Summary of Contents for Manhattan Comfort DK001
- Page 1 MANHATTAN COMFORT DK001 V.10102024...
-
Page 3: Included In This Package
O.DRAWER RIGHT FRONT PANEL (1) E. BACK PANEL (1) F. CURVED PANEL (2) G. FRONT HORIZONTAL PANEL (1) H. BEHIND HORIZONTAL PANEL (1) I. DRAWER LEFT FRONT PANEL (1) J. DRAWER LEFT PANEL (2) K. DRAWER RIGHT PANEL (2) DK001 Page 3... -
Page 4: Hardware Identification
Hardware Identification WOOD DOWEL - 24pcs SCREW - 2pcs Ø8*30mm Ø6*50mm BLACK HANDLE SCREW - 4pcs SCREW - 12pcs Ø3.5*12mm Ø4*38mm GOLD HANDLE LOCK - 1pc Page 4 DK001... - Page 5 Page 5 DK001...
- Page 6 Step 1: * Insert Nineteen KD BOLT (1) to the TOP PANEL (A) and Two CURVED PANEL(F) ( 19 PCS ) Page 6 DK001...
- Page 7 Step 2: * Insert Eight KD BOLT (1) to the LEFT PANEL (C) and RIGHT PANEL(D). ( 8 PCS ) Page 7 DK001...
- Page 8 Step 3: * Insert Four KD BOLT (1) to the BACK PANEL (E). ( 4 PCS ) Page 8 DK001...
- Page 9 Step 4: * Attach the FRONT HORIZONTAL PANEL(G) and BEHIND HORIZONTAL PANEL(H) to the BETWEEN PANEL(B) by the Two SCREW(6), LOCK(10) and Two WOOD DOWEL (4). ( 2 PCS ) ( 2 PCS ) ( 1 PC ) DK001 Page 9...
- Page 10 * Attach the BEHIND HORIZONTAL PANEL(H) to the BACK PANEL(E) by the Four KD LARGE CAM (2) , Four (3) and Two WOOD DOWEL (4) . ( 2 PCS ) ( 4 PCS ) ( 4 PCS ) Page 10 DK001...
- Page 11 * Attach the LEFT PANEL(C) to the BEHIND HORIZONTAL PANEL(H), FRONT HORIZONTAL PANEL(G) and BACK PANEL(E) by the Four KD LARGE CAM (2) , Four (3) and Four WOOD DOWEL (4). ( 4 PCS ) ( 4 PCS ) ( 4 PCS ) DK001 Page 11...
- Page 12 * Attach the RIGHT PANEL(D) to the BEHIND HORIZONTAL PANEL(H), FRONT HORIZONTAL PANEL(G) and BACK PANEL(E) by the Four KD LARGE CAM (2) , Four (3) and Four WOOD DOWEL (4). ( 4 PCS ) ( 4 PCS ) ( 4 PCS ) Page 12 DK001...
- Page 13 * Attach the Two CURVED PANEL(F) to the TOP PANEL(A) by the Six KD LARGE CAM (2) , Six (3) and Four WOOD DOWEL (4) . ( 4 PCS ) ( 6 PCS ) ( 6 PCS ) DK001 Page 13...
- Page 14 * Attach the Two CURVED PANEL(F) to the LEFT PANEL(C),BACK PANEL(E), BETWEEN PANEL(B) and RIGHT PANEL(D) by the Thirteen KD LARGE CAM (2) , Thirteen (3) and Eight WOOD DOWEL (4) . ( 8 PCS ) ( 13 PCS ) ( 13 PCS ) Page 14 DK001...
- Page 15 Step 10: * Assemble the DRAWER BACK PANEL(L) to the DRAWER LEFT PANEL (J) and DRAWER RIGHT PANEL (K) by the SCREW (9) . ( 8 PCS ) Groove DK001 Page 15...
- Page 16 Step 11: * Slide in the DRAWER BOTTOM PANEL (M). Page 16 DK001...
- Page 17 Step 12: * Assemble the DRAWER SUPPORT PANEL (N) to the DRAWER TRAY by the SCREW (9) . ( 4 PCS ) DK001 Page 17...
- Page 18 * Attach the Two BLACK HANDLE(7) or Two GOLD HANDLE(11) to the DRAWER LEFT FRONT PANEL (I) and DRAWER RIGHT FRONT PANEL (O) by the SCREW (8). ( 10 PCS ) ( 2 PCS ) ( 2 PCS ) ( 4 PCS ) Page 18 DK001...
- Page 19 * Assemble the DRAWER LEFT FRONT PANEL (I) and DRAWER RIGHT FRONT PANEL (O) to the DRAWER TRAY by the Ten KD SMALL CAM (5) and Ten (3). ( 10 PCS ) ( 10 PCS ) DK001 Page 19...
- Page 20 Step 15: *Input Two Drawer tray to the Console. Page 20 DK001...
