FIBI
34175302 - STYLE: 7530
.
NO. Item description
1
3 DRAWER DRESSER
This product is manufactured by FIBI for
Version 0 - 2024/05/28
VALENTINA Kids
3 DRAWER DRESSER
DO NOT SUBSTITUTE PARTS. PLEASE CONTACT
YOUR RETAIL STORE OR WWW.ROOMSTOGO.COM
WITH SERVICE OR PARTS REPLACEMENT.
QTY
1
Screwdriver
not
included
Anti Tip
Hardware
included
KIDS
Page 1/12
Advertisement
Related Manuals for ROOMS TO GO KIDS VALENTINA FIBI 7530
Summary of Contents for ROOMS TO GO KIDS VALENTINA FIBI 7530
- Page 1 VALENTINA Kids 3 DRAWER DRESSER Screwdriver included Anti Tip Hardware included FIBI 34175302 - STYLE: 7530 NO. Item description IMAGE 3 DRAWER DRESSER DO NOT SUBSTITUTE PARTS. PLEASE CONTACT YOUR RETAIL STORE OR WWW.ROOMSTOGO.COM WITH SERVICE OR PARTS REPLACEMENT. KIDS This product is manufactured by FIBI for Version 0 - 2024/05/28 Page 1/12...
- Page 2 Assembly Instructions Rotate 90° twice counter-clockwise Open the carton using a cutter Cutter included KIDS This product is manufactured by FIBI for Version 0 - 2024/05/28 Page 2/12...
- Page 3 Assembly Instructions Open the carton fold Rotate 90° twice -clockwise KIDS This product is manufactured by FIBI for Version 0 - 2024/05/28 Page 3/12...
- Page 4 Assembly Instructions Lift the carton off Remove all the packaging Dresser ready to work KIDS This product is manufactured by FIBI for Version 0 - 2024/05/28 Page 4/12...
- Page 5 Assembly Instructions-Drawer adjustment Open and unhook the [A] fixing pin under the drawer. Turn the [B] camme (0-4mm max). 0_+4mm KIDS This product is manufactured by FIBI for Version 0 - 2024/05/28 Page 5/12...
- Page 6 Assembly Instructions-Drawer adjustment Close and control the right space between drawers and repeat in left side ( if necessary ). If it is correct, open and hook [A] fixing pin under the drawer. Close the drawer. If necessary, repeat these procedures even on the other drawers. KIDS This product is manufactured by FIBI for Version 0 - 2024/05/28...
- Page 7 Assembly Instructions-Drawer adjustment If a drawer does not close properly, or get's stuck, the most likely cause is that the drawer came of the "glide". This is not a defect and can easily be corrected. Remove all contents of the drawer. If the drawer comes off the glide,visulay inspect underneith the drawer.
- Page 8 Assembly Instructions-Drawer adjustment Rest drawer back on the glides and slide it inwards. KIDS This product is manufactured by FIBI for Version 0 - 2024/05/28 Page 8/12...
- Page 9 Assembly Instructions-Drawer adjustment Make sure the drawer back stop is inserted in the back of the drawer, into the lower drawer hole. drawer glide back back hole stop KIDS This product is manufactured by FIBI for Version 0 - 2024/05/28 Page 9/12...
- Page 10 Assembly Instructions-Drawer adjustment Push the latch into the lock position. Latch Latch close close Right side Left side KIDS This product is manufactured by FIBI for Version 0 - 2024/05/28 Page 10/12...
- Page 11 Assembly Instructions This anti-tip device must be attached to a wall stud using the 2" screw enclosed. 1-Attach a bracket securely to back top rail or bak top edge of the furniture using the 5/8 " screw provided, through the smaller hole in the bracket. 2-Locate the other bracket on the wall over a stud and 2 inches below the mounting bracket secured to the back of your unit.
- Page 12 Assembly Instructions 5-Bring both ends together and rotate the thumb nut onto the threaded end until tight. 6-Confirm that the cable is securely laced and locked. Screwdriver included Furniture WALL Furniture Locked WALL KIDS This product is manufactured by FIBI for Version 0 - 2024/05/28 Page 12/12...
