ROOMS TO GO HMIS F1823-04 HUTCH Assembly Instructions

***Caution: Please read all instructions carefully before starting the assembly process. These parts are cumbersome and heavy. Therefore, two people
are recommended in order to prevent personal injury and ensure the parts are not damaged during the assembly.

PARTS LIST

Code
Table Top
1
Right Middle Table Base
2
3
Left Middle Table Base
4 Side Table Base
5 Middle Sheft
Credenza
6
(Sold Separately)
Step 2
4
3
5
Step 3
B
A
This product is manufactured by HMIS for
MADE IN VIETNAM
Assembly Instructions
HMIS F1823-04 HUTCH
1Pc
1Pc
1Pc
2pcs
2pcs
1Pc
2
1
5
Hardware Pack Location(s):
HMIS F1823-04 HUTCH, SKU# : 26818231
SKU #: 26818231
Step
Code
Allen Bolt - Ø1/4x20x19mm
A Flat washer - Ø1/4x16x1.5mm
1+2+3
5 Lock washer - Ø1/4"
Allen Key - 4mm
B
Iron -plate - 94 x 20 x 2mm
5 C
TOOLS REQUIRED (NOT PROVIDED)
Description
Phillips screwdriver
Step 1 :Assembly the Side Table Base(4), Middle Table Base
(2,3) with the Middle Sheft(5) using the bolts (A) and tighten
them through by Allen Key (B) provided.
Do not fully tighten all bolts until the assembly is completed.
Step 2 + Step 3: Assembly Table Base(2), Middle Table Base
(3) with the Table top(1) using the bolts (A) and tighten them
through by Allen Key (B) provided.
Do not fully tighten all bolts until the assembly is completed.
4
5
4
B

Hardware List

Sketch
3
Step 1
A
20Pcs
20Pcs
20Pcs
1Pc
2Pcs
1 OF 2
