D330E Series
USER MANUAL/About This Machine
Before using this Product, please read the
USER MANUAL carefully and keep it for
your reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the D330E Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sindoh D330E Series

Summary of Contents for Sindoh D330E Series

  • Page 1 D330E Series USER MANUAL/About This Machine Before using this Product, please read the USER MANUAL carefully and keep it for your reference.

  • Page 2: Table Of Contents

    Table of contents Name and Function of Each Part in Main Unit Front..............................1-2 Side/rear..............................1-3 Inside..............................1-4 Checking the Machine Status Using Indicator LEDs Name and Function of Each Indicator LED .................. 2-2 Warning Indicator..........................2-3 Data Indicator..........................2-4 Name and Function of Each Optional Component Optional Components........................
  • Page 3 Upgrade Kit UK-221 .........................6-13 [About This Machine]...

  • Page 4: Name And Function Of Each Part In Main Unit

    Name and Function of Each Part in Main Unit...

  • Page 5: Front

    Name and Function of Each Part in Main Unit Front This illustration shows the main unit with Reverse Automatic Document Feeder DF-633. Name Description Reverse Automatic Automatically feeds and scans originals by page. This unit also revers- Document Feeder es and automatically scans 2-sided originals. This unit is referred to as ADF in the manual.

  • Page 6: Side/Rear

    Name Description Right Door Release Used to lock the Right Door. Lever Main Power Switch Press this switch to turn the machine on or off. Tray 1, Tray 2 Allows you to load up to 500 sheets of plain paper. For details on the available paper, refer to "User's Guide[Introduc- tion]/[Loading Paper]".

  • Page 7: Inside

    Name Description Network Connector Connect to this port when using this machine as a network printer or (10Base-T/100Base- network scanner. TX/1000Base-T) Tips The network port of this product is following No.2 and No.3. A port is activated when a network port inserts a cable.
  • Page 8 Name Description Lock Release Tab Used to remove the Drum Unit. (Black only) Waste Toner Box Used to collect used waste toners. Printhead Cleaner Used to clean the surface of the Print Head Glass. Toner Cartridge This machine provides Toner Cartridge in four colors: cyan (C), ma- genta (M), yellow (Y), and black (K).
  • Page 9 [About This Machine]...

  • Page 10: Checking The Machine Status Using Indicator Leds

    Checking the Machine Status Using Indicator LEDs...

  • Page 11: Name And Function Of Each Indicator Led

    Name and Function of Each Indicator LED Checking the Machine Status Using Indicator LEDs Name and Function of Each Indicator LED Name Description Data Indicator Flashes or lights up to indicate the data receiving status on this ma- chine. For details, refer to page 2-4. Warning Indicator Flashes or lights up to indicate that a problem has occurred in this ma- chine.

  • Page 12: Warning Indicator

    Warning Indicator Warning Indicator Flashes or lights up to indicate that a problem has occurred in this machine. Status of LED Status of this machine Flash (orange) Indicates that a warning has occurred in this machine. Light-up (orange) Indicates that this machine is stopped due to an error. [About This Machine]...

  • Page 13: Data Indicator

    Data Indicator Data Indicator Flashes or lights up to indicate the data receiving status on this machine. Status of LED Status of this machine Flash (blue) Indicates that print data is currently being received. Light-up (blue) Indicates that data is currently being stored. [About This Machine]...

  • Page 14: Name And Function Of Each Optional Component

    Name and Function of Each Optional Component...

  • Page 15: Optional Components

    Optional Components Name and Function of Each Optional Component Optional Components List of optional components 17 18 Name Description Main unit Scans the original in the scanner section, and prints a scanned image in the printer section. This unit is referred to as "this machine" or "the main unit" in the man- ual.
  • Page 16 Optional Components Name Description Reverse Automatic Automatically feeds and scans originals by page. This unit also revers- Document Feeder DF- es and automatically scans 2-sided originals. This unit is referred to as ADF in the manual. FAX Kit FK-513 Used to operate this machine as a fax machine. When you use this machine as a fax machine, the optional Expanded Memory Unit must also be installed in this machine.

  • Page 17: List Of Other Optional Components

    Optional Components Name Description Punch Kit PK-519 Install this unit onto the Finisher FS-533. This unit supports the punching function. Job Separator JS-506 Install this unit onto the output tray of this machine. This unit sorts printed sheets. The Mount Kit MK-603 is required to install Job Separator JS-506. Mount Kit MK-603 This unit is required to install the Finisher FS-539/FS-539 SD/FS-533 or Job Separator JS-506 on this machine.

  • Page 18: Front

    Optional Components Name Description Power Supply BOX Used to turn on or off the operation of Heater HT-509 for paper feed MK-734 cabinet. The Power Supply BOX MK-734 can be mounted when you pur- chase the Paper Feed Cabinet PC-118, PC-218, or PC-418 or Desk DK-518.

  • Page 19: Side/Rear

    Optional Components Name Description Tray 4/Storage Box Used as a Storage Box when installing Single Paper Feed Cabinet. This box allows you to load up to 500 sheets of plain paper when Dou- ble Paper Feed Cabinet is installed. For details on the available paper, refer to "User's Guide[Introduc- tion]/[Loading Paper]".

  • Page 20: Finisher Fs-539/Fs-539 Sd/Punch Kit Pk-524

    Finisher FS-539/FS-539 SD/Punch Kit PK-524 Finisher FS-539/FS-539 SD/Punch Kit PK-524 [About This Machine]...
  • Page 21 Finisher FS-539/FS-539 SD/Punch Kit PK-524 Name Description Output Tray2 Outputs printed pages. Output Tray1 Outputs printed pages. Front Door Open this door when clearing a paper jam or staple jam or when re- placing a staple cartridge. Horizontal Transport Outputs printed pages. Unit Cover Open this cover when removing paper that caused a paper jam in the horizontal transport unit.
  • Page 22 Finisher FS-539/FS-539 SD/Punch Kit PK-524 Name Description Jam Removal Dial Turn this dial to remove paper that caused a paper jam in the finisher. [SD3] Handle [SD1] Hold this handle when moving the Saddle Stitcher in and out. Manual Staple Used to manually staple printed sheets at the corner.

  • Page 23: Finisher Fs-533/Punch Kit Pk-519

    Finisher FS-533/Punch Kit PK-519 Finisher FS-533/Punch Kit PK-519 Name Description Jam Removal Dial Turn this dial to remove paper that caused a paper jam in the finisher. [FS1] Punch Kit Release Le- Used to open the punch kit when removing a punch scrap box. ver [FS2] Punch Kit You can punch printed sheets for filing by installing the Punch Kit in...

  • Page 24: Job Separator Js-506

    Job Separator JS-506 Job Separator JS-506 Name Description Output Tray1 Collects printed pages. Output Tray2 Collects printed pages. [About This Machine] 3-11...

  • Page 25: Using Manual Staple

    Using Manual Staple Using Manual Staple Using the manual staple function installed in the Finisher allows you to manually staple printed sheets at the corner (45 degrees). This function is useful when you want to staple the printed sheets later without setting the staple function.

  • Page 26: List Of Functions With Options Required

    List of Functions with Options Required...

  • Page 27: Copy Options

    List of Functions with Options Required Copy options Function Required option Half-Fold Finisher FS-539 SD Center Staple & Fold Tri-Fold Punch One of the following combinations is required. • Finisher FS-539 and Punch Kit PK-524 • Finisher FS-539 SD and Punch Kit PK-524 •...

  • Page 28: Scan Options

    Scan options Function Required option DOCX/XLSX conver- Expanded Memory Unit and i-Option LK-110 sion and OCR charac- ter recognition PDF encryption by digi- One of the following combinations is required. tal ID • Expanded Memory Unit and i-Option LK-102 • Expanded Memory Unit and i-Option LK-110 PDF File Properties One of the following combinations is required.

  • Page 29: Guidance, Font, Security, And Maintenance Options

    Function Required option User Box administrator Expanded Memory Unit User Box Document Expanded Memory Unit Backup User Box Expanded Memory Unit Guidance, font, security, and maintenance options Function Required option Voice guidance Expanded Memory Unit, i-Option LK-104, and Local Interface Kit Bar code font i-Option LK-106 Unicode font...
  • Page 30 Function Required option Link with fax server Expanded Memory Unit Connection to applica- Expanded Memory Unit tion [About This Machine]...
  • Page 31 [About This Machine]...

  • Page 32: Specifications Of This Machine

    Specifications of this Machine...

  • Page 33: Main Unit

    Specifications of this Machine Main unit Item Specifications D332 Name bizhub C287i D330 bizhub C227i Type Desktop 600 dpi e 600 dpi Scanning resolution 1800 dpi or equivalent e 600 dpi Writing resolution Gradation Memory size 6 GB Storage size 256 GB Originals Sheets, books, objects (Max.

  • Page 34: Scanning Function Specifications

    Item Specifications Copy magnification < Fixed same magnification > Full size 1 : 1^0.5% or less Enlarge Inch area 1: 1.214/1.294/1.545/2.000 Metric area 1: 1.154/1.224/1.414/2.000 Reduce Inch area 1: 0.785/0.733/0.647/0.500 Metric area 1: 0.866/0.816/0.707/0.500 < Preset > 3 types < Zoom > 25% to 400% (in 0.1% increments) <...

  • Page 35: Printer Specifications

    Printer specifications Item Specifications Type Embedded Paper size Conforms to the main unit specifications. Print speed Conforms to the main unit specifications. Resolution 1800 dpi (equivalent) e 600 dpi (at smoothing) Page description lan- PCL5e/c Emulation guage PCL6 (XL ver. 3.0) Emulation PostScript 3 Emulation (3016) Fonts <...

  • Page 36: Specifications Of Optional Components

    Specifications of Optional Components...

  • Page 37: Fax Kit Fk-513

    Specifications of Optional Components FAX Kit FK-513 Item Specifications Communication Super G3 Applicable lines Subscribed telephone lines (including facsimile communication networks) PBX lines Line density Ultra Fine: 600 dpi e 600 dpi Super Fine: 16 dot/mm e 15.4 line/mm, 400 dpi e 400 dpi Fine: 8 dot/mm e 7.7 line/mm, 200 dpi e 200 dpi Normal:...

  • Page 38: Paper Feed Cabinet Pc-118

    Item Specifications When copying (B & W, Letter (8-1/2 e 11 v) or A4 v, resolution 600 dpi) Scanning speed 1-sided original: 30 sheets/min. 2-sided original: 14 sides/min. When scanning (B & W/Color, Letter (8-1/2 e 11 v) or A4 v, resolution 300 dpi) 1-sided original: 55 sheets/min.
  • Page 39 Item Specifications Paper capacity Plain paper: 2500 sheets (21-1/4 lb (80 g/m Thick: 1000 sheets Power supply Supply from machine Max. power consump- 15 W or less tion Dimensions ([W] e [D] e 22-3/16 inches (564 mm) e 25-3/16 inches (640 mm) e 10 inches (254 mm) [H]) Weight Approx.
  • Page 40 Item Specifications Stacking ca- Sort/Group Thin paper, Plain paper, Plain paper+ 8-1/2 e 11, 7-1/4 e 10-1/2, A4, B5: 3000 sheets pacity • (Output Tray2) • 5-1/2 e 8-1/2 or smaller, A5 or smaller: 500 sheets Thick, Transparency, Envelope, Label sheet, Letterhead: 20 sheets * Paper cannot be stacked higher than the following height regard- less of the number of sheets in the stack.

  • Page 41: Finisher Fs-539 Sd

    Item Specifications Manual staple mode Number of stapled sheets: Max. 50 sheets (23-15/16 lb (90 g/m Staple position: Corner 45° Paper detection: Provided Height of paper insertion slit: 3/16 inches (5.5 mm) (Paper butting part) Available options Punch Kit PK-524 Power supply Supply from machine Consumables...
  • Page 42 Item Specifications Stacking ca- Sort/Group Thin paper, Plain paper, Plain paper+ 8-1/2 e 11, 7-1/4 e 10-1/2, A4, B5: 2000 sheets pacity • (Output Tray2) • 8-1/2 e 14 or larger, B4 or larger: 1500 sheets 5-1/2 e 8-1/2 or smaller, A5 or smaller: 500 sheets •...
  • Page 43 Item Specifications Manual staple mode Number of stapled sheets: Max. 50 sheets (23-15/16 lb (90 g/m Staple position: Corner 45° Paper detection: Provided Height of paper insertion slit: 3/16 inches (5.5 mm) (Paper butting part) Saddle stitcher mode Center Staple, Half-Fold, Tri-Fold Center staple paper size •...

  • Page 44: Punch Kit Pk-524

    Item Specifications Dimensions ([W] e [D] e [H]) 21-3/8 inches (543 mm) e 26-13/16 inches (681 mm) e 40-1/4 inches (1023 mm) With trays pulled out: 25-7/8 inches (658 mm) e 26-13/16 inches (681 mm) e 41-15/16 inches (1065 mm) Weight Approx.

  • Page 45: Punch Kit Pk-519

    Item Specifications Stacking ca- Group/Sort, Thin paper, Plain paper 8-1/2 e 11, 7-1/4 e 10-1/2, A4, B5: 500 sheets pacity (Output Offset • Tray1) Group/Offset • 8-1/2 e 14 or larger, B4 or larger: 250 sheets Sort Thick: 10 sheets * Paper cannot be stacked higher than the following height regard- less of the number of sheets in the stack.

  • Page 46: Authentication Unit Au-102

    Item Specifications Paper type Thin paper (13-13/16 lb to 15-11/16 lb (52 g/m to 59 g/m )), Plain paper (15-15/16 lb to 27-15/16 lb (60 g/m to 105 g/m )), Thick (28- 3/16 lb to 79-13/16 lb (106 g/m to 300 g/m )), Transparency, Post- card (4 e 6 (A6 Card)), Envelope, Label sheets, Letterhead, Index pa- per, Banner paper...

  • Page 47: Authentication Unit Au-201S

    Item Specifications Compatible Computer PC-AT compatible machine computer Conforms to the recommended operating environment of your oper- ating system. Memory (RAM) Conforms to the recommended operating environment of your oper- ating system. Storage space 600 MB or more Monitor 800 e 600 pixels or more Network TCP/IP settings must be configured correctly.
  • Page 48 Upgrade Kit UK-221 Item Specifications Compliance Standards IEEE802.11b/IEEE802.11g/IEEE802.11n/IEEE802.11a/IEEE802.11ac Transmission Scheme DS-SS Scheme/OFDM Scheme 2.4 GHz frequency 2.412 GHz to 2.472 GHz (Based on Radio Law of each country) range 5 GHz frequency range 5.180 GHz to 5.825 GHz (Based on Radio Law of each country) 2.4 GHz channel 1 ch to 13 ch (Based on Radio Law of each country) 5 GHz channel...
  • Page 49 [About This Machine] 6-14...

  • Page 50: Notice To Users

    Notice to users Type Notice This class A product is registered in Electromagnetic Compatibility, and Class A items (Broadcast communications User may be required to take adequate unit for business use) measures for other purposes than household use. This class B product is registered in Class B items Electromagnetic compatibility and is (Broadcast communications...
