VEVOR 0.5-F Original Instruction

MANUAL TROLLEY
NEED HELP? CONTACT US!
Have product questions? Need technical support? Please
feel free to contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
This is the original instruction, please read all manual instructions carefully before
operating. VEVOR reserves a clear interpretation of our user manual. The
appearance of the product shall be subject to the product you received. Please
forgive us that we won't inform you again if there are any technology or software
updates on our product.
01
SAFETY INSTRUCTIONS
WARNING:
1.Assemble only according to these instructions.
Improper assembly can create hazards.
2.Wear heavy-duty work gloves during assembly.
3.Over-loading is strictly forbidden
4.While iting the load, passing or working or working
under a litting load is strictly forbidden.
5.Bearing and beam surface should be greased
regularly, and examine the bolts and nuts to make sure
that they are tightened
Caution:
1.Read this material before using this product. Failure
to do so can result in serious injury.
2.The trolley must be used flexibly, and it is strictly
prohibited to use it compulsorily when individual
connections are inflexible.
3. After use, please dry before storage to avoid rusting
of bolts affecting use.
SAVE THESE INSTRUCTIONS
MODEL AND PARAMETERS
Model 0.5-F 1T-F
Ton 0.5 1
Load
Capacity
lbs 1100 2200
I-beam /
2.5-5.5
H-beam track
(64-
Rail width
140mm)
inches (mm）
Colour Black、Blue
02
Model
Load
Capacity
I-beam /
H-beam track
Rail
inches (mm）
Colour
2T-F 3T-F
①Trolley side plates and wheels assembly
2 3 ② Hanging ring plate
④ Thickened washers
⑥nut
4400 6600
2.5-7
(64-177mm)
03
0.5-K 1T-K 2T-K 3T-K
Ton 0.5 1 2 3
lbs 1100 2200 4400 6600
(64-203mm)
width
Black、Orange
ASSEMBLY AND USE
③Trolley Pin
⑤ Thin washers
⑦wire pin
5T-K
5
11000
4.5-8
(114-
203
mm)
