...

  • Page 13: Specifications

    1x RS232/422/485 (jumperless selection) + 3x RS232 USB 2.0 4x USB 2.0 (pin header) USB 3.X 2x Type-A Serial ATA 1x SATA III Digital IO 4-In & 4-Out Infineon SLB9672 series Power +12V ~ +24V DC-in H/W Monitor IB839 User’s Manual...
  • Page 14 0°C ~ +60°C (+32°F ~+140°F) for Processor N Operating Temperature -40°C~+80°C (-40°F ~+176°F) for Atom x7000RE- processor Storage -40°C~85°C (-40°F ~+185°F) Temperature Relative Humidity 10% ~ 90 % (non-condensing) All specifications are subject to change without prior notice. IB839 User’s Manual...

  • Page 15: Block Diagram

    Block Diagram IB839 User’s Manual...

  • Page 16: Board Pictures

    General Information Board Pictures Top View Bottom View ＊The photos are for reference only. Some minor components may differ. IB839 User’s Manual...
  • Page 17 I/O View Oblique View IB839 User’s Manual...

  • Page 18: Dimensions

    General Information Dimensions IB839 User’s Manual...
  • Page 19 This page has been intentionally left blank. IB839 User’s Manual...

  • Page 20: Chapter 2 Hardware Configuration

    Chapter 2 Hardware Configuration This section provides information on jumper settings and connectors on the IB839in order to set up a workable system. On top of that, you will also need to install crucial pieces such as the CPU and the memory before using the product. The topics covered are: •...

  • Page 21: Essential Installations

    Essential Installations 2.1.1 Installing the Memory The IB839 supports one DDR5 memory socket. To install the modules, locate the memory slot on the board and perform the following steps: Align the key of the memory module with that on the memory slot and insert the module slantwise.

  • Page 22: Setting The Jumpers

    Open When two pins of a jumper are encased in a jumper cap, this jumper is closed, i.e. turned On. When a jumper cap is removed from two jumper pins, this jumper is open, i.e. turned Off. IB839 User’s Manual...

  • Page 23: Jumper & Connector Locations

    Jumper & Connector Locations IB839 User’s Manual...

  • Page 24: Jumpers Quick Reference

    Panel Power Selection LVDS Panel Brightness Selection LVDS Panel Power Selection AT / ATX Selection Clear CMOS Data Clear ME Register 2.4.1 Sierra Module Interface Selection (JP1) Function Pin closed Setting PCIE (default) Note: This is via J3. IB839 User’s Manual...

  • Page 25: Edp Panel Power Selection (Jp2)

    Panel Power Selection (JP2) Function Pin closed Setting 3.3V (default) Note: This is for setting Pin1~Pin5 voltage of CN2. 2.4.3 LVDS Panel Brightness Selection (JP3) Function Pin closed Setting 3.3V (default) Note: This is for setting Pin3 voltage of J20. IB839 User’s Manual...

  • Page 26: Lvds Panel Power Selection (Jp4)

    LVDS Panel Power Selection (JP4) Function Pin closed Setting 3.3V (default) Note: This is for setting Pin19~Pin20 voltage of J10, J16. 2.4.5 AT / ATX Selection (JP5) Function Pin closed Setting Note: AT: Auto power on; ATX: Manual power on IB839 User’s Manual...

  • Page 27: Clear Cmos Data (Sw1)

    2.4.6 Clear CMOS Data (SW1) Function Setting Normal (default) P1-OFF Clear CMOS P1-ON 2.4.7 Clear ME Register (SW1) Function Setting Normal (default) P2-OFF Clear ME Register P2-ON IB839 User’s Manual...

  • Page 28: Connectors Quick Reference

    LVDS Connectors J10, J16 SMBUS Connector M.2 E-Key 2230 Connector M.2 M-Key 2280 Connector J18, J17, COM2, COM3, COM4 RS-232 Ports RTC Battery Connector LVDS Backlight Connector 80 Port Debug Tool Connector Digital I/O Connector Front Panel Connector IB839 User’s Manual...

  • Page 29: Sata Connectors (Cn1)

    2.5.1 SATA Connectors (CN1) Assignment Assignment Ground Ground Ground 2.5.2 eDP Connector (CN2) Remarks: KEL_SSL00-40S Note: Use JP1 to set Pin1~ Pin5 voltage; Total current: 1A Pin27, Pin36 Total current: 1A Pin28, Pin35 Total current: 1A Pin31 Total current: 0.5A IB839 User’s Manual...
  • Page 30 AUXP eDP Vcc AUXN Ground Ground +3.3V Ground EDP BKLT (+12V) Ground Hot Plug detect Ground Ground TXN3 TXP3 Back Light Control Ground Back Light Enable TXN2 EDP BKLT (+12V) TXP2 +3.3V Ground Ground TXN1 TXP1 Ground IB839 User’s Manual...

  • Page 31: Dp Connectors (Cn3, Cn4)

    2.5.3 DP Connectors (CN3, CN4) Assignment Assignment LAN0_P LAN3_N LAN0_N CONFIG LAN1_P AUXP LAN1_N LAN2_P AUXN Hot Plug LAN2_N LAN3_P +3.3V/0.5A IB839 User’s Manual...

  • Page 32: Lan Connectors (Cn5, Cn6)

    Hardware Configuration 2.5.4 LAN Connectors (CN5, CN6) 2.5.5 USB 3.2 Connector (CN7) IB839 User’s Manual...

  • Page 33: Com1 Rs-232/422/485 Serial Port (Cn8)

    DCD, Data carrier detect Ground DTR, Data terminal ready Ground CTS, Clear to send TX, Transmit RTS, Request to send RX, Receive RI, Ring Indicator Assignment RS-232 RS-422 RS-485 (default) Ground Ground Ground Ground Ground Ground Data+ Data- IB839 User’s Manual...

  • Page 34: Nano Sim Card Slot (J1)

    Hardware Configuration 2.5.7 Nano SIM Card Slot (J1) 2.5.8 DDR5 SO-DIMM Connector (J2) IB839 User’s Manual...

  • Page 35: B-Key 3052 Connector (J3)

    2.5.9 M.2 B-Key 3052 Connector (J3) *With sierra LTE card, USB/PCIE I/F is configurable by JP5, JP6. 2.5.10 DC Power Input Connector (J4) Assignment +9V ~ +36V Ground IB839 User’s Manual...

  • Page 36: Usb 2.0 Connector (J5)

    Hardware Configuration 2.5.11 USB 2.0 Connector (J5) Remarks: HK_DF11-8S-PA66H Assignment Assignment +5V/0.5A Ground Data- Data+ Data+ Data- Ground +5V/0.5A 2.5.12 SPI Flash Tool Connector (J6) Remarks: Factory use only. IB839 User’s Manual...

  • Page 37: Audio Connector (J7)

    2.5.13 Audio Connector (J7) Remarks: HK_DF11-12S-PA66H Assignment Assignment Lineout_L Lineout_R JD_FRONT Ground LINEIN_L Linein_R JD_LINEIN Ground MIC_L MIC-R JD_MIC1 Ground 2.5.1 SATA HDD Power Connector (J8) Assignment VCC5 Ground IB839 User’s Manual...

  • Page 38: Lvds Connectors (J10, J16)

    2.5.2 LVDS Connectors (J10, J16) ** J10:Channel-A, J16:Channel-B Remarks: HIROSE_DF20G-20DP-1V(56) Note: Use JP3 to set Pin19~Pin20 voltage.Total current: 1A Assignment Assignment TX0P TX0N Ground Ground TX1P TX1N Ground Ground TX2P TX2N Ground Ground CLKP CLKN Ground Ground TX3P TX3N Power Power IB839 User’s Manual...

  • Page 39: Smbus Connector (J11)

    2.5.3 SMBUS Connector (J11) Assignment Assignment PLT_RST# SMB_DATA GPIO SMB_CLK- Ground 2.5.4 M.2 E-Key 2230 Connector (J13) *Supports CNVI Card IB839 User’s Manual...

  • Page 40: M-Key 2280 Connector (J14)

    2.5.2 COM2, COM3, COM4 RS-232 Ports (J18, J17, J15) Remarks: HK_DF11-10S-PA66H Assignment Assignment DCD, Data carrier detect RXD, Receive data TXD, Transmit data DTR, Data terminal ready Ground DSR, Data set ready RTS, Request to send CTS, Clear to send RI, Ring indicator Not Used IB839 User’s Manual...

  • Page 41: Rtc Battery Connector (J19)

    2.5.3 RTC Battery Connector (J19) Note: Coin battery with cable. Assignment Ground 2.5.4 LVDS Backlight Connector (J20) Remarks: E-CALL_0110-161-040 Note: Use JP2 to set Pin3 voltage. Assignment Assignment +12V/1.5A Brightness Control Backlight Enable Ground IB839 User’s Manual...

  • Page 42: Port Debug Tool Connector (J21)

    Hardware Configuration 2.5.5 80 Port Debug Tool Connector (J21) Remarks: Factory use only. 2.5.6 Digital I/O Connector (J22) Remarks: E-CALL_0196-01-200-100 Assignment Assignment Ground +5V/0.5A OUT3 OUT1 OUT2 OUT0 IB839 User’s Manual...

  • Page 43: Front Panel Setting Connector (J23)

    2.5.7 Front Panel Setting Connector (J23) Remarks: E-CALL_0126-01-203-080 Assignment Assignment PWR_BTN- PWR_BTN+ HDD_LED+, 3.3V HDD Active Ground Reset POWER_LED+, 5V Ground IB839 User’s Manual...

  • Page 44: Chapter 3 Drivers Installation

    Chapter 3 Drivers Installation This chapter introduces installation of the following drivers: • ® Intel Chipset Software Installation Utility • Intel® Graphics Drivers • Realtek HD Audio Driver • ® Intel ME Drivers • ® Intel Serial IO Drivers • ®...

  • Page 45: Introduction

    Double click the file to decompress it. Run “CDGuide” to go to the main drivers page as shown below. Run the drivers disk. Click Intel on the left pane and then Intel(R) Amston Lake Chipset Drivers on the right pane. IB839 User’s Manual...
  • Page 46 Chipset Device Software appears, click Next to continue. Accept the software license agreement and proceed with the installation process. On the Readme File Information screen, click Install. After completing the installation, click Finish to complete the setup process. IB839 User’s Manual...

  • Page 47: Vga Driver Installation

    VGA Driver Installation Click Intel on the left pane and then Intel(R) Amston Lake Chipset Drivers on the right pane. Click Intel(R) HD Graphics Driver. Click Begin installation. IB839 User’s Manual...
  • Page 48 Driver Installation Click I agree to accept the license agreement. On the next screen, click Start and then click Finish when installation has been completed. IB839 User’s Manual...

  • Page 49: Realtek Audio Driver Installation

    On the Welcome screen of the InstallShield Wizard, click Next. Realtek Audio Driver will configure the new software installation. After the InstallShield Wizard has successfully installed Realtek Audio Driver, restart the computer to use the program. Click Finish. IB839 User’s Manual...

  • Page 50: Intel ® Management Engine Drivers Installation

    When the Welcome screen appears, click Next. Accept the license agreement and click Next. Cick Next to install to the default folder, or click Change to choose another destination folder After Intel Management Engine Components have been successfully installed, click Finish. IB839 User’s Manual...

  • Page 51: Intel(R) Serial Io Drivers Installation

    In the Welcome screen, click Next. In the next screen, accept the license agreement and click Next. In the Readme File Information screen, click Next. In the Confirmation screen, click Next. When installation has been completed, click Finish. IB839 User’s Manual...

  • Page 52: Lan Driver Installation

    LAN Driver Installation Click LAN Card on the left pane and then Intel LAN Controller Drivers. Click Intel(R) I22x 2.5G Network Drivers . Run the LAN_Setup.bat file as shown on the screen to proceed. Setup is complete. IB839 User’s Manual...
  • Page 53 This page has been intentionally left blank. IB839 User’s Manual...

  • Page 54: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup This chapter describes the different settings available in the AMI BIOS that comes with the board. The topics covered in this chapter are as follows: • Main Settings • Advanced Settings • Chipset Settings • Security Settings •...

  • Page 55: Introduction

    These defaults have been carefully chosen by both AMI and your system manufacturer to provide the absolute maximum performance and reliability. Changing the defaults could make the system unstable and crash in some cases. IB839 User’s Manual...

  • Page 56: 4.3 Main Settings

    BIOS Setup 4.3 Main Settings BIOS Setting Description Sets the date. Use the <Tab> key to switch System Date between the date elements. Set the time. Use the <Tab> key to switch System Time between the time elements. IB839 User’s Manual...

  • Page 57: 4.4 Advanced Settings

    4.4 Advanced Settings This section allows you to configure system features according to your preference. IB839 User’s Manual...

  • Page 58: Connectivity Configuration

    Serial IO UART0 needs to be enabled to select BT Interface interface. BT Tile Mode Options: Enabled/Disabled Advanced Configure ACPI objects for wireless devices Settings Default: Disabled WWAN Configure WWAN related options. Configuration WWAN Device: enable or disable M.2 WWAN device IB839 User’s Manual...
  • Page 59 Vanderpool Technology. Number of E-cores to enable in each Active Efficient-cores processor package. Note: Number of cores and E-cores are looked at together. When both are (o,o), Pcode will enable all cores. Enable/Disable AES (Advanced Encryption Standard) IB839 User’s Manual...

  • Page 60: Power & Performance

    Management Control Allows more than two frequency ranges to be Intel Speedstep supported Enable/Disable Intel Speed Shift Technology Intel Speed Shift support. Enabling will expose the CPPC v2 Technology interface to allow for hardware controlled P- states. IB839 User’s Manual...

  • Page 61: Pch-Fw Configuration

    4.4.4 PCH-FW Configuration IB839 User’s Manual...

  • Page 62: Trusted Computing

    TPM 1.2 will restrict support to TPM 1.2 devices. TPM 2.0 will restrict support to TPM 2.0 devices. Device Select Auto will support both with the default set to TPM 2.0 devices if not found, TPM 1.2 devices will be enumerated. IB839 User’s Manual...

  • Page 63: Acpi Settings

    Enables / Disables the system ability to Enable Hibernation hibernate (OS/S4 Sleep State). This option may be not effective with some OS. Select the highest ACPI sleep state the system ACPI Sleep State will enter when the SUSPEND button is pressed. IB839 User’s Manual...
  • Page 64 BIOS Setup 4.4.7 LVDS Configuration IB839 User’s Manual...
  • Page 65 4.4.8 F81966 Super IO Configuration BIOS Setting Description Serial Port Configuration Sets parameters of Serial Port 1/2/3/4 Enable – provide the standby power for devices. Standby Power on S5 Disable – shutdown the standby power. (Eup) IB839 User’s Manual...

  • Page 66: Hardware Monitor

    Hardware Monitor BIOS Setting Description These fields are the parameters of the hardware monitoring function feature of the Temperatures / motherboard. The values are read-only values Voltages as monitored by the system and show the PC health status. IB839 User’s Manual...

  • Page 67: Usb Configuration

    Max.time the device will take before it properly reports itself to the Host Controller. ‘Auto’ uses Device power-up default value: for a Root port it is 100ms, for a delay Hub port the delay is taken from Hub descriptor. IB839 User’s Manual...
  • Page 68 BIOS Setup 4.4.12 Network Stack Configuration IB839 User’s Manual...

  • Page 69: Nvme Configuration

    4.4.13 NVME Configuration IB839 User’s Manual...

  • Page 70: 4.5 Chipset Settings

    BIOS Setup 4.5 Chipset Settings 4.5.1 System Agent (SA) Configuration 4.5.1.1. Graphics Configuration: IB839 User’s Manual...

  • Page 71: Pch-Io Configuration

    Enables / Disables Serial Port 0 ~ 2. SATA Ports Hot Plug Enables / Disables SATA Ports HotPlug. Power-On After Specify what state to go to when power is re- Power failure applied after a power failure (G3 state) IB839 User’s Manual...

  • Page 72: 4.6 Security Settings

    The mode change requires platform reset. Secure Boot mode options: Standard or Custom. Secure Boot Mode In Custom mode, Secure Boot Policy variables can be configured by a physically present user without full authentication IB839 User’s Manual...

  • Page 73: 4.7 Boot Settings

    Number of seconds to wait for setup activation Timeout key. 65535 (0xFFFF) means indefinite waiting. Bootup NumLock Selects the keyboard NumLock state. State Quiet Boot Enables / Disables Quiet Boot option. FIXED BOOT Sets the system boot order. ORDER Priorities IB839 User’s Manual...

  • Page 74: 4.8 Save & Exit Settings

    Saves the changes done so far as User Defaults Defaults. Restore User Restores the user defaults to all the setup Defaults options. Launch EFI Shell Attempts to launch EFI shell application from filesystem (Shell.efi) from one of the available filesystem device devices. IB839 User’s Manual...
  • Page 75 This page has been intentionally left blank. IB839 User’s Manual...

  • Page 76: Appendix

    Appendix This section provides the mapping addresses of peripheral devices and the sample code of watchdog timer configuration.

  • Page 77: I/O Port Address Map

    SMBus - 54A3 0x00001854-0x00001857 Motherboard resources 0x00000000-0x00000CF7 PCI Express Root Complex 0x00000D00-0x0000FFFF PCI Express Root Complex 0x00003090-0x00003097 Standard SATA AHCI Controller 0x00003080-0x00003083 Standard SATA AHCI Controller 0x00003060-0x0000307F Standard SATA AHCI Controller 0x00003000-0x0000303F Intel(R) UHD Graphics 0x00002000-0x000020FE Motherboard resources IB839 User’s Manual...
  • Page 78 Programmable interrupt controller 0x000000A0-0x000000A1 Programmable interrupt controller 0x000000A4-0x000000A5 Programmable interrupt controller 0x000000A8-0x000000A9 Programmable interrupt controller 0x000000AC-0x000000AD Programmable interrupt controller 0x000000B0-0x000000B1 Programmable interrupt controller 0x000000B4-0x000000B5 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000004D0-0x000004D1 Programmable interrupt controller IB839 User’s Manual...

  • Page 79: Interrupt Request Lines (Irq)

    Standard SATA AHCI Controller IRQ 4294967293 Intel(R) UHD Graphics Intel(R) USB 3.10 eXtensible Host Controller - IRQ 4294967291 1.20 (Microsoft) Intel(R) Serial IO GPIO Host Controller - IRQ 14 INTC1057 IRQ 1 Standard PS/2 Keyboard IRQ 12 Microsoft PS/2 Mouse IB839 User’s Manual...

  • Page 80: Watchdog Timer Configuration

    **endptr; char SIO; printf("Fintek 81966 watch dog program\n"); SIO = Init_F81966(); if (SIO == 0) printf("Can not detect Fintek 81966, program abort.\n"); return(1); }//if (SIO == 0) if (argc != 2) printf(" Parameter incorrect!!\n"); return (1); IB839 User’s Manual...
  • Page 81 //--------------------------------------------------------------------------- void DisableWDT(void) unsigned char bBuf; Set_F81966_LD(0x07); //switch to logic device 7 bBuf = Get_F81966_Reg(0xFA); bBuf &= ~0x01; Set_F81966_Reg(0xFA, bBuf); //disable WDTO output bBuf = Get_F81966_Reg(0xF5); bBuf &= ~0x20; bBuf |= 0x40; Set_F81966_Reg(0xF5, bBuf); //disable WDT //--------------------------------------------------------------------------- IB839 User’s Manual...
  • Page 82 //Fintek 81966 goto Init_Finish; F81966_BASE = 0x00; result = F81966_BASE; Init_Finish: return (result); //--------------------------------------------------------------------------- void Unlock_F81966 (void) outportb(F81966_INDEX_PORT, F81966_UNLOCK); outportb(F81966_INDEX_PORT, F81966_UNLOCK); //--------------------------------------------------------------------------- void Lock_F81966 (void) outportb(F81966_INDEX_PORT, F81966_LOCK); //--------------------------------------------------------------------------- void Set_F81966_LD( unsigned char LD) Unlock_F81966(); outportb(F81966_INDEX_PORT, F81966_REG_LD); outportb(F81966_DATA_PORT, LD); IB839 User’s Manual...
  • Page 83 #define F81966_DATA_PORT (F81966_BASE+1) //--------------------------------------------------------------------------- #define F81966_REG_LD 0x07 //--------------------------------------------------------------------------- #define F81966_UNLOCK 0x87 #define F81966_LOCK 0xAA //--------------------------------------------------------------------------- unsigned int Init_F81966(void); void Set_F81966_LD( unsigned char); void Set_F81966_Reg( unsigned char, unsigned char); unsigned char Get_F81966_Reg( unsigned char); //--------------------------------------------------------------------------- #endif // F81966_H IB839 User’s Manual...

  • Page 84: Onboard Connector Reference Types

    WAFER396-2S-WV VHR-2N Dupont Dupont Digital I/O 2.00 mm-pitch pin 2.00 mm-pitch (Female) header (Male) E-CALL LCD Backlight 0110-161-040 PHR-4. Hirose Hirose LVDS J10, J16 DF20G-20DP-1V DF20A-20DS-1C SSL00-40S SSL20-40S USB Power Control Mapping Function Connector Software Mapping bit_2 IB839 User’s Manual...
  • Page 85 Our company network supports you worldwide with offices in Germany, Austria, Switzerland, the UK and the USA. For more information please contact: FORTEC Elektronik AG | Augsburger Straße 2b | 82110 Germering +49 89 894450-0 info@fortecag.de www.fortecag.de FORTEC Power GmbH | Lise-Meitner-Straße 3 | 64560 Riedstadt FORTEC Integrated GmbH | Augsburger Straße 2b | 82110 Germering +49 6158 8285-0 +49 89 894363-0...
