Page 1 Carl Zeiss ® ® S7 / OPMI PROergo Instructions for Use G-30-1435-en Version 9.0 6/14/2012...
Page 2 – The index facilitates searching via keywords. Scope The following Instructions for Use apply to OPMI PROergo with the following suspension systems and identifications: – S7 floor stand, reference number: 000000-1087-851 – S7 ceiling mount - rigid, reference number: 000000-1103-022 –...
Page 3 S7 / OPMI PROergo Version 9.0 G-30-1435-en Page 3...
Page 4 S7 / OPMI PROergo Version 9.0 Page 4 G-30-1435-en...
Page 5: Chapter Overview
S7 / OPMI PROergo Chapter overview Chapter: Safety Measures Chapter: System Overview Chapter: Preparations for use Chapter: Operation Chapter: What to do in the event of malfunctions Chapter: Care and Maintenance Chapter: System Data Chapter: Index Version 9.0 G-30-1435-en Page 5...
Page 6 S7 / OPMI PROergo Version 9.0 Page 6 G-30-1435-en...
Page 7: Table Of Contents
S7 / OPMI PROergo Safety Measures Safety Measures Key to symbols .................. 9 Hazard symbols ...................9 Information symbols..................9 Target group ...................10 Field of application ................10 Intended use .....................10 Normal use....................10 Reasonably foreseeable misuse..............10 Liability and warranty..............11 Notes for the operator..............12 Requirements for operation.............
Page 8 Safety Measures S7 / OPMI PROergo Additional labels on S7 wall mount............51 Labels on the light sources of the suspension systems....... 52 Version 9.0 Page 8 G-30-1435-en...
Page 9: Key To Symbols
S7 / OPMI PROergo Safety Measures Key to symbols We would like to inform you about safety aspects which must be observed when handling this device. This chapter contains a summary of the most im- portant information concerning matters relevant to instrument safety.
Page 10: Target Group
Normal use OPMI PROergo is a microscope designed for dental treatment and for surgical procedures in the field of dentistry. Through its selection of illumination systems (halogen, xenon) and its me- chanical construction, it is adapted to the requirements of daily tasks involved in treatment and surgery applications.
Page 11: Liability And Warranty
S7 / OPMI PROergo Safety Measures purposes. In particular, video images and recorded videos and still images may differ from the real treatment area in contrast, color, size and shape. Liability and warranty Warranty and liability depend on the applicable contractual stipulations.
Page 12: Notes For The Operator
Safety Measures S7 / OPMI PROergo Notes for the operator The correct use of the device is absolutely vital for safe operation. Therefore, please thoroughly familiarize yourself with the content of these Instructions for Use before starting up the device. Please also observe the Instructions for Use of additional instrument equipment.
Page 13 (see section "Care and Maintenance"). • Modifications and repairs of this device or any equipment operated to- gether with this device may only be performed by Carl Zeiss service staff or other persons authorized by Carl Zeiss.
Page 14 Safety Measures S7 / OPMI PROergo • Start with the lowest brightness setting and gradually increase brightness up to the necessary and still admissible level. • With increasing age of the light source, the actual illumination intensity delivered at the respective setting decreases (this is a normal property of the system).
Page 15: Requirements For Operation
Safety Measures Requirements for operation Prior to the very first use Carl Zeiss Service or a person authorized by Carl Zeiss will install the device. Please make sure that the following requirements continue to be met for fur- ther operation: ...
Page 16: Before Every Use
Safety Measures S7 / OPMI PROergo Before every use • When adding accessories and/or components please ensure the permissi- ble total weight of the device is not exceeded (see label "Maximum load" or section "Technical Data"). • Before every use, make certain to compensate for any added weight; this will enable the surgical microscope to maintain its balance in all positions of the working range.
Page 17 • Do not force electrical connections. If connection is not readily possible, check whether the plug fits the socket. If any of the connectors are dam- aged, have the Carl Zeiss service team or authorized specialist staff repair them. • Position the suspension system in such a way that you can slide or swing it away from the patient at any time.
Page 18: During Use
Safety Measures S7 / OPMI PROergo More specific information about the ceiling mount: • Move the lift arm or the lifting column down to its lower end position. • Do not activate the lifting column or the lift arm during surgery. Do not use the lifting column or the lift arm for focusing.
Page 19: After Every Use
S7 / OPMI PROergo Safety Measures • Risk of crushing - mind your fingers! Fingers may be crushed in areas marked with the label "Crushing Hazard". Do not touch these areas whilst the machine is being moved. After every use •...
Page 20: Risk Of Burn Injuries Caused By High Illumination Intensity
Safety Measures S7 / OPMI PROergo Risk of burn injuries caused by high illumination intensity General The xenon illumination is a light source with high intensity. If used improperly, excessive illumination intensities may lead to third-degree burns. Keep the il- luminated tissue moist and make sure it is sufficiently rinsed.
Page 21 Recommendations Due to the large number of different factors involved and the lack of scientific publications on this topic, Carl Zeiss cannot provide guidance on acceptable illumination intensities and exposure durations. However, the surgical micro- scope has several features that can help the user to reduce the risk of burn injuries: –...
Page 22 S7 / OPMI PROergo Final remark Carl Zeiss recommends to reduce illumination of the surgical field in that pos- sible extent to ensure the patient's security and a good microscopic image. Please refer to the warnings and precautions in this case.
Page 23: Safety Devices Of The Suspension Systems
S7 / OPMI PROergo Safety Measures Safety devices of the suspension systems Halogen illumination system 1 Manual switching to the backup lamp The lamp housing contains a backup lamp which is automatically swung into the illumination beam path when the first lamp fails. If this automatic function fails, you can switch on the backup lamp by pressing this button.
Page 24 Safety Measures S7 / OPMI PROergo Xenon illumination system CAUTION The xenon lamp has a limited service life of 500 h! If used beyond its maximum service life, the xenon lamp may explode. • Please replace the xenon lamp in due time.
Page 25 S7 / OPMI PROergo Safety Measures Version 9.0 G-30-1435-en Page 25...
Page 26 Safety Measures S7 / OPMI PROergo Ceiling mount with lifting column Lifting column Selector switch for setting the optimum viewing height of the surgical microscope or for downward movement into the working position. As long as you keep the selector switch in the turned position, the lifting column moves upward (2) or downward (1), depending on the switch posi- tion.
Page 27 S7 / OPMI PROergo Safety Measures Version 9.0 G-30-1435-en Page 27...
Page 28: Symbols And Labels On The Device
Label on the knob for tilting the microscope upwards. 4 "Balance setting of front-to-back tilt axis" label Label on the knob for tilting the microscope downwards. 5 "OPMI PROergo" device label The device label contains the following information: – Manufacturer (company –...
Page 29 S7 / OPMI PROergo Safety Measures 7 "Friction adjustment of front-to-back tilt axis" label Label on the knob for setting the required friction of the front-to-back tilt axis. 8 "Friction adjustment of lateral tilt axis" label Label on the knob for setting the required friction of the lateral tilt axis.
Page 30 Safety Measures S7 / OPMI PROergo 9 "Filter selector" marking The illustration on the left shows the marks on the filter selector knob: 10 Labeling of zoom and focusing switches Labeling of the zoom and focusing switches on the handgrips.
Page 31 S7 / OPMI PROergo Safety Measures Version 9.0 G-30-1435-en Page 31...
Page 32: Labels On S7 Floor Stand
Safety Measures S7 / OPMI PROergo Labels on S7 floor stand 1 "Risk of crushing" label Fingers may be pinched between the carrier and suspension arms. Do not touch this area while the surgical microscope is being moved. 2 "Maximum load" warning label The maximum load on the suspension arm must not exceed 14 kg.
Page 33 S7 / OPMI PROergo Safety Measures Version 9.0 G-30-1435-en Page 33...
Page 34 Safety Measures S7 / OPMI PROergo 7 "Observe Instructions for Use" label Observe the Instructions for Use or accompanying documents. 8 Year of manufacture This label indicates the year of manufacture of the device. 9 Rating label The rating label provides the following information: –...
Page 35 S7 / OPMI PROergo Safety Measures Version 9.0 G-30-1435-en Page 35...
Page 36 Manufacturer (company name) – Your options to contact the device manufacturer, i.e., phone number, fax number and email address of the local contact of the national Carl Zeiss sales organization. XXXX XXXXXX – SIP No. A unique identification number assigned to your device.
Page 37 S7 / OPMI PROergo Safety Measures Version 9.0 G-30-1435-en Page 37...
Page 38: Additional Labels On S7 Floor Stand (Instrument Tray Option)
Safety Measures S7 / OPMI PROergo Additional labels on S7 floor stand (instrument tray option) 1 "Maximum load on instrument tray" indicating label The maximum load of accessories on the instrument tray must not exceed 13 kg. Version 9.0 Page 38...
Page 39 S7 / OPMI PROergo Safety Measures Version 9.0 G-30-1435-en Page 39...
Page 40: Labels On S7 Ceiling Mount
Safety Measures S7 / OPMI PROergo Labels on S7 ceiling mount 1 "Risk of crushing" label Fingers may be pinched between the carrier and suspension arms. Do not touch this area while the surgical microscope is being moved. 2 "Maximum load" warning label The maximum load on the suspension arm must not exceed 14 kg.
Page 41 S7 / OPMI PROergo Safety Measures Version 9.0 G-30-1435-en Page 41...
Page 42 Manufacturer (company name) – Your options to contact the device manufacturer, i.e., phone number, fax number and email address of the local contact of the national Carl Zeiss sales organization. XXXX XXXXXX – SIP No. A unique identification number assigned to your device.
Page 43 S7 / OPMI PROergo Safety Measures 12 Rating label (for S7 ceiling mount with lifting column) The rating label provides the following information: – Manufacturer's symbol – Manufacturer (company name) Carl Zeiss Meditec AG – Manufacturer's address Goeschwitzer Strasse 51-52 07745 Jena, Germany –...
Page 44: Additional Label On S7 Ceiling Mount With Lifting Column
Safety Measures S7 / OPMI PROergo Additional label on S7 ceiling mount with lifting column 1 "Lifting column operation" indicating sign Switch for moving the vertical position upward or downward. Version 9.0 Page 44 G-30-1435-en...
Page 45 S7 / OPMI PROergo Safety Measures Version 9.0 G-30-1435-en Page 45...
Page 46: Labels On S7 Wall Mount And On S7 Centro Suspension System
Safety Measures S7 / OPMI PROergo Labels on S7 wall mount and on S7 Centro suspension system 1 "Risk of crushing" label Fingers may be pinched between the carrier and suspension arms. Do not touch this area while the surgical microscope is being moved.
Page 47 S7 / OPMI PROergo Safety Measures Version 9.0 G-30-1435-en Page 47...
Page 48 Manufacturer (company name) – Your options to contact the device manufacturer, i.e., phone number, fax number and email address of the local contact of the national Carl Zeiss sales organization. XXXX XXXXXX – SIP No. A unique identification number assigned to your device.
Page 49 S7 / OPMI PROergo Safety Measures 12 Rating label on wall mount with long arm The rating label provides the following information: – Manufacturer's symbol – Manufacturer (company name) Carl Zeiss Meditec AG – Manufacturer's address Goeschwitzer Strasse 51-52 07745 Jena, Germany –...
Page 50 Safety Measures S7 / OPMI PROergo 13 Rating label on S7 Centro suspension system The rating label provides the following information: – Manufacturer's symbol – Manufacturer (company name) Carl Zeiss Meditec AG – Manufacturer's address Goeschwitzer Strasse 51-52 07745 Jena, Germany –...
Page 51 S7 / OPMI PROergo Safety Measures Additional labels on S7 wall mount 14 "Risk of crushing" label Fingers may be crushed in this area. Do not touch this area while the sur- gical microscope is being moved. Version 9.0 G-30-1435-en...
Page 52 Safety Measures S7 / OPMI PROergo Labels on the light sources of the suspension systems Xenon light source 1 "Warning of a hazard area" indicating label The Superlux light source is equipped with an integrated xenon illumina- tion system. The xenon illumination must not be used for ophthalmic sur- gery.
Page 53 S7 / OPMI PROergo Safety Measures Version 9.0 G-30-1435-en Page 53...
Page 54 Safety Measures S7 / OPMI PROergo Halogen light source 1 "Filter selector for halogen light source" This label indicates the position of the filter wheel. 2 "Instructions for Use" label Observe the Instructions for Use or accompanying documents. Version 9.0...
Page 55 System Overview System Overview PROergo surgical microscope on S7 suspension system ....58 Features ....................58 System components ..................60 OPMI PROergo surgical microscope ..........62 Design .......................62 Controls, displays, connections ..............64 Tiltable binocular tube and eyepieces ............70 S7 floor stand ..................74 Design .......................74 Suspension arm ..................76...
Page 56 System Overview S7 / OPMI PROergo Connector panel ..................102 Illumination system................104 Halogen illumination system ..............106 Xenon illumination system ..............108 Control panel and menu overview ..........112 Structure of the menus ................114 Foot control panel (option) ............134 Features....................134 Design ....................
Page 57 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 57...
Page 58: Proergo Surgical Microscope On S7 Suspension System
Suspension systems The S7 floor stand is a suspension system for Zeiss surgical microscopes. It comprises a suspension arm, a carrier arm, a stand column and a stand base. A maneuvering handle mounted on the stand column is used to move the stand and to attach the foot control panel.
Page 59 S7 / OPMI PROergo System Overview The carrier arm of all suspension systems contains the control unit with all electrical supply systems required for the control of a motorized surgical mi- croscope. You can control the motorized functions using the handgrips, or via a foot control panel (option).
Page 60: System Components
3 S7 wall mount 4 S7 floor stand 5 S7 Centro suspension system 6 OPMI PROergo surgical microscope with 180° tiltable tube and magnetic eyepieces The overall system comprises a suspension system and a microscope. All op- tions described in these Instructions for Use can be ordered separately.
Page 61 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 61...
Page 62: Opmi Proergo Surgical Microscope
System Overview S7 / OPMI PROergo OPMI PROergo surgical microscope Design The OPMI PROergo surgical microscope comprises the following modules: 1 Microscope body 2 Balancing system including magnetic brakes This system allows balancing of the surgical microscope. When the mag- netic brakes are unlocked, the surgical microscope can be positioned al- most effortlessly.
Page 63 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 63...
Page 64: Controls, Displays, Connections
System Overview S7 / OPMI PROergo Controls, displays, connections 1 Friction adjustment of vertical axis Use this knob to adjust the friction of the vertical axis as required. 2 Balance setting of lateral tilt motion Use this knob to adjust the balance setting of the lateral tilt motion.
Page 65 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 65...
Page 66 System Overview S7 / OPMI PROergo 8 Rotating the video image (option) This knob allows you to rotate the video image, i.e. the video image can be rotated to provide better orientation for the assistant or for documen- tation purposes. The zero position of the knob is indicated by a clickstop.
Page 67 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 67...
Page 68 System Overview S7 / OPMI PROergo 14 Release buttons, freely programmable In combination with an S7 suspension system, specific functions of the suspension system can be assigned to these buttons (e.g.: focus, zoom, brightness control, still and video camera release, etc.). Configuring these buttons is described on page 120 (Handgrip Settings menu).
Page 69 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 69...
Page 70: Tiltable Binocular Tube And Eyepieces
System Overview S7 / OPMI PROergo Tiltable binocular tube and eyepieces 180° tiltable tube 1 PD adjustment knob The correct position has been set when the two eyepiece images merge into one. 2 180° tiltable tube 3 Eyepiece tube Version 9.0...
Page 71 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 71...
Page 72 System Overview S7 / OPMI PROergo Widefield eyepieces with magnetic coupling NOTE Eyepieces have a magnetic field! Please note that the usual rules for the handling of magnets must be ob- served for eyepieces removed from the tube: • Do not place the eyepiece near instruments which may be magnetizable.
Page 73 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 73...
Page 74: S7 Floor Stand
System Overview S7 / OPMI PROergo S7 floor stand Design 1 Suspension arm 2 Lamp housing (either xenon or halogen illumination) 3 Carrier arm 4 Control panel 5 Connector panel 6 Handgrip 7 Cable supports (2x, on the right and left of the stand column)
Page 75 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 75...
Page 76: Suspension Arm
System Overview S7 / OPMI PROergo Suspension arm 1 Lamp housing with halogen or xenon illumination The suspension system is equipped with an illumination system for light guides. Each lamp housing contains a backup lamp. When a halogen illu- mination system is used, the backup lamp will be automatically swung in if the first lamp fails.
Page 77 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 77...
Page 78: Carrier Arm, Stand Column, Stand Base
System Overview S7 / OPMI PROergo Carrier arm, stand column, stand base 1 Control and display panel The control and display panel permits you to control all electrical functions of the S7 floor stand and the surgical microscope. 2 Friction Knob for adjusting the friction of the carrier arm's swivel movement.
Page 79 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 79...
Page 80: Connector Panel Of S7 Floor Stand
Connector panel of S7 floor stand CAUTION Danger! Electrical voltage! • Only connect medical devices and accessories intended by Carl Zeiss for use with this system to power outlet socket (5). When connecting other devices, make sure that safety is guaranteed re- garding admissible touch currents and ground leakage currents as per IEC 60601-1:2005.
Page 81 S7 / OPMI PROergo System Overview 9 Y/C video port (option) for S-VHS video signal output. 10 Display window for rated voltage The voltage shown here must correspond to the rated line voltage pro- vided on the site of installation. You can adjust the sliding switch using a suitable tool.
Page 82: Instrument Tray (Option)
The instrument tray (1) can carry a maximum of 13 kg. The tray has been de- signed, for example, for mounting MediLive Trio by Carl Zeiss. Further acces- sories can be installed on the instrument tray using the strap provided.
Page 83 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 83...
Page 84: S7 Ceiling Mount
System Overview S7 / OPMI PROergo S7 ceiling mount Design 1 Ceiling flange 2 Stand column 3 Control panel 4 Connector panel 5 Lamp housing (either xenon or halogen illumination) 6 Suspension arm 7 Carrier arm Version 9.0 Page 84...
Page 85 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 85...
Page 86: Carrier And Suspension Arms
System Overview S7 / OPMI PROergo Carrier and suspension arms 1 Lamp housing with halogen or xenon illumination The suspension system is equipped with an illumination system for light guides. Each lamp housing contains a backup lamp. When a halogen illu- mination system is used, the backup lamp will be automatically swung in if the first lamp fails.
Page 87 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 87...
Page 88: Connector Panel
System Overview S7 / OPMI PROergo Connector panel 1 Opening for the system cable from an external video camera 2 Remote socket for controlling external devices (e.g. MEDIALINK 100) with a max. breaking capacity of 24 V/0.5 A. 3 Connector for control component (option) Here, a foot control panel can be connected.
Page 89 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 89...
Page 90: S7 Ceiling Mount With Lifting Column
System Overview S7 / OPMI PROergo S7 ceiling mount with lifting column Design 1 Ceiling flange 2 Lifting column 3 Control panel 4 Connector panel 5 Lamp housing (either xenon or halogen illumination) 6 Suspension arm 7 Carrier arm Version 9.0...
Page 91 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 91...
Page 92: Ceiling Flange With Lifting Column
System Overview S7 / OPMI PROergo Ceiling flange with lifting column 1 Lifting column 2 Selector switch for setting the optimum viewing height of the surgical microscope or for downward movement into the working position. As long as you keep the selector switch in the turned position, the lifting column moves downward (3) or upward (4), depending on the switch po- sition.
Page 93 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 93...
Page 94: Carrier And Suspension Arms
System Overview S7 / OPMI PROergo Carrier and suspension arms 1 Lamp housing with halogen or xenon illumination The suspension system is equipped with an illumination system for light guides. Each lamp housing contains a backup lamp. When a halogen illu- mination system is used, the backup lamp will be automatically swung in if the first lamp fails.
Page 95 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 95...
Page 96: Connector Panel Of S7 Ceiling Mount With Lifting Column
System Overview S7 / OPMI PROergo Connector panel of S7 ceiling mount with lifting column 1 Opening for the system cable from an external video camera 2 Remote socket for controlling external devices (e.g. MEDIALINK 100) with a max. breaking capacity of 24 V/0.5 A.
Page 97 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 97...
Page 98: S7 Wall Mount And S7 Centro Suspension System
System Overview S7 / OPMI PROergo S7 wall mount and S7 Centro suspension system The functions of the S7 Centro suspension system are identical to those of the S7 wall mount. Design 1 Wall anchor plate (for S7 wall mount only)
Page 99 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 99...
Page 100: Carrier And Suspension Arms
System Overview S7 / OPMI PROergo Carrier and suspension arms 1 Lamp housing with halogen or xenon illumination The suspension system is equipped with an illumination system for light guides. Each lamp housing contains a backup lamp. When a halogen illu- mination system is used, the backup lamp will be automatically swung in if the first lamp fails.
Page 101 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 101...
Page 102: Connector Panel
System Overview S7 / OPMI PROergo Connector panel 1 Opening for the system cable from an external video camera 2 Remote socket for controlling external devices (e.g. MEDIALINK 100) with a max. breaking capacity of 24 V/0.5 A. 3 Connector for control component (option) Here, a foot control panel can be connected.
Page 103 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 103...
Page 104: Illumination System
System Overview S7 / OPMI PROergo Illumination system Two different types of illumination are available for the suspension system. 1 Halogen illumination The halogen light source is equipped with an illumination system for fiber illumination. The lamp housing contains a backup lamp which is automat- ically swung into the illumination beam path when the first lamp fails.
Page 105 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 105...
Page 106: Halogen Illumination System
System Overview S7 / OPMI PROergo Halogen illumination system The illumination system has been designed for fiber illumination. The lamp housing contains a backup lamp which automatically swings into the illumi- nation beam path when the first lamp fails. 1 Lamp module...
Page 107 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 107...
Page 108: Xenon Illumination System
System Overview S7 / OPMI PROergo Xenon illumination system CAUTION Risk of injury caused by xenon light in the facial area Surgery using xenon light in the facial area may seriously harm the patient's eyes. • The patient's eyes must not be exposed to xenon light.
Page 109 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 109...
Page 110 System Overview S7 / OPMI PROergo When inserting a new lamp module, make sure that the knob (2) is set to “1". If the first lamp fails, switch to the second lamp in logical sequence. 3 Indicator: Backup lamp is in use When the segment in knob (2) lights up, the backup lamp is in use.
Page 111 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 111...
Page 112: Control Panel And Menu Overview
System Overview S7 / OPMI PROergo Control panel and menu overview The control panel consists of a graphic display (1) with control keys (3). All functions can be interactively controlled via menus. The display shows the se- lected functions and settings. Using control buttons (3) you can move through the menus and activate a selection field.
Page 113 S7 / OPMI PROergo System Overview Version ..300 mm Please wait ... USER 1 NONE USER 2 USER 3 NONE 50 % 300 mm 50 % 50 % 50 % 4.9 x 300 mm 20 % Standard Close Press Enter...
Page 114: Structure Of The Menus
After you have switched on the system, the software is loaded. The growing size of the ZEISS logo indicates that this loading process is still in progress. The release number is displayed in the top left corner. The system then performs a self-test.
Page 115 S7 / OPMI PROergo System Overview Edit User menu Three different users or applications (e.g. Endo, Paro, Cosmetic) and their pro- files can be stored in the User menu. The Edit User menu allows you to enter your personal user name. When Edit icon (1) after the user name is activated, Dr.
Page 116 System Overview S7 / OPMI PROergo Surgery menu The Surgery menu is constantly displayed during operation. The menu in- cludes the icons (from left to right) for the following menus: Zoom / Focus / 4.9x 300 mm Illumination. Bottom: User / Options / Video und Balance. The displays below...
Page 117 S7 / OPMI PROergo System Overview Focus menu You can adjust the settings for the following functions in the Focus menu: Zoom Link: The Zoom Link function allows the focusing speed to be coupled to the cur- 50 % 300 mm rent magnification.
Page 118 System Overview S7 / OPMI PROergo Illumination menu You can adjust the settings for the following functions in the Illumination menu: Zoom Link Intensity: 50 % 50 % The illumination intensity from minimum to maximum brightness from 5 % to 100 % in steps of 5 %. This setting can be adjusted for the xenon il- lumination and the halogen illumination.
Page 119 S7 / OPMI PROergo System Overview Options menu Activate the Options icon and press the enter button to access the Options menu. The Options menu comprises the following submenus (from the top): – Handgrip Settings menu – Foot Control menu –...
Page 120 System Overview S7 / OPMI PROergo Handgrip Settings menu This menu allows you to assign one of the listed functions to each of the four buttons (A, B, C, D) for every user or application: – Light on/off: switching the illumination on and off.
Page 121 S7 / OPMI PROergo System Overview – Autofocus: triggering the SpeedFokus autofocus option. – Video Gain +/-: adjusting the brightness level of the integrated video sys- tem (option). – OSD on/off: activating/deactivating the on-screen display of the integrat- ed video system (option).
Page 122 System Overview S7 / OPMI PROergo relevant adjustment knobs. If "Off" has been activated by pressing the Enter button, the magnetic brakes will be unlocked and remain unlocked when you press release button (1) the next time. To reactivate the magnetic brakes, select "On" and press the Enter button.
Page 123 S7 / OPMI PROergo System Overview SpeedFokus autofocus option The SpeedFokus autofocus option permits you to select and automatically focus on a feature in the ROI (region of interest, measuring field) in the image of the surgical field. The SpeedFokus autofocus function is based on the evaluation of the video image contrast: during focusing of the microscope's Varioskop optics, Speed- Fokus continuously determines the video image contrast in the selected ROI.
Page 124 This function permits you to activate or deactivate the automatic start of the focusing process. For repositioning the OPMI PROergo, you have to unlock its magnetic brakes. Press the release button for the magnetic brakes on one of the handgrips. The magnetic brakes of the microscope are unlocked for as long as you press one of these release buttons.
Page 125 S7 / OPMI PROergo System Overview Submenu "Advanced Settings" – This submenu is only available in systems equipped with an external video camera. – This submenu contains camera-specific settings. These settings only need to be changed when a different video camera is installed.
Page 126 System Overview S7 / OPMI PROergo Video Settings menu (option) The Video Settings menu permits you to configure the integrated 1CCD video camera in the Config submenu, and to enter or edit text using the OSD func- tion. Activate the Video icon and press the enter button to access the Video Set-...
Page 127 S7 / OPMI PROergo System Overview Freeze/Live setting The freeze button permits you to freeze the current live video image and to Press Enter Auto Auto White Balance display it as a full-screen freeze frame on the video monitor. During this time,...
Page 128 System Overview S7 / OPMI PROergo OSD menu (On Screen Display) The OSD function allows you to display freely selectable texts, a ruler and mi- croscope parameters such as magnification and working distance on the video monitor. This information is included in the picture when the screen shot is saved or printed.
Page 129 S7 / OPMI PROergo System Overview If "Ruler" selection field (4) has been activated, a ruler including a dimension is displayed in the bottom left corner of the screen. The ruler and the dimen- sion specified automatically change with the zoom and focus settings. The nu- merical value of the dimension displayed can be 2.5 / 5 / 10 / or 20 mm.
Page 130 System Overview S7 / OPMI PROergo Balance menu The Balance menu has been designed as a user prompt and consists of six im- ages explaining the balancing procedure. You can scroll through the Balance menu using the arrow buttons ( ).
Page 131 S7 / OPMI PROergo System Overview Laser menu Since this surgical microscope model does not allow the attachment of a laser, the Laser menu is not used. You should therefore check that the default setting "NONE "- No Laser is dis- played in all menus (1) to ensure problem-free operation.
Page 132 System Overview S7 / OPMI PROergo Malfunctions (Error message menu) This window appears on your display when a malfunction or incorrect opera- tion has occurred. At the same time, this is also indicated by three beeps. In addition, the type of malfunction present and a code number are displayed in field (1).
Page 133 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 133...
Page 134: Foot Control Panel (Option)
System Overview S7 / OPMI PROergo Foot control panel (option) Features The foot control panel permits you to operate various functions of a suspen- sion system or surgical microscope. The assignment of functions to the con- trols on the foot control panel is described on the next page. Only functions provided in the system configuration used (suspension system, surgical micro- scope) can be controlled.
Page 135 S7 / OPMI PROergo System Overview Version 9.0 G-30-1435-en Page 135...
Page 136: Foot Control Panel With 14 Functions
System Overview S7 / OPMI PROergo Foot control panel with 14 functions The illustration shows the standard assignment of functions to the foot con- trol panel with 14 functions. The focus/zoom assignment can be changed by our service staff, on request.
Page 137: Foot Control Panel With 8 Functions
S7 / OPMI PROergo System Overview Foot control panel with 8 functions The illustration shows the standard assignment of functions to the foot con- trol panel with 8 functions. The focus/zoom assignment can be changed by our service staff, on request.
Page 138: Foot Control Panel For Zoom And Focus
System Overview S7 / OPMI PROergo Foot control panel for zoom and focus 1 FOCUS : reducing the working distance 2 FOCUS : increasing the working distance 3 ZOOM : increasing the field of view, reducing magnification 4 ZOOM : reducing the field of view, increasing magnification Version 9.0...
Page 139 S7 / OPMI PROergo Preparations for use Preparations for use Attaching the equipment...............142 Mounting the tube and eyepieces............142 Connections................... 144 Connecting the strain relief device ............144 Connecting the suspension system - S7 floor stand........146 Connecting the suspension system - S7 ceiling mount with rigid column ....................148...
Page 140 Preparations for use S7 / OPMI PROergo Balancing the surgical microscope ..........164 Adjusting the surgical microscope ..........169 Preparing the system for sterile use ..........171 Attaching asepsis caps ................171 Applying drapes..................171 Configuring the camera settings (config) ........172 Relocating the S7 floor stand ............178 Version 9.0...
Page 141 S7 / OPMI PROergo Preparations for use Version 9.0 G-30-1435-en Page 141...
Page 142: Attaching The Equipment
Preparations for use S7 / OPMI PROergo Attaching the equipment Mounting the tube and eyepieces CAUTION Risk of injury caused by lowering of the surgical microscope or accessories falling down! • Never change modules and accessories during a surgical procedure or above the patient.
Page 143 S7 / OPMI PROergo Preparations for use Version 9.0 G-30-1435-en Page 143...
Page 144: Connections
Preparations for use S7 / OPMI PROergo Connections Connecting the strain relief device You can secure the power plug and the multipoint connector of the switching component against inadvertent loosening by installing the two cables in strain relief device (1).
Page 145 S7 / OPMI PROergo Preparations for use 320 mm Version 9.0 G-30-1435-en Page 145...
Page 146: Connecting The Suspension System - S7 Floor Stand
Preparations for use S7 / OPMI PROergo Connecting the suspension system - S7 floor stand NOTE Risk of tripping! Inappropriate routing of cables increases the risk of tripping. • Always run cables in a manner that will not impede the user's move- ments.
Page 147 S7 / OPMI PROergo Preparations for use Version 9.0 G-30-1435-en Page 147...
Page 148: Connecting The Suspension System - S7 Ceiling Mount With Rigid Column
Preparations for use S7 / OPMI PROergo Connecting the suspension system - S7 ceiling mount with rigid column • Check the voltage indicated at (2). The suspension system is set at the factory to the rated voltage used in the country of destination.
Page 149 S7 / OPMI PROergo Preparations for use Version 9.0 G-30-1435-en Page 149...
Page 150: Connecting The Suspension System - S7 Ceiling Mount With Lifting Column
Preparations for use S7 / OPMI PROergo Connecting the suspension system - S7 ceiling mount with lifting column • Check the voltage indicated at (2). The suspension system is set at the factory to the rated voltage used in the country of destination.
Page 151 S7 / OPMI PROergo Preparations for use Version 9.0 G-30-1435-en Page 151...
Page 152: Connecting The Suspension System - S7 Wall Mount
Preparations for use S7 / OPMI PROergo Connecting the suspension system - S7 wall mount • Check the voltage indicated at (2). The suspension system is set at the factory to the rated voltage used in the country of destination. The rated voltage indicated at window (2) must correspond to the rated voltage available on the site of installation.
Page 153 S7 / OPMI PROergo Preparations for use Version 9.0 G-30-1435-en Page 153...
Page 154: Connecting The Video Monitor And The Medialink 100 (Option)
Preparations for use S7 / OPMI PROergo Connecting the video monitor and the MEDIALINK 100 (option) NOTE Use of video signal isolation When video signals are led out of the OR, e.g. for a conference, this may cause excessive leakage and contact currents.
Page 155 S7 / OPMI PROergo Preparations for use (Option) VIDEO IN VIDEO IN BNC(FBAS) MEDIALINK 100 BNC(FBAS) Remote Version 9.0 G-30-1435-en Page 155...
Page 156: Adjusting The System - S7 Floor Stand
Preparations for use S7 / OPMI PROergo Adjusting the system - S7 floor stand Balancing the suspension arm CAUTION Risk of crushing - mind your fingers! Fingers may be crushed in the areas marked with the "risk of crushing" label.
Page 157 S7 / OPMI PROergo Preparations for use • Lower the surgical microscope until it can be focused on the surgical field (depending on the focal length of the objective lens), while at the same time allowing for a sufficient safety distance from the surgical field.
Page 158: Adjusting The System - S7 Ceiling And Wall Mounts And S7 Centro Suspension System
Preparations for use S7 / OPMI PROergo Adjusting the system - S7 ceiling and wall mounts and S7 Centro suspension system Balancing the suspension arm CAUTION Risk of crushing - mind your fingers! Fingers may be crushed in the areas marked with the "risk of crushing" label.
Page 159 S7 / OPMI PROergo Preparations for use • Lower the surgical microscope until it can be focused on the surgical field (depending on the focal length of the objective lens), while at the same time allowing for a sufficient safety distance from the surgical field.
Page 160: Adjusting The System - S7 Ceiling Mount With Lifting Column
Preparations for use S7 / OPMI PROergo Adjusting the system - S7 ceiling mount with lifting column Setting an ergonomic working height CAUTION Risk of injury caused by lifting column Activating the lifting column may cause injuries. • Do not activate the lifting column during surgery.
Page 161 S7 / OPMI PROergo Preparations for use Version 9.0 G-30-1435-en Page 161...
Page 162: Balancing The Suspension Arm
Preparations for use S7 / OPMI PROergo Balancing the suspension arm CAUTION Risk of crushing - mind your fingers! Fingers may be crushed in the areas marked with the "risk of crushing" label. • Do not touch these areas while the system is being moved or brought in its working / transport position.
Page 163 S7 / OPMI PROergo Preparations for use – The limit of downward travel is only effective in the lower part of the sus- pension arm's vertical movement range (starting from the arm's horizontal position). – If you wish to use the suspension arm's full range of vertical movement, lower the suspension arm as far as it will go and then firmly retighten lock- ing lever (2).
Page 164: Balancing The Surgical Microscope
Preparations for use S7 / OPMI PROergo Balancing the surgical microscope NOTE Injury to the patient! With an incorrectly balanced system, brake release may lead to uncontrolled movements of the suspension arm. • Use the surgical microscope in perfectly balanced condition only! •...
Page 165 S7 / OPMI PROergo Preparations for use Version 9.0 G-30-1435-en Page 165...
Page 166 Preparations for use S7 / OPMI PROergo Balancing the front-to-back tilt motion NOTE Unintentional movement of the system With an incorrectly balanced system uncontrolled movements of the suspen- sion system may occur. • If uncontrolled movements occur, move the surgical microscope, by over- coming the braking effect, into a position in which the patient is not put at risk.
Page 167 S7 / OPMI PROergo Preparations for use Version 9.0 G-30-1435-en Page 167...
Page 168 Preparations for use S7 / OPMI PROergo Correcting the balance of the front-to-back tilt motion After a slight change in the position of accessories (e.g. the angle of the coo- bservation tube) it may become necessary to correct the balance setting.
Page 169: Adjusting The Surgical Microscope
S7 / OPMI PROergo Preparations for use Adjusting the surgical microscope Notes on adjustment – It is recommended to provide the interpupillary distance as well as the re- fraction values for the different users to adjust the surgical microscope more quickly and to preset the values in the scope of the preparation.
Page 170 Preparations for use S7 / OPMI PROergo • Repeat the entire procedure for the second eyepiece.  Now, the microscope is adjusted in such a way that the image is sharply defined over the complete magnification range without any renewed fo- cusing during the magnification setting.
Page 171: Preparing The System For Sterile Use
Attaching asepsis caps For sterile use, the system can be equipped with resterilizable products. The asepsis sets available from Carl Zeiss contain caps and hand grips which can be sterilized in autoclaves. For detailed information on sterilization please see the enclosed instructions "Preparation of resterilizable products" for the re- spective asepsis sets.
Page 172: Configuring The Camera Settings (Config)
Preparations for use S7 / OPMI PROergo Configuring the camera settings (config) The configuration menu permits you to configure the camera settings of the 1 chip video camera. The user program is set by default on delivery. 4.9 x 300 mm 20 % •...
Page 173 S7 / OPMI PROergo Preparations for use Navigation in the Config mode using the control buttons Control buttons Press the control buttons to access the submenu required. To activate the selected submenu, press the enter button. Enter button The enter button permits you to jump on from all submenus (except Chroma).
Page 174 Preparations for use S7 / OPMI PROergo Lightmeter The use of the Lightmeter function will only be meaningful if Brightness has been set to the automatic mode (Auto). You can select between three metering patterns provided by the video camera in the Lightmeter selection field: Integral, small, or large.
Page 175 S7 / OPMI PROergo Preparations for use Chroma submenu The Chroma submenu permits you to adjust the overall color impression pro- vided by the camera. Chroma Use the control buttons for continuous adjustment of the color intensity in a range between 0% and 100%. The value currently set is displayed on the right of the Chroma submenu bar.
Page 176 Preparations for use S7 / OPMI PROergo Factory settings After the selection of this function, all settings of the selected user can be reset to the factory settings. If you select "Factory Settings" (using the Enter button), the display shows "processing"...
Page 177 S7 / OPMI PROergo Preparations for use Version 9.0 G-30-1435-en Page 177...
Page 178: Relocating The S7 Floor Stand
Preparations for use S7 / OPMI PROergo Relocating the S7 floor stand CAUTION Risk of crushing - mind your fingers! Fingers may be crushed in the areas marked with the "risk of crushing" label. • Do not touch these areas while the system is being moved or brought in its working / transport position.
Page 179 Transport over long distances! Over long distances (e.g. removal, return for repair, etc.) the device must al- ways be transported in the original packaging or in special return packaging. • For details, please contact your dealer or the Carl Zeiss Service. Version 9.0...
Page 180 Preparations for use S7 / OPMI PROergo Version 9.0 Page 180 G-30-1435-en...
Page 181: Operation
S7 / OPMI PROergo Operation Operation Checklist for S7 floor stand ............182 Checklist for S7 ceiling and wall mounts and S7 Centro suspension system............186 Checklist for S7 ceiling mount with lifting column ......190 Procedure ..................194 Working with the SpeedFokus autofocus option........195 Version 9.0...
Page 182: Checklist For S7 Floor Stand
Operation S7 / OPMI PROergo Checklist for S7 floor stand CAUTION Risk of injury! Incorrect configuration settings may lead to unexpected behavior of the de- vice and may cause injury to the patient. • Always check the settings of the selected user profile before using the system.
Page 183 S7 / OPMI PROergo Operation – If operated for 8 hours/day on 5 days/week, the lamp needs to be ex- changed after 12 weeks maximum. Checking the illumination system  Check that the lamp and the backup lamp are intact.
Page 184 Operation S7 / OPMI PROergo Checking the functions of the magnetic brakes • Press release button (1). The magnetic brakes will be active if, in the Surgery/Options/Magnetic Brakes menu: "Brakes" is in the "Off" mode. Checking the functions of the knobs •...
Page 185 S7 / OPMI PROergo Operation Balance setting  Check that the suspension arm has been properly balanced. When fully balanced, the surgical microscope should remain stationary in all positions within the work area and move neither upward nor downward. Limiting downward travel ...
Page 186: Checklist For S7 Ceiling And Wall Mounts And S7 Centro Suspension System
Operation S7 / OPMI PROergo Checklist for S7 ceiling and wall mounts and S7 Centro suspension system CAUTION Risk of injury! Incorrect configuration settings may lead to unexpected behavior of the de- vice and may cause injury to the patient.
Page 187 S7 / OPMI PROergo Operation – If operated for 8 hours/day on 5 days/week, the lamp needs to be ex- changed after 12 weeks maximum. Checking the illumination system  Check that the lamp and the backup lamp are intact.
Page 188 Operation S7 / OPMI PROergo Checking the functions of the magnetic brakes • Press release button (1). The magnetic brakes will be active if, in the Surgery/Options/Magnetic Brakes menu: "Brakes" is in the "Off" mode. Checking the functions of the knobs •...
Page 189 S7 / OPMI PROergo Operation Balance setting  Check that the suspension arm has been properly balanced. When fully balanced, the surgical microscope should remain stationary in all positions within the work area and move neither upward nor downward. Limiting downward travel ...
Page 190: Checklist For S7 Ceiling Mount With Lifting Column
Operation S7 / OPMI PROergo Checklist for S7 ceiling mount with lifting column CAUTION Risk of injury! Incorrect configuration settings may lead to unexpected behavior of the de- vice and may cause injury to the patient. • Always check the settings of the selected user profile before using the system.
Page 191 S7 / OPMI PROergo Operation – If operated for 8 hours/day on 5 days/week, the lamp needs to be ex- changed after 12 weeks maximum. Checking the illumination system  Check that the lamp and the backup lamp are intact.
Page 192 Operation S7 / OPMI PROergo Checking the functions of the magnetic brakes • Press release button (1). The magnetic brakes will be active if, in the Surgery/Options/Magnetic Brakes menu: "Brakes" is in the "Off" mode. Checking the functions of the knobs •...
Page 193 S7 / OPMI PROergo Operation Checking the lifting column • Check the function of the lifting column by operating the selector switch. Balance setting  Check that the suspension arm has been properly balanced. When fully balanced, the surgical microscope should remain stationary in all positions within the work area and move neither upward nor downward.
Page 194: Procedure
Operation S7 / OPMI PROergo Procedure CAUTION Risk of injury caused by xenon light in the facial area Surgery using xenon light in the facial area may seriously harm the patient's eyes. • The patient's eyes must not be exposed to xenon light.
Page 195: Working With The Speedfokus Autofocus Option
S7 / OPMI PROergo Operation Working with the SpeedFokus autofocus option The SpeedFokus autofocus option permits you to select an area of special in- terest to you in the surgical field. SpeedFokus focuses on this selected area at the press of a button. Focusing is triggered on the buttons of the handgrip or foot control panel as configured in the Options menu.
Page 196 Operation S7 / OPMI PROergo Version 9.0 Page 196 G-30-1435-en...
Page 197: What To Do In The Event Of Malfunctions
S7 / OPMI PROergo What to do in the event of malfunctions What to do in the event of malfunctions Failure of main functions ...............199 Failure of the magnetic brakes..............199 Failure of the SpeedFokus autofocus option ..........199 Failure of the motorized focusing function..........200 Failure of the halogen lamp ..............202...
Page 198 What to do in the event of malfunctions S7 / OPMI PROergo Version 9.0 Page 198 G-30-1435-en...
Page 199: Failure Of Main Functions
Failure of the SpeedFokus autofocus option with otherwise correct function of the OPMI PROergo / S7 system: You can continue using your OPMI PROergo / S7 system, but you can no longer benefit from the SpeedFokus autofocus option until it has been re- paired by the service staff.
Page 200: Failure Of The Motorized Focusing Function
What to do in the event of malfunctions S7 / OPMI PROergo Failure of the motorized focusing function Motor running constantly • Bring the suspension arm into its horizontal position and tighten locking knob (4) firmly. • Loosen and remove knurled nut (1).
Page 201 S7 / OPMI PROergo What to do in the event of malfunctions Version 9.0 G-30-1435-en Page 201...
Page 202: Failure Of The Halogen Lamp
What to do in the event of malfunctions S7 / OPMI PROergo Failure of the halogen lamp NOTE Overheating of the lamp module! If ventilation grids are covered e.g. by drapes, this may lead to overheating of the lamp housing and deactivation of the lamp.
Page 203 S7 / OPMI PROergo What to do in the event of malfunctions Version 9.0 G-30-1435-en Page 203...
Page 204: Lamp Failure Of The Xenon Illumination
What to do in the event of malfunctions S7 / OPMI PROergo Lamp failure of the xenon illumination CAUTION Risk of injury caused by lamp rupture! Lamp rupture (audible as a loud bang) may lead to jamming of the lamp module and/or failure of the electronics modules.
Page 205 S7 / OPMI PROergo What to do in the event of malfunctions Version 9.0 G-30-1435-en Page 205...
Page 206 What to do in the event of malfunctions S7 / OPMI PROergo • Reset the service hour counter to “0". Use a pointed object and press it into the recess of reset button (1). • Switch the suspension system back on again at the power switch.
Page 207: Causes Of Malfunctions And Remedies
S7 / OPMI PROergo What to do in the event of malfunctions Causes of malfunctions and remedies For your safety • This system is a high-grade technological product. To ensure optimum performance and safe working order, we recommend having it checked by our service representative as part of regular scheduled maintenance.
Page 208 What to do in the event of malfunctions S7 / OPMI PROergo Problem Possible cause Remedy Surgical microscope tilts for- Surgical microscope not bal- Balance surgical microscope. ward / backward or sideward. anced or incorrectly balanced. Motion of surgical micro-...
Page 209 S7 / OPMI PROergo What to do in the event of malfunctions Problem Possible cause Remedy Insufficient surgical field illu- Brightness level set too low. Adjust brightness on the sus- page 118 mination. pension system's display panel or using the foot con- trol panel.
Page 210 What to do in the event of malfunctions S7 / OPMI PROergo Problem Possible cause Remedy Connecting cable between Properly plug in the cable. CCU and monitor or between CCU and surgical microscope not or not properly plugged Defective connecting cable Change the cable.
Page 211 S7 / OPMI PROergo What to do in the event of malfunctions SpeedFokus video autofocus Problem Possible cause Remedy SpeedFokus video autofocus Camera control unit (CCU) • Switch on MediLive CCU. is inoperative. switched off. Monitor switched off. • Switch on the monitor.
Page 212 What to do in the event of malfunctions S7 / OPMI PROergo Problem Possible cause Remedy Focusing cannot be activated. Different function assigned to • Call up the Handgrip Set- page 120 handgrip button (A, B, C or tings menu and assign the Autofocus function to one of the buttons.
Page 213 S7 / OPMI PROergo Care and Maintenance Care and Maintenance Care of the device................214 Cleaning ....................214 Sterilization .....................215 Disinfection .....................216 System maintenance..............217 Maintenance intervals................217 Safety check ....................218 Replacing the halogen lamp ..............220 Changing the xenon lamp module............222 Spare parts ....................224 Disposal....................225...
Page 214: Care Of The Device
• Remove dust from the optical surfaces using a squeeze blower or a clean, grease-free brush. For the regular cleaning of objective lenses and eyepieces of the surgical mi- croscope, we recommend the optics cleaning set available from Carl Zeiss. For the catalog number, please see the section "Device data". Prevention of fogging To keep the objective lenses from fogging, we recommend using an anti-fog- ging agent.
Page 215: Sterilization
• Make sure that the operating staff is briefed about the sterile operation of the system. The asepsis sets available from Carl Zeiss contain rubber caps and hand grips which can be sterilized in autoclaves. For detailed information on sterilization please see the enclosed instructions "Preparation of resterilizable products"...
Page 216: Disinfection
Care and Maintenance S7 / OPMI PROergo Disinfection NOTE Risk of damaging the paint on the device! • Use a disinfectant based on aldehyde or alcohol. The addition of quater- nary compounds is acceptable. To avoid damaging the surfaces, do not use any disinfecting components other than those specified below.
Page 217: System Maintenance
All maintenance work not detailed here requires system-specific expert know- how. It is frequently necessary to open the system for this work. Please contact your local Carl Zeiss service representative in due time for the performance of these maintenance activities.
Page 218: Safety Check
Care and Maintenance S7 / OPMI PROergo Safety check CAUTION Risk of injury! Cables and plug connections may come loose and parts of the housing may become live. • Make sure that the regular technical safety checks required for this sys- tem in accordance with the applicable national regulations are performed on schedule and to the stipulated extent.
Page 219 S7 / OPMI PROergo Care and Maintenance Version 9.0 G-30-1435-en Page 219...
Page 220: Replacing The Halogen Lamp
Care and Maintenance S7 / OPMI PROergo Replacing the halogen lamp NOTE Risk of burns caused by hot lamp! If you change the lamp shortly after it has failed, the lamp will still be very hot. • Allow the lamp to cool down before changing it.
Page 221 S7 / OPMI PROergo Care and Maintenance Version 9.0 G-30-1435-en Page 221...
Page 222: Changing The Xenon Lamp Module
Care and Maintenance S7 / OPMI PROergo Changing the xenon lamp module CAUTION Risk of injury caused by lamp rupture! Lamp rupture (audible as a loud bang) may lead to jamming of the lamp module and/or failure of the electronics modules.
Page 223 S7 / OPMI PROergo Care and Maintenance • Pack the old lamp module (5) in the transport packaging of the new lamp module. Fill in the enclosed return card and send the old lamp module to the nearest Zeiss service representative.
Page 224: Spare Parts
Care and Maintenance S7 / OPMI PROergo Spare parts Asepsis sets Description Cat. No. Asepsis caps, 27 mm (pack of 6) 305810-9008-000 Asepsis caps, 22 mm (pack of 6) 305810-9001-000 Asepsis caps for 180° tiltable tube (pack of 6) 305810-9003-000...
Page 225: Disposal
S7 / OPMI PROergo Care and Maintenance Disposal User information on the disposal of electrical and electronic devices This symbol means that the product must not be disposed of as normal do- mestic waste. The correct disposal of electrical or electronic devices helps to protect the en-...
Page 226 Care and Maintenance S7 / OPMI PROergo Version 9.0 Page 226 G-30-1435-en...
Page 227 Electromagnetic immunity for ME equipment and ME systems ....245 Electromagnetic immunity for non-life-supporting ME equipment and ME systems..................247 Recommended safety distances between portable and mobile RF communication equipment and the S7 / OPMI PROergo .....249 System combinations..............250 Version 9.0 G-30-1435-en...
Page 228: Technical Data
System Data S7 / OPMI PROergo Technical data Surgical microscope Component Features Magnification Motorized zoom system, zoom ratio 1:6, magnification factor γ = 0.4x - 2.4x. Total magnification 2.4x - 14.6x at a working distance of 200 mm (10x eyepiece) 1.5x - 8.7x at a working distance of 415 mm...
Page 229: Suspension Systems
S7 / OPMI PROergo System Data Suspension systems Electrical data (of all S7 suspension systems) Component Features Power connection Only connect the floor stand to wall outlets which are provided with a properly connected protective ground conductor. Rated voltage 115 V∼ (100...125 V~ ±10%) 230 V~ (220...240 V~ ±10%)
Page 230 System Data S7 / OPMI PROergo S7 floor stand Mechanics Component Features Carrier arm Length: 450 mm Swivel angle: 360° Suspension arm Length: 865 mm Swivel angle: 296° Vertical lift: -320 mm / +400 mm Coupling Swivel angle: 350° Stand height...
Page 231 S7 / OPMI PROergo System Data S7 ceiling mount Mechanics Component Features Carrier arm Length: 450 mm Swivel angle: 296° Suspension arm Length: 865 mm Swivel angle: 296° Vertical lift: -320 mm / +400 mm Coupling Swivel angle: 350° Admissible max. load...
Page 232 System Data S7 / OPMI PROergo S7 ceiling mount with lifting column Mechanics Component Features Carrier arm Length: 450 mm Swivel angle: 296° Suspension arm Length: 865 mm Swivel angle: 296° Vertical lift: -320 mm / +400 mm Coupling Swivel angle: 350°...
Page 233 S7 / OPMI PROergo System Data Technical data of lifting column Rated voltage 24 VDC Current consumption Vertical lift, total 350 mm Lifting force 2000 N Lifting speed 5.5 mm/sec Interval (operation / pause) 1 min / 9 min Version 9.0...
Page 234 System Data S7 / OPMI PROergo S7 wall mount Mechanics Component Features Carrier arm Length: 450mm Swivel angle: 190° Suspension arm Length: 865mm Length: 1065mm Swivel angle: 360° Swivel angle: 360° Vertical lift: +400mm Vertical lift: +540mm -320mm -390mm Coupling Swivel angle: 350°...
Page 235 S7 / OPMI PROergo System Data S7 Centro suspension system Mechanics Component Features Carrier arm Length: 450mm Swivel angle: 190° Suspension arm Length: 1065mm Swivel angle: 360° Vertical lift: +540mm / - 390mm Coupling Swivel angle: 350° Admissible max. load...
Page 236: Integrated 1 Ccd Pal Video Camera (Option)
System Data S7 / OPMI PROergo Integrated 1 CCD PAL video camera (option) Component Features Video focal length 48mm with 1/4 in. CCD image sensor Optical separation 80% observer / 20% camera Image sensor 1/4 in. interline transfer CCD image sensor...
Page 237: Ordering Data
System Data Ordering data Only operate the system with the accessories included in the delivery package and approved by Carl Zeiss. You will find the contact responsible for orders in your country on this website: www.meditec.zeiss.com The product configurations, accessories and spare parts that are applicable for authorized Carl Zeiss partners are stipulated by contract.
Page 238 System Data S7 / OPMI PROergo Eyepieces Description Cat. No. 10x push-in widefield eyepiece 305542-0000-000 12.5x push-in widefield eyepiece, asph. 305543-9901-000 The eyepieces are also available with a focusing aid (1 eyepiece with "format" reticle or with "focusing aid" reticle).
Page 239 S7 / OPMI PROergo System Data Further accessories Description Cat. No. Instrument tray for S7 floor stand 000000-1352-922 Wall socket for S7 ceiling mount 000000-1351-565 Foot control panel for zoom and focus 305946-9200-000 Adapter with double iris diaphragm (for increasing...
Page 240 System Data S7 / OPMI PROergo Video accessories For external video accessories for this surgical microscope, please refer to the separate product overview G-30-1888. Version 9.0 Page 240 G-30-1435-en...
Page 241: Regulatory Information
S7 / OPMI PROergo System Data Regulatory information S7 / OPMI PROergo Electrical safety The medical device complies with the requirements according to – IEC 60601-1:2005, – IEC 601-1:1988+A1:1991+A2:1995, – CAN/CSA-C22.2 No. 601.1-M90. Classification according to level of protection against electrical shock: Protection class 1 Protection rating (acc.
Page 242: Ambient Conditions
System Data S7 / OPMI PROergo Ambient conditions For operation Feature Permissible range Temperature + 10 °C ... + 40 °C Rel. Humidity 30 % ... 75 % Air pressure 700 hPa ... 1060 hPa For transportation and storage Feature...
Page 243: Emc (Electromagnetic Compatibility)
When using the device, the EMC precautions specified below must be ob- served. • Only use spare parts approved by Carl Zeiss for this device. • Do not use any portable or mobile RF communication equipment in the vicinity of the device as this may impair the device's function.
Page 244: Electromagnetic Interference
The S7 / OPMI PROergo is intended for operation in an electromagnetic envi- ronment as specified below. The customer or the user of S7 / OPMI PROergo is responsible for ensuring that the device is operated in such an environment.
Page 245: Electromagnetic Immunity For Me Equipment And Me Systems
System Data Electromagnetic immunity for ME equipment and ME systems The S7 / OPMI PROergo is intended for operation in an electromagnetic envi- ronment as specified below. The customer or the user of the S7 / OPMI PRO- ergo is responsible for ensuring that the device is operated in such an environ- ment.
Page 246 System Data S7 / OPMI PROergo Immunity IEC 60601 - Compliance level Electromagnetic environment - tests test level guidelines NOTE: U is the AC supply voltage prior to application of the test level. Version 9.0 Page 246 G-30-1435-en...
Page 247: Electromagnetic Immunity For Non-Life-Supporting Me Equipment And Me Systems
Electromagnetic immunity for non-life-supporting ME equipment and ME systems The S7 / OPMI PROergo is intended for operation in an electromagnetic envi- ronment as specified below. The customer or the user of the S7 / OPMI PRO- ergo is responsible for ensuring that the device is operated in such an environ- ment.
Page 248 System Data S7 / OPMI PROergo Immunity IEC 60601 - Compliance Electromagnetic environment - tests test level level guidelines Note 2 These guidelines may not apply in all situations. Electromagnetic propagation is influ- enced by absorption and reflection by structures, objects and persons.
Page 249: Recommended Safety Distances Between Portable And Mobile Rf Communication Equipment And The S7 / Opmi Proergo
Recommended safety distances between portable and mobile RF communication equipment and the S7 / OPMI PROergo The S7 / OPMI PROergo is intended for use in an electromagnetic environment in which RF disturbances are controlled. The customer or the user of S7 / OPMI...
Page 250: System Combinations
16.2, the power outlet socket of this system is a multiple connector that is intended for an ME system. Connecting electrical devices not approved by Carl Zeiss can lead to a reduced level of safety on the ME system. When configuring your ME system (use of the power outlet socket), make sure...
Page 251 S7 / OPMI PROergo Index Index Numerics 180° tiltable tube ..................70 Acoustic signals ..................132 Address of manufacturer ................2 Adjusting the eyepieces ................169 Adjusting the interpupillar distance ............169 Adjusting the surgical microscope ............169 Adjusting the system ..............156, 160 Adjusting the system - S7 ceiling, wall mounts and S7 Centro suspension sys- tem ....................158...
Page 252 Index S7 / OPMI PROergo Ceiling anchor ...................15 Ceiling flange ..................84, 90 Ceiling mount with lifting column .............26 Checklist for S7 ceiling mount with lifting column ........190 Checklist for S7 ceiling mount with rigid column ........186 Checklist for S7 Centro suspension system ..........186 Checklist for S7 floor stand ..............182...
Page 253 S7 / OPMI PROergo Index Factory settings ..................176 Failure of magnetic brakes ..............199 Failure of main functions ................199 Field of application ...................10 Filter selector ..................106, 110 First use ....................15 Focal length of objective lens ..............228 Focal lengths ..................228 Focus menu ....................117 Focus start value ..................117...
Page 254 Index S7 / OPMI PROergo Information symbols ...................9 Instrument carrier (option) ................82 Instrument tray, strap provided ..............82 Intended use .....................10 Intensity start value .................118 Key to symbols ...................9 KK 40 filter ..................23, 106 Labels on S7 wall mount and on S7 Centro suspension system ....46 Lamp failure ..................202, 204...
Page 255 S7 / OPMI PROergo Index Opening for system cable .............80, 88, 96, 102 Opening the lamp module ..............106, 110 Optical surfaces, cleaning ...............214 Option, video autofocus .................123 Options button ..................119 Options menu ..........119, 121, 126, 128, 131, 132 Orange filter .....................66 Ordering data ..................237...
Page 256 Index S7 / OPMI PROergo Signal-to-noise ratio ................236 SIP label ..................36, 42, 48 Spare parts .....................224 Speed .....................117 Speed setting ..................116 Stand base ..................74, 78 Stand column ................74, 78, 84 Standard configuration of foot control panel with 14 functions ....136 Standard configuration of foot control panel with 8 functions ....137...
Page 257 S7 / OPMI PROergo Index Video autofocus ..................123 Video autofocus, working with ...............195 Video camera (CCD position), orientation of ...........124 Video camera configuration ..............172 Video camera, 1 CCD PAL mono and stereo (technical data) ....236 Video camera, external ............123, 124, 125 Video camera, integrated ...............120...
Page 258 Index S7 / OPMI PROergo Version 9.0 Page 258 G-30-1435-en...
Page 259 S7 / OPMI PROergo (Blank page, for your notes . . .) Version 9.0 G-30-1435-en Page 259...
Page 260 Carl Zeiss Meditec AG Fax: + 49 (0)7364 - 20 4823 Goeschwitzer Strasse 51-52 Email: surgical@meditec.zeiss.com 07745 Jena Internet: www.meditec.zeiss.com Germany...
