Manitowoc

SERVICE/MAINTENANCE MANUAL

The serial number of the crane is the only method Manitowoc has of providing you with

correct parts and service information.

Always furnish serial number of crane and its attachments when ordering parts

or discussing service problems with your Manitowoc distributor or the factory.

©2013 Manitowoc

Published 10-02-13, Control # 210-03

This manual has been prepared for and is considered part of -

12000-1/12000E-1

This Manual is Divided into the following Sections:

SECTION 1

SECTION 2

SECTION 3

SECTION 4

SECTION 5

SECTION 6

SECTION 7

SECTION 8

SECTION 9

SECTION 10

SECTION 11

SECTION 12

SECTION 13

To prevent death or serious injury:

•

Avoid unsafe operation and maintenance.

Crane and attachments must be operated and maintained by trained

and experienced personnel. Manitowoc is not responsible for qualifying

these personnel.

•

Do not operate or work on crane or attachments without first reading

and understanding instructions contained in Operator Information

Manual and Service Manual supplied with crane and applicable

attachments.

•

Store Operator Information Manual and Service Manual in operator's

cab.

If Operator Information Manual or Service Manual is missing from cab,

contact your Manitowoc distributor for a new one.

Model Number

1200Ref

Serial Number

SAFETY SECTION

REFERENCE MATERIALS

TEST PROCEDURES

GENERAL

POWER TRAIN

HYDRAULIC SYSTEM

HOIST SYSTEM

BOOM HOIST SYSTEM

SWING SYSTEM

PROPEL SYSTEM

ELECTRICAL SYSTEM

AIR CONDITIONER

TRANSLIFTER SYSTEM

TROUBLESHOOTING

NOTICE

Table of Contents
