Technical Support and E-Warranty Certificate www.vevor.com/support
PROPANE FORGE
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
Advertisement
Table of Contents
Related Manuals for VEVOR JHLJS03AD
Summary of Contents for VEVOR JHLJS03AD
- Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support PROPANE FORGE We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
- Page 3 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.
-
Page 4: Safety Instructions
SAFETY INSTRUCTIONS WARNING: 1. This product is intended for outside use (Use of this equipment without proper ventilation could result in asphyxiation). 2. Read these instructions carefully before assembling the hose and regulator units. 3. Wear protective gloves, protective glasses and heat-proof clothing when using the furnace to avoid burns. - Page 5 13. The unit will heat large objects to forging temperature with the door open, but it will take a little longer. 14. Never leave the line pressure on when not in use. Always cut the ball valve and tank valve off for storage. 15.
-
Page 6: Structure Diagram
MODEL AND PARAMETERS JHLJS03AD / JHLJS03AE / JHLJS03AF / Model JHLJS03AG / JHLJS03AH Fuel Propane Working pressure 14.5～29PSI(0.1～0.2MPa) Maximum Temperature 2600°F ±3% (1427℃±3%） Shape Hexagon Number of burners Number of doors Material Metal Color Black STRUCTURE DIAGRAM NOTE: Your assembly should... -
Page 7: Parts List
NOTE: 1. It is not necessary to force these fittings to the extreme, however, it is important to use the proper wrench size when tightening the parts. Once the unit is assembled, turn the gas pressure on from the tank to the ball valve and use soapy water to check for leaks on all joints. -
Page 8: Operation Steps
OPERATION STEPS ① Place the copper nozzle at each end of the bridge. ② Insert the burner into each opening at the top of the forging. ③ Secure the burner in place using screws. ④ Insert and secure the copper nozzle into the burner with a set screw. -
Page 9: Maintenance
WARNING Please note that the closing and opening operations are performed in the following order: Opening steps: First, open the ball valve of the gas container, then open the ball valve of the burner(s). Closing steps: First, close the ball valve of the burner(s), then close the ball valve of the gas container. - Page 10 Manufacturer: Shanghaimuxinmuyeyouxiangongsi Address: Shuangchenglu 803nong11hao1602A-1609shi, baoshanqu, shanghai 200000 CN. EC REP: E-CrossStu GmbH. Mainzer Landstr.69, 60329 Frankfurt am Main. UK REP: YH CONSULTING LIMITED. C/O YH Consulting Limited Office 147, Centurion House, London Road, Staines-upon-Thames, Surrey, TW18 4AX Imported to AUS: SIHAO PTY LTD. 1 ROKEVA STREETEASTWOOD NSW 2122 Australia Imported to USA: Sanven Technology Ltd.
- Page 12 Technical Support and E-Warranty Certificate www.vevor.com/support...
