ROOMS TO GO CREDENZA HMIS F048-03 Assembly Instructions

HMIS F048/F049-03 CREDENZA
***Caution: Please read all instructions carefully before starting the assembly process. These parts are cumbersome and heavy. Therefore, two people
are recommended in order to prevent personal injury and ensure the parts are not damaged during the assembly.
Code

PARTS LIST

Table Top
1
2 Strecher
Right Leg
3
Left Leg
4

TOOLS REQUIRED (NOT PROVIDED)

Description
Phillips screwdriver
Step 1
3
Hardware Pack Location(s):
HMIS F048/F049-03 CREDENZA, SKU #: 26704800/26304927
This product is manufactured by HMIS for
MADE IN VIETNAM
Assembly Instructions
1Pc
1Pc
1Pc
1pc
Sketch
2
1
SKU #: 26704800/26304927
Step
Code
Allen Bolt - Ø1/4x20x19mm
2-3 A Flat washer - Ø1/4x16x1.5mm
Lock washer - Ø1/4"
Allen Key - 4mm
2-3 B
The Furniture Tipping
4 C
Restraint
Step 1: Assembly the legs(3,4) with the Strecher(2) and The table top(1).
Step 2: Then locate Bolts (A) into drilled holes on the legs with on the
strecher(3) and tighten them through by Allen Key (B) provided.
Do not fully tighten all bolts until the assembly is completed.
4
2
Hardware List
16Pcs
16Pcs
16Pcs
Step 2
4
1Pc
1Set
A
B
1 OF 2
