C300
USER MANUAL
Read the User Manual before operating the product,
and keep the manual at a convenient place near the
product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sindoh C300

Summary of Contents for Sindoh C300

  • Page 1 C300 USER MANUAL Read the User Manual before operating the product, and keep the manual at a convenient place near the product.
  • Page 2 Cautions for User Safety Please follow the below guidelines when using the device. Warning : Failure to follow the instructions may lead to death or serious injury. Plug the power cord directly into the outlet on wall. Do not use an extension cord. If the power cable or plug is worn or damaged, unplug the power plug by pulling it out.
  • Page 3 Before Use Thank you for purchasing our product. This user manual is intended for first-time user of this MFP as well as MFP administrators. This manual explains functions and operation procedures of MFP, user tips and important warnings, maintenance tips, and simple troubleshootings. Read this manual carefully to fully and effectively use the device.

  • Page 4: Table Of Contents

    Contents Chapter Safety information Conventions-------------------------------------------------------------------------------------------------------------- 1-2 Product statements --------------------------------------------------------------------------------------------------- 1-2 Chapter Learning about the printer Finding information about the printer ----------------------------------------------------------------------------- 2-2 Printer configurations ------------------------------------------------------------------------------------------------- 2-3 Using the control panel ---------------------------------------------------------------------------------------------- 2-4 Customizing the home screen -------------------------------------------------------------------------------------- 2-4 Changing the language of the keyboard on the display ----------------------------------------------------- 2-4 Understanding the status of the indicator light ----------------------------------------------------------------- 2-5 Selecting paper -------------------------------------------------------------------------------------------------------- 2-5 Chapter 3.
  • Page 5 Supported flash drives and file types ----------------------------------------------------------------------------- 5-4 Configuring confidential jobs ---------------------------------------------------------------------------------------- 5-4 Printing confidential and other held jobs ------------------------------------------------------------------------- 5-5 Printing from a Cloud Connector profile ------------------------------------------------------------------------- 5-6 Printing a font sample list -------------------------------------------------------------------------------------------- 5-6 Placing separator sheets between copies ----------------------------------------------------------------------- 5-6 Canceling a print job -------------------------------------------------------------------------------------------------- 5-7 Adjusting toner darkness -------------------------------------------------------------------------------------------- 5-7 Chapter 6.
  • Page 6 Blocking junk faxes ---------------------------------------------------------------------------------------------------- 8-4 Holding a fax ------------------------------------------------------------------------------------------------------------ 8-4 Forwarding a fax ------------------------------------------------------------------------------------------------------- 8-4 Chapter 9. Scan Using the automatic document feeder and scanner glass -------------------------------------------------- 9-2 Scanning to an FTP server ------------------------------------------------------------------------------------------ 9-2 Scanning to an FTP server using a shortcut -------------------------------------------------------------------- 9-2 Creating a network folder shortcut -------------------------------------------------------------------------------- 9-3 Scanning to a network folder using a shortcut ----------------------------------------------------------------- 9-3 Scanning to a flash drive -------------------------------------------------------------------------------------------- 9-3...
  • Page 7 Media Configuration ----------------------------------------------------------------------------------------------- 10-18 Universal Setup ----------------------------------------------------------------------------------------------------- 10-18 Custom Scan Sizes ------------------------------------------------------------------------------------------------ 10-19 Media Types --------------------------------------------------------------------------------------------------------- 10-19 Copy ------------------------------------------------------------------------------------------------------------------- 10-20 Copy Defaults -------------------------------------------------------------------------------------------------------- 10-20 Fax --------------------------------------------------------------------------------------------------------------------- 10-22 Fax Defaults ---------------------------------------------------------------------------------------------------------- 10-22 Fax Mode ------------------------------------------------------------------------------------------------------------- 10-22 Fax Setup ------------------------------------------------------------------------------------------------------------- 10-22 E-mail ----------------------------------------------------------------------------------------------------------------- 10-28 E-mail Setup --------------------------------------------------------------------------------------------------------- 10-28 E-mail Defaults ------------------------------------------------------------------------------------------------------ 10-28 Advanced Imaging ------------------------------------------------------------------------------------------------- 10-30...
  • Page 8 Unable to read flash drive ----------------------------------------------------------------------------------------12-3 Enabling the USB port ---------------------------------------------------------------------------------------------12-4 Network connection problems ----------------------------------------------------------------------------------12-5 Cannot open Embedded Web Server ---------------------------------------------------------------------------12-5 Issues with supplies -----------------------------------------------------------------------------------------------12-6 Replace cartridge, printer region mismatch -------------------------------------------------------------------12-6 Printer and print cartridge regions -------------------------------------------------------------------------------12-6 Non-Sindoh supply ---------------------------------------------------------------------------------------------------12-6...
  • Page 9 Scanner maintenance required, use ADF Kit ------------------------------------------------------------------12-6 Clearing jams ---------------------------------------------------------------------------------------------------------12-8 Avoiding jams ----------------------------------------------------------------------------------------------------------12-8 Load paper properly -------------------------------------------------------------------------------------------------12-8 Use recommended paper ------------------------------------------------------------------------------------------12-8 Identifying jam locations --------------------------------------------------------------------------------------------12-9 Paper jam in the standard tray ---------------------------------------------------------------------------------- 12-10 Paper jam in the standard tray ---------------------------------------------------------------------------------- 12-11 Paper jam in the standard bin ----------------------------------------------------------------------------------- 12-13 Paper jam in the manual feeder -------------------------------------------------------------------------------- 12-13 Paper jam in door B ------------------------------------------------------------------------------------------------ 12-14...
  • Page 10 11.2 Partial copies of document or photo --------------------------------------------------------------------------- 12-49 11.3 Scan job was not successful ------------------------------------------------------------------------------------- 12-49 11.4 Poor copy quality --------------------------------------------------------------------------------------------------- 12-50 11.5 Vertical dark streaks on output when scanning from the ADF ------------------------------------------- 12-50 11.6 Scanner does not close ------------------------------------------------------------------------------------------- 12-51 11.7 Scanning takes too long or freezes the computer ---------------------------------------------------------- 12-51 11.8...

  • Page 11: Safety Information

    C300 User’s Guide Safety information...

  • Page 12: Conventions

    Safety information Conventions Note - A note identifies information that could help you. Warning - A warning identifies something that could damage the product hardware or software. Caution - A caution indicates a potentially hazardous situation that could injure you. Different types of caution statements include: CAUTION : POTENTIAL INJURY Indicates a risk of injury.
  • Page 13 Safety information CAUTION : POTENTIAL INJURY Do not cut, twist, bind, crush, or place heavy objects on the power cord. Do not subject the power cord to abrasion or stress. Do not pinch the power cord between objects such as furniture and walls. If any of these things happen, a risk of fire or electrical shock results. Inspect the power cord regularly for signs of such problems.
  • Page 14 Safety information CAUTION : TIPPING HAZARD To reduce the risk of equipment instability, load each tray separately. Keep all other trays closed until needed. CAUTION HOT SURFACE The inside of the printer might be hot. To reduce the risk of injury from a hot com ponent, allow the surface to cool before touching it.

  • Page 15: Learning About The Printer

    C300 User’s Guide Learn about the printer...

  • Page 16: Finding Information About The Printer

    Learn about the printer Finding information about the printer What are you looking for? Find it here Initial setup instructions: See the setup documentation that came with the printer - Connecting the printer - Installing the printer software More setup and instructions for using the printer: - Selecting and storing paper and specialty media - Loading paper - Configuring printer settings...

  • Page 17: Printer Configurations

    Learn about the printer Printer configurations C300 Automatic document feeder (ADF) ADF tray ADF bin Standard bin Manual feeder Standard 250-sheet tray Optional 250-sheet trays Note - This option is supported only in some printer models. Control panel...

  • Page 18: Using The Control Panel

    Learn about the printer Using the control panel Control panel part Function Power button Turn on or turn off the printer. Note - To turn off the printer, press and hold the power button for five seconds. Home button Go to the home screen. Back button Return to the previous screen.

  • Page 19: Understanding The Status Of The Indicator Light

    Learn about the printer Understanding the status of the indicator light Indicator light Printer status The printer is off. Blue The printer is on or ready. Blinking blue The printer is processing data. Blinking red The printer requires user intervention. PAmber The printer is in Sleep mode.
  • Page 20 Learn about the printer Fiber content Most high-quality xerographic paper is made from 100 percent chemically treated pulped wood. This content provides the paper with a high degree of stability, resulting in fewer paper feeding problems and better print quality. Paper containing fibers such as cotton can negatively affect paper handling.
  • Page 21 Learn about the printer Supported paper sizes Standard or Manual Two-sided Scanner Paper size optional feeder printing glass 250-sheet tray 210 x 297 mm (8.27 x 11.7 in.) × 148 x 210 mm (5.83 x 8.27 in.) × 105 x 148 mm (4.13 x 5.83 in.) JIS B5 ×...
  • Page 22 Learn about the printer Standard or Manual Two-sided Scanner Paper size optional feeder printing glass 250-sheet tray 10 Envelope × × 104.8 x 241.3 mm (4.12 x 9.5 in.) DL Envelope × × 110 x 220 mm (4.33 x 8.66 in.) C5 Envelope ×...
  • Page 23 Learn about the printer Standard or optional Paper type and weight Manual feeder Two-sided printing 250-sheet tray Plain paper 75–90.3 g/m grain long (20–24-lb bond) Heavy paper 90.3–100 g/m grain long (24.1–26-lb bond) Card stock 105.1–162 g/m grain long × (28.1–43-lb bond) Card stock 105.1–200 g/m...

  • Page 25: Chapter 3. Set Up, Install, And Configure

    C300 User’s Guide Set up, install, and configure...

  • Page 26: Selecting A Location For The Printer

    Set up, install, and configure Selecting a location for the printer - Leave enough room to open trays, covers, and doors and to install hardware options. - Set up the printer near an electrical outlet. CAUTION : POTENTIAL INJURY To avoid the risk of fire or electrical shock, connect the power cord to an appropriately rated and properly grounded electrical outlet that is near the product and easily accessible.

  • Page 27: Attaching Cables

    Set up, install, and configure Attaching cables CAUTION : SHOCK HAZARD To avoid the risk of electrical shock, do not set up this product or make any electrical or cabling connections, such as the power cord, fax feature, or telephone, during a lightning storm. CAUTION : POTENTIAL INJURY To avoid the risk of fire or electrical shock, connect the power cord to an appropriately rated and properly grounded electrical outlet that is near the product and easily accessible.

  • Page 28: Setting Up And Using The Home Screen Applications

    Set up, install, and configure Turn off the printer. Unplug the power cord from the electrical outlet, and then from the printer. Unpack the optional tray, and then remove all packing material. Align the printer with the optional tray, and then lower the printer into place. CAUTION : POTENTIAL INJURY lf the printer weight is greater than 20 kg (44 lb), then it may require two or more people to lift it safely.
  • Page 29 Set up, install, and configure Open a web browser, and then go to https://Sindoh.cloud-connect.co. Click Next, and then accept the Terms of Use. Enter the authorization code, and then click Connect. Log in to your cloud service provider account. Grant permissions. Note - To complete the authorization process, open the profile within 72 hours.

  • Page 30: Setting Up The Printer To Fax

    Set up, install, and configure Creating folders ❖ Open a web browser, and then type the printer IP address in the address field. Note - View the printer IP address on the printer home screen. The IP address appears as four sets of numbers separated by periods, such as 123.123.123.123. - If you are using a proxy server, then temporarily disable it to load the web page correctly. Click Bookmarks → Add Folder, and then type a folder name. Note - To limit access to the folder, enter a PIN. Click Save.
  • Page 31 Set up, install, and configure Using the Embedded Web Server ❖ Open a web browser, and then type the printer IP address in the address field. Settings → Device → Preferences → Run Initial Setup Note - View the printer IP address on the home screen. The IP address appears as four sets of numbers separated by periods, such as 123.123.123.123. - If you are using a proxy server, then temporarily disable it to load the web page correctly. Click Settings → Fax → Fax Setup → General Fax Settings. Configure the settings. Apply the changes.
  • Page 32 Set up, install, and configure Setup 2: Printer is sharing the line with an answering machine ❖ Note - If you subscribe to a distinctive ring service, then make sure that you set the correct ring pattern for the printer. Otherwise, the printer does not receive faxes even if you have set it to receive faxes automatically.
  • Page 33 Set up, install, and configure Connecting the printer to a non‑RJ11 wall jack ❖ Connect one end of the telephone cable to the line port of the printer. Connect the other end of the cable to the RJ11 adapter, and then connect the adapter to the wall jack. If you want to connect another device with a non-RJ11 connector to the same wall jack, then connect it directly to the telephone adapter.

  • Page 34: Loading Paper And Specialty Media

    Set up, install, and configure Connect the other end of the cable to the RJ11 adapter, and then connect the adapter to an N port. If you want to connect a telephone and answering machine to the same wall jack, then connect the devices as shown.
  • Page 35 Set up, install, and configure Loading trays CAUTION : TIPPING HAZARD To reduce the risk of equipment instability, load each tray separately. Keep all other trays closed until needed. Remove the tray. Note - To avoid paper jams, do not remove trays while the printer is busy. Flex, fan, and align the paper edges before loading. Load the paper stack with the printable side faceup.
  • Page 36 Set up, install, and configure Note - Load letterhead faceup with the header toward the back of the tray for one-sided printing. - Load letterhead facedown with the header toward the front of the tray for two-sided printing. - Do not slide paper into the tray. - To avoid paper jams, make sure that the stack height is below the maximum paper fill indicator.
  • Page 37 Set up, install, and configure Loading the manual feeder Adjust the guide to match the size of the paper that you are loading. Load a sheet of paper with the printable side faceup. - Load letterhead with the printable side faceup and the top edge entering the printer first for one-sided printing. - Load letterhead with the printable side facedown and the top edge entering the printer last for two-sided printing.

  • Page 38: Installing And Updating Software, Drivers, And Firmware

    Set up, install, and configure - Load envelope with the flap side down and against the right side of the paper guide. Feed the paper until its leading edge gets pulled in. Note - To avoid paper jams, do not force paper into the manual feeder. - Before loading another sheet, wait for a message to appear on the display. Linking trays From the home screen, touch Settings → Paper → Tray Configuration → select a paper source.
  • Page 39 Set up, install, and configure Updating firmware Some applications require a minimum device firmware level to operate correctly. For more information on updating the device firmware, contact your representative. Open a web browser, and then type the printer IP address in the address field. Note - View the printer IP address on the printer home screen. The IP address appears as four sets of numbers separated by periods, such as 123.123.123.123. - If you are using a proxy server, then temporarily disable it to load the web page correctly. Click Settings → Device → Update Firmware. Browse to the flash file. Click Upload.

  • Page 40: Networking

    Set up, install, and configure Networking Installing the wireless print server Turn off the printer. Install the adapter. On the Fax setup screen, configure the settings.
  • Page 41 Connecting the printer to a Wi‑Fi network Make sure that Active Adapter is set to Auto. From the home screen, touch Settings → Network/Ports → Network Overview → Active Adapter. Using the control panel ❖ From the home screen, touch Settings → Network/Ports → Wireless → Setup On Printer Panel → Choose Network. Select a Wi-Fi network, and then type the network password. Note - For Wi-Fi-network-ready printer models, a prompt to set up the Wi-Fi network appears during initial setup. Using Sindoh Mobile Assistant ❖ Depending on your mobile device, download the Mobile Assistant application from either the Google Play store or App Store online store. From the printer home screen, touch Settings → Network/Ports → Wireless → Setup Using Mobile App → Printer ID. From your mobile device, launch the application, and then accept the Terms of Use. Note - If necessary, grant permissions.
  • Page 42 Set up, install, and configure Using the personal identification number (PIN) method ❖ From the home screen, touch Settings → Network/Ports → Wireless → Wi-Fi Protected Setup → Start PIN Method. Copy the eight-digit WPS PIN. Open a web browser, and then type the IP address of your access point in the address field. Note - To know the IP address, see the documentation that came with your access point.

  • Page 43: Printing The Menu Settings Page

    Set up, install, and configure Note - You can change the SSID on the control panel. Navigate to: Settings → Network/Ports → Wi-Fi Direct → SSID. - You can also change the PSK on the control panel. Navigate to: Settings → Network/Ports → Wi-Fi Direct → Set PSK. Deactivating the Wi‑Fi network From the home screen, touch Settings → Network/Ports → Network Overview → Active Adapter → Standard Network. Follow the instructions on the display. Checking the printer connectivity From the home screen, touch Settings → Reports → Network → Network Setup Page. Check the first section of the page and confirm that the status is connected. If the status is not connected, then the LAN drop may be inactive or the network cable may be unplugged or malfunctioning.

  • Page 45: Chapter 4. Secure The Printer

    C300 User’s Guide Secure the printer...

  • Page 46: Erasing Printer Memory

    Secure the printer Erasing printer memory To erase volatile memory or buffered data, turn off the printer. To erase non‑volatile memory or individual settings, device and network settings, security settings, and embedded solutions, do the following: From the home screen, touch Settings → Device → Maintenance → Out of Service Erase. Select the Sanitize all information on nonvolatile memory check box, and then touch OK. Select either Start initial setup or Leave printer offline, and then touch OK. Restoring factory default settings From the home screen, touch Settings → Device → Restore Factory Defaults.

  • Page 47: Chapter 5. Print

    C300 User’s Guide Print...

  • Page 48: Aprinting From A Computer

    Print Printing from a computer Note - For labels, card stock, and envelopes, set the paper size and type in the printer before printing the document. From the document that you are trying to print, open the Print dialog. If necessary, adjust the settings. Print the document.

  • Page 49: Printing From A Flash Drive

    Print Select a printer, and then adjust the settings, if necessary. Print the document. ® Printing from a mobile device using Wi‑Fi Direct Wi-Fi Direct is a printing service that lets you print to any Wi-Fi Direct-ready printer. Note - Make sure that the mobile device is connected to the printer wireless network. For more information, see “Connecting a mobile device to the printer”...

  • Page 50: Supported Flash Drives And File Types

    Print Warning Potential Damage: ‑ To avoid loss of data or printer malfunction, do not touch the flash drive or the printer in the area shown while actively printing, reading, or writing from the memory device. Supported flash drives and file types Flash drives - Lexar JumpDrive S70 (16GB and 32GB) - SanDisk Cruzer (16GB and 32GB)

  • Page 51: Printing Confidential And Other Held Jobs

    Print Max Invalid PIN Set the number of times an invalid PIN can be entered. Note - When the limit is reached, the print jobs for that user name are deleted. Confidential Job Expiration Set the expiration time for confidential print jobs. Note - Confidential held jobs are stored in the printer until they are released or deleted manually.

  • Page 52: Printing From A Cloud Connector Profile

    Print For Macintosh users With a document open, choose File > Print. If necessary, click the disclosure triangle to see more options. From the print options or Copies & Pages menu, choose Job Routing. Select the print job type (Confidential, Repeat, Reserve, or Verify). If the print job is confidential, then assign a user name and a four-digit PIN.

  • Page 53: Canceling A Print Job

    Print Canceling a print job From the printer control panel From the home screen, touch Cancel a job. Select a job to cancel. From the computer Depending on the operating system, do either of the following: - Open the printers folder, and then select your printer. - From the System Preferences in the Apple menu, navigate to your printer.

  • Page 55: Chapter 6. Copy

    C300 User’s Guide Copy...

  • Page 56: Using The Automatic Document Feeder And Scanner Glass

    Copy Using the automatic document feeder and scanner glass Correct loading of paper Incorrect loading of paper - Use the ADF for multiple-page or two-sided documents. - Load an original document faceup. For multiple-page - Use the scanner glass for single-page documents, documents, make sure to align the leading edge book pages, small items (such as postcards or before loading.

  • Page 57: Copying On Both Sides Of The Paper

    Copy Copying on both sides of the paper Load an original document into the ADF tray or on the scanner glass. From the home screen, touch Copy → Sides. Adjust the settings. Copy the document. Reducing or enlarging copies Load an original document into the ADF tray or on the scanner glass. From the home screen, navigate to: Copy →...

  • Page 59: Chapter 7. E-Mail

    C300 User’s Guide E-mail...

  • Page 60: Using The Automatic Document Feeder And Scanner Glass

    E-mail Using the automatic document feeder and scanner glass Correct loading of paper Incorrect loading of paper - Use the ADF for multiple-page or two-sided documents. - Load an original document faceup. For multiple-page - Use the scanner glass for single-page documents, documents, make sure to align the leading edge book pages, small items (such as postcards or before loading.

  • Page 61: Creating An E-Mail Shortcut

    E-mail Creating an e-mail shortcut From the home screen, touch E‑mail. Configure the settings, and then touch Create a shortcut.

  • Page 63: Chapter 8. Fax

    C300 User’s Guide...

  • Page 64: Using The Automatic Document Feeder And Scanner Glass

    Using the automatic document feeder and scanner glass Correct loading of paper Incorrect loading of paper - Use the ADF for multiple-page or two-sided documents. - Load an original document faceup. For multiple-page - Use the scanner glass for single-page documents, documents, make sure to align the leading edge book pages, small items (such as postcards or before loading.

  • Page 65: Scheduling A Fax

    For Macintosh users ❖ With a document open, choose File → Print. Select the printer, and then enter the recipient number. If necessary, configure other fax settings. Fax the document. Scheduling a fax Load the original document into the ADF tray or on the scanner glass. From the home screen, navigate to: Fax → To → enter the fax number → Done Touch Send Time, configure the date and time, and then touch OK.

  • Page 66: Blocking Junk Faxes

    Blocking junk faxes From the home screen, touch Settings → Fax → Fax Setup → Fax Receive Settings → Admin Controls. Set Block No Name Fax to On. Holding a fax Open a web browser, and then type the printer IP address in the address field. Note - View the printer IP address on the printer home screen. The IP address appears as four sets of numbers separated by periods, such as 123.123.123.123. - If you are using a proxy server, then temporarily disable it to load the web page correctly. Click Settings > Fax > Fax Setup > Fax Receive Settings > Holding Faxes.

  • Page 67: Chapter 9. Scan

    C300 User’s Guide Scan...

  • Page 68: Using The Automatic Document Feeder And Scanner Glass

    Scan Using the automatic document feeder and scanner glass Correct loading of paper Incorrect loading of paper - Use the ADF for multiple-page or two-sided documents. - Load an original document faceup. For multiple-page - Use the scanner glass for single-page documents, documents, make sure to align the leading edge book pages, small items (such as postcards or before loading.

  • Page 69: Creating A Network Folder Shortcut

    Scan Creating a network folder shortcut Open a web browser, and then type the printer IP address in the address field. Note - View the printer IP address on the printer home screen. The IP address appears as four sets of numbers separated by periods, such as 123.123.123.123.

  • Page 70: Scanning To A Cloud Connector Profile

    Scan Scanning to a Cloud Connector profile Load an original document into the ADF tray or on the scanner glass. Click Shortcuts → Add Shortcut. From the Shortcut Type menu, select Network Folder, and then configure the settings. Note - For more information on creating a Cloud Connector profile, see “Creating a Cloud Connector profile” on P.

  • Page 71: Chapter 10. Use Printer Menus

    C300 User’s Guide Use printer menus...

  • Page 72: Menu Map

    Use printer menus Menu map Device • Preferences • Restore Factory Defaults • Eco‑Mode • Maintenance • Remote Operator Panel • Visible Home Screen Icons • Notifications • About this Printer • Power Management Print • Layout • PostScript • Setup •...

  • Page 73: Device

    Use printer menus Device Preferences Menu item Description Display Language Set the language of the text that appears on the display. [List of languages] Country/Region Identify the country or region where the printer is configured to [List of countries or regions] operate.

  • Page 74: Eco-Mode

    Use printer menus Eco‑Mode Menu item Description Print Specify whether to print on one side or two sides of the paper. Sides 1‑Sided* 2‑Sided Print Print multiple page images on one side of a sheet of paper. Pages per Side Off* 2 pages per side 3 pages per side...

  • Page 75: Notifications

    Use printer menus 2.4 Notifications Menu item Description ADF Loaded Beep Enable a sound when loading paper into the ADF. Alarm Control Set the number of times that the alarm sounds when the printer requires user intervention. Single* Continuous Supplies Show the estimated status of the supplies.

  • Page 76: Power Management

    Use printer menus Menu item Description Error Prevention Set the printer to restart when an error occurs. Auto Reboot Auto Reboot Reboot when idle Reboot always* Reboot never Error Prevention Set the number of automatic reboots that the printer can Auto Reboot perform.

  • Page 77: Restore Factory Defaults

    Use printer menus Menu item Description Timeouts Set the time before the printer turns off. Hibernate Timeout Disabled 1 hour 2 hours 3 hours 6 hours 1 day 2 day 3 days* 1 week 2 week 1 month Timeouts Set Hibernate Timeout to turn off the printer while an active Ethernet Hibernate Timeout on Connection connection exists.
  • Page 78 Use printer menus Menu item Description Tray Configuration Display a message to select paper size and type after inserting the Show Tray Insert Message tray. Only for unknown sizes* Always Tray Configuration Specify the page orientation when loading A5 paper size. A5 Loading Short Edge Long Edge*...
  • Page 79 Use printer menus Menu item Description Printer Emulations Disable access to printer message during emulation. Emulator Security Disable Printer Message Access Fax Configuration Set fax to enter Sleep mode whenever the printer determines Fax Low Power Support that it should. Disable Sleep Permit Sleep Auto*...
  • Page 80 Use printer menus Menu item Description Toner patch sensor setup Set the default calibration frequency. Calibration frequency preference Disabled Fewest color adjustment Fewer color adjustment Normal* Better color accuracy Best color accuracy Toner patch sensor setup Run the full color calibration. Full calibration Toner patch sensor setup Print a diagnostic page that contains toner patch sensor calibration.

  • Page 81: Out Of Service Erase

    Use printer menus Out of Service Erase Menu Item Description Sanitize all information on nonvolatile Clear all settings and applications that are stored in the printer. memory Erase all printer and network settings Erase all shortcuts and shortcut settings Visible Home Screen Icons Menu Item Description Copy...
  • Page 82 Use printer menus Menu Item Description Send Logs Send diagnostic information to Sindoh. Cancel Send * This menu item appears only in some printer models.

  • Page 83: Print

    Use printer menus Print Layout Menu Item Description Sides Specify whether to print on one side or two sides of the paper. 1‑sided* 2‑sided Flip Style Determine which side of the paper (long edge or short edge) is bound Long Edge* when performing two‑sided printing.

  • Page 84: Setup

    Use printer menus Menu Item Description Print Area Set the printable area on a sheet of paper. Normal* Fit to page Whole Page Note: An asterisk (*) next to a value indicates the factory default setting. Setup Menu Item Description Printer Language Set the printer language.

  • Page 85: Advanced Imaging

    Use printer menus Menu Item Description Halftone Enhance the printed output to have smoother lines with sharper edges. Normal* Detail RGB Brightness Adjust the brightness, contrast, and saturation for color output. ‑6 to 6 (0*) Note ‑ This setting does not affect files where CMYK color specifications are used. RGB Contrast 0 to 5 (0*) RGB Saturation...

  • Page 86: Pcl

    Use printer menus Menu Item Description Lock PS Startup Mode Disable the SysStart file. Note ‑ The default setting varies depending on the printer model. Image Smoothing Enhance the contrast and sharpness of low‑resolution images. Note Off* ‑ This setting has no effect on images with a resolution of 300 dpi or higher.

  • Page 87: Image

    Use printer menus Menu Item Description A4 Width Set the width of the logical page on A4‑size paper. 198 mm* Note 203 mm ‑ Logical page is the space on the physical page where data is printed. Auto CR after LF Set the printer to perform a carriage return after a line feed control command.

  • Page 88: Paper

    Use printer menus Paper 4.1 Tray Configuration Menu Item Description Default Source Set the paper source for all print jobs. Tray [x] (1*) Manual Paper Manual Envelope Paper Size / Type Specify the paper size or paper type loaded in each paper source. Tray [x] (1*) Manual Paper Manual Envelope...

  • Page 89: Custom Scan Sizes

    Use printer menus Custom Scan Sizes Menu Item Description Custom Scan Size [x] Assign a scan size name and configure the scan settings. Scan Size Name Width 1–8.50 inches (8.50*) 25–216 mm (216*) Height 1–14 inches (14*) 25–356 mm (297*) Orientation Portrait* Landscape...

  • Page 90: Copy

    Use printer menus Copy Copy Defaults Menu Item Description Content Type Improve the output result based on the content of the original document. Text Text / Photo* Photo Graphics Sides Specify the scanning behavior based on the original document. 1 sided to 1 sided* Note 1 sided to 2 sided ‑...
  • Page 91 Use printer menus Advanced Imaging Menu Item Description Color Balance Adjust the color intensity during scanning. Cyan to Red ‑4 to 4 (0*) Magenta to Green ‑4 to 4 (0*) Yellow to Blue ‑4 to 4 (0*) Auto Color Detect Set the amount of color that the printer detects from the original Color Sensitivity document.

  • Page 92: Fax

    Use printer menus Fax Defaults Fax Mode Menu Item Description Fax Mode Select a fax mode. Fax* Disabled Note: An asterisk (*) next to a value indicates the factory default setting. Fax Setup General Fax Settings Menu Item Description Fax Name Identify your fax machine.
  • Page 93 Use printer menus Fax Send Settings Menu Item Description Resolution Set the resolution of the scanned image. Standard* Note Fine ‑ A higher resolution increases fax transmission time and requires Super Fine higher memory. Ultra Fine Original Size Specify the size of the original document. [List of paper sizes] Note ‑...
  • Page 94 Use printer menus Menu Item Description Contrast Set the contrast of the output. Best for Content* Background Removal Adjust the amount of background visible on a scanned image. Level ‑4 to 4 (0*) Scan Edge to Edge Allow edge‑to‑edge scanning of the original document. Off* Note: An asterisk (*) next to a value indicates the factory default setting.
  • Page 95 Use printer menus Menu Item Description Auto Convert Color Faxes to Mono Convert all outgoing color faxes to black and white. Faxes Confirm Fax Number Ask the user to confirm the fax number. Off* Dial Prefix Set a dialing prefix. Note: An asterisk (*) next to a value indicates the factory default setting.
  • Page 96 Use printer menus Menu Item Description Enable Caller ID Show the number that is sending the incoming fax. Off* Block No Name Fax Block incoming faxes sent from devices with no station ID or fax ID specified. Off* Answer On Set a distinctive ring pattern for incoming fax.
  • Page 97 Use printer menus Menu Item Description Auto Print Logs Print all fax activity. Log Paper Source Specify the paper source for printing logs. Tray [x] (1*) Logs Display Identify the sender by remote fax name or fax number. Remote Fax Name* Dialed Number Enable Job Log View a summary of all fax jobs.

  • Page 98: E-Mail

    Use printer menus E‑mail E‑mail Setup Menu Item Description Primary SMTP Gateway Type the IP address or host name of the primary SMTP server for sending e‑mail. Primary SMTP Gateway Port Enter the port number of the primary SMTP server. 1‑65535(25*) Secondary SMTP Gateway Type the server IP address or host name of your secondary or...
  • Page 99 Use printer menus Menu Item Description Format Specify the file format for the scanned image. PDF(.pdf)* TIFF(.tif) JPEG(.jpg) PDF Settings Set the PDF format of the scanned image. PDF Version Note ‑ Archival Version and Archival (PDF/A) appear only if PDF Version is set to 1.4.

  • Page 100: Advanced Imaging

    Use printer menus Advanced Imaging Menu Item Description Color Balance Adjust the color intensity during scanning. Cyan to Red ‑4 to 4 (0*) Magenta to Green ‑4 to 4 (0*) Yellow to Blue ‑4 to 4 (0*) Auto Color Detect Set the amount of color that the printer detects from the original Color Sensitivity document.
  • Page 101 Use printer menus Menu Item Description Text / Photo Default Set the quality of text or photo on a scanned image. 5‑95 (75*) Photo Default Set the quality of a photo on a scanned image. 5‑95 (50*) Transmission Log Print a log for successful e‑mail transmission. Print log* Do Not Print Log Print Only For Error...

  • Page 102: Ftp

    Use printer menus FTP Defaults Menu Item Description Format Specify the file format for the scanned image. PDF(.pdf)* TIFF(.tif) JPEG(.jpg) PDF Settings Set the PDF format for the scanned image. PDF Version Note ‑ Archival Version and Archival (PDF/A) appear only if PDF Version is set to 1.4.
  • Page 103 Use printer menus Menu Item Description Sides Specify the orientation of the original document when scanning on both Off* sides of the document. Long Edge Note Short Edge ‑ This menu item appears only in some printer models. File Name Specify the file name of the scanned image.
  • Page 104 Use printer menus Menu Item Description Photo Default Set the quality of a photo image on a scanned image. 5‑95 (50*) Transmission Log Print a log for successful FTP scan transmission. Print Log* Do Not Print Log Print Only For Error Log Paper Source Specify the paper source for printing FTP logs.

  • Page 105: Usb Drive

    Use printer menus USB Drive Flash Drive Scan Menu Item Description Format Specify the file format for the scanned image. PDF(.pdf)* TIFF(.tif) JPEG(.jpg) PDF Setting Set the PDF format for the scanned image. PDF Version Note ‑ Archival Version and Archival (PDF/A) appear only if PDF Version is set to 1.4.

  • Page 106: Advanced Imaging

    Use printer menus Menu Item Description Sides Specify the orientation of the original document when scanning on both Off* sides of the document. Long Edge Note Short Edge ‑ This menu item appears only in some printer models. File Name Specify the file name of the scanned image.

  • Page 107: Flash Drive Print

    Use printer menus Menu Item Description Photo Default Set the quality of a photo on a scanned image. 5‑95 (50*) Note: An asterisk (*) next to a value indicates the factory default setting. Flash Drive Print Menu Item Description Number of Copies Set the number of copies.
  • Page 108 Use printer menus Menu Item Description Separator Sheets Specify whether to insert blank separator sheets when printing. Off* Between Copies Between Jobs Between Pages Separator Sheet Source Specify the paper source for the separator sheet. Tray [x] (1*) Blank Pages Specify whether to print blank pages in a print job.

  • Page 109: Network/Ports

    Use printer menus 10. Network/Ports 10.1 Network Overview Menu Item Description Active Adapter Specify the type of the network connection. Auto* Note Standard to Network ‑ Wireless is available only in printers connected to a wireless network. Wireless Network Status Show the connectivity status of the printer network.

  • Page 110: Wireless

    Use printer menus 10.2 Wireless Menu Item Description Setup Using Mobile Appz Configure the wireless connection using the Sindoh Mobile Assistant app. Setup On Printer Panel Determine the wireless network that the printer connects to. Choose Network Note Add Wi‑Fi Network ‑...
  • Page 111 Use printer menus Menu Item Description 802.1x Encryption Mode Enable wireless security through 802.1x standard. WPA+ Note WPA2* ‑ This menu item appears only when Wireless Security Mode is set to 802.1x ‑ Radius. IPv4 Enable Dynamic Host Configuration Protocol (DHCP). Enable DHCP Note ‑...

  • Page 112: Ethernet

    Use printer menus Menu Item Description PS SmartSwitch Set the printer to switch automatically to PS emulation when a print job requires it, regardless of the default printer language. Note ‑ If PS SmartSwitch is off, then the printer does not examine incoming data and uses the default printer language specified in the Setup menu.

  • Page 113: Tcp/Ip

    Use printer menus Menu Item Description IPv6 Specify the address prefix. Address Prefix 0–128 (64*) IPv6 Show all IPv6 addresses. All IPv6 Addresses IPv6 Show all IPv6 router addresses. All IPv6 Router Addresses Network Address Show the printer Media Access Control (MAC) addresses: Locally Administered Address (LAA) and Universally Administered Address (UAA).
  • Page 114 Use printer menus Menu Item Description DNS Address Specify the current Domain Name System (DNS) server address. Backup DNS Specify the backup DNS server addresses. Backup DNS 2 Backup DNS 3 Domain Search Order Specify a list of domain names to locate the printer and its resources that reside in different domains on the network.

  • Page 115: Snmp

    Use printer menus 10.5 SNMP Note ‑ This menu appears only in network printers or printers that are attached to print servers. Menu Item Description SNMP Versions 1 and 2c Configure Simple Network Management Protocol (SNMP) versions 1 Enabled and 2c to install print drivers and applications. Allow SNMP Set Enable PPM MIB SNMP Community...
  • Page 116 Use printer menus Menu Item Description DH (Diffie‑Hellman) Group Proposal Set the IPSec encryption. modp2048 (14)* Note modp3072 (15) ‑ DH (Diffie‑Hellman) Group Proposal appears only when Base modp4069 (16) Configuration is set to Compatibility. modp6144 (17) ‑ IKE SA Lifetime (Hours) and IPSec SA Lifetime (Hours) appear only when Base Configuration is set to Secure.

  • Page 117: Lpd Configuration

    Use printer menus 10.8 LPD Configuration Note ‑ This menu appears only in network printers or printers that are attached to print servers. Menu Item Description LPD Timeout Set the time‑out value to stop the Line Printer Daemon (LPD) server 0–65535 seconds (90*) from waiting indefinitely for hung or invalid print jobs.

  • Page 118: Usb

    Use printer menus Menu Item Description Retries for HTTP/FTP Requests Set the number of retries to connect to the HTTP/FTP server. 1–299 (3*) Note: An asterisk (*) next to a value indicates the factory default setting. 10.10 USB Menu Item Description PCL SmartSwitch Set the printer to switch to PCL emulation when a print job received...

  • Page 119: Google Cloud Print

    Use printer menus 10.12 Google Cloud Print Menu Item Description Registration Register the printer to the Google Cloud Print server. Register Options Print directly from your Google account. Enable Google Cloud Print Options Allow the registered user and other users on the same subnet to send Enable Local Discovery jobs to the printer locally.

  • Page 120: Security

    Use printer menus 11. Security 11.1 Login Methods Public Menu Item Description Manage Permissions Control access to the printer functions. Function Access Manage Shortcuts Create Profiles Manage Bookmarks Flash Drive Print Flash Drive Color Printing Flash Drive Scan Copy Function Copy Color Printing E‑mail Function FTP Function...

  • Page 121: Certificate Management

    Use printer menus Menu Item Description Manage Groups/Permissions Control group or user access to the printer functions, applications, and Add Group security settings. Import Access Controls Function Access Administrative Menus Device Management All Users Import Access Controls Function Access Administrative Menus Device Management Admin Function Access...

  • Page 122: Confidential Print Setup

    Use printer menus 11.4 Confidential Print Setup Menu Item Description Max Invalid PIN Set the number of times an invalid PIN can be entered. 2–10 (0*) Note ‑ A value of zero turns off this setting. ‑ When the limit is reached, the print jobs for that user name and PIN are deleted.

  • Page 123: Miscellaneous

    Use printer menus 11.6 Miscellaneous Menu Item Description Print Permission Let the user log in before printing. Off* Default Print Permission Login Set the default login for Print Permission. Minimum Password Length Specify the minimum characters that are allowed for a password. 0–32 (0*) Note: An asterisk (*) next to a value indicates the factory default setting.

  • Page 124: Cloud Connector

    Use printer menus 12. Cloud Connector Menu Item Description Enable/Disable Connectors Enable a cloud service provider.

  • Page 125: Reports

    Use printer menus 13. Reports 13.1 Menu Settings Page Menu Item Description Menu Settings Page Print a report that contains the printer menus. 13.2 Device Menu Item Description Device Information Print a report that contains information about the printer. Device Statistics Print a report about printer usage and supply status.

  • Page 126: Network

    Use printer menus 13.6 Network Menu Item Description Network Setup Page Print a page that shows the configured network and wireless settings on the printer. Note ‑ This menu item appears only in network printers or printers connected to print servers. Wi‑Fi Direct Connected Clients Print a page that shows the list of devices that are connected to the printer using Wi‑Fi Direct.

  • Page 127: Troubleshooting

    Use printer menus 14. Troubleshooting Menu Item Description Print Quality Test Pages Print sample pages to identify and correct print quality defects. Cleaning the Scanner Print instructions on how to clean the scanner.

  • Page 129: Chapter 11. Maintain The Printer

    C300 User’s Guide Maintain the printer...

  • Page 130: Checking The Status Of Parts And Supplies

    Maintain the printer Checking the status of parts and supplies From the home screen, touch Status/Supplies. Select the parts or supplies that you want to check. Note - You can also access this setting by touching the top section of the home screen. Configuring supply notifications Open a web browser, and then type the printer IP address in the address field.

  • Page 131: Ordering Parts And Supplies

    Maintain the printer Ordering parts and supplies To order supplies in the U.S., contact Sindoh for information about authorized supplies dealers in your area. In other countries or regions, go to www.Sindoh.com or contact the place where you purchased the printer.

  • Page 132: Replacing Parts And Supplies

    Maintain the printer Replacing parts and supplies Replacing a print cartridge Note - If the tray is extended, then remove it before replacing a cartridge. Open the front door, and then firmly push it down. Pull out the print cartridge tray. Remove the used print cartridge.
  • Page 133 Maintain the printer Unpack the new print cartridge. Warning Potential Damage ‑ Do not expose the underside of the print cartridge to direct light. Extended exposure to light may cause print quality problems. ‑ Do not touch the underside of the print cartridge. Doing so may affect the quality of future print jobs. Insert the new print cartridge.
  • Page 134 Maintain the printer Replacing the waste toner bottle Remove the used waste toner bottle. Note - To avoid spilling the toner, place the bottle in an upright position. Unpack the new waste toner bottle. Insert the new waste toner bottle. Replacing the tray Remove the used tray. Unpack the new tray.
  • Page 135 Maintain the printer Insert the new tray. Replacing the manual feeder Remove the tray. Unpack the new tray. Unpack the new manual feeder.
  • Page 136 Maintain the printer Insert the new manual feeder. Insert the tray. Replacing the ADF tray Open the ADF cover. Unpack the new waste toner bottle.
  • Page 137 Maintain the printer Unpack the new ADF tray. Insert the new ADF tray until it clicks into place. Close the ADF cover.
  • Page 138 Maintain the printer Replacing the pick tires Turn off the printer. Unplug the power cord from the electrical outlet, and then from the printer. Open the front door, and then firmly push it down. Pull out the print cartridge tray. To avoid stray toner contamination, place a sheet of paper on the top of the print cartridge tray, and then insert the print cartridge tray.
  • Page 139 Maintain the printer Close the front door. Remove the tray. Remove the waste toner bottle. Position the printer on its side.
  • Page 140 Maintain the printer Remove the used pick tires. Unpack the new pick tires. Note - To avoid contamination, make sure that your hands are clean.
  • Page 141 Maintain the printer Insert the new pick tires. Return the printer to its original position, and then insert the waste toner bottle. Insert the tray. Open the front door, and then firmly push it down. Pull out the print cartridge tray. Remove the paper, and then insert the print cartridge tray. Close the front door. Connect the power cord to the printer, and then to the electrical outlet. CAUTION : POTENTIAL INJURY To avoid the risk of fire or electrical shock, connect the power cord to an appropriately rated and properly grounded electrical outlet that is near the product and easily accessible.
  • Page 142 Maintain the printer Replacing the ADF separator pad Open the ADF cover. Pull out the print cartridge tray.
  • Page 143 Maintain the printer Unpack the new ADF separator pad. Insert the new separator pad until it clicks into place. Close the ADF cover.

  • Page 144: Cleaning Printer Parts

    Maintain the printer Resetting the supply usage counters From the home screen, touch Settings → Device → Maintenance → Config Menu → Supply Usage And Counters. Select the counter that you want to reset. Warning Potential Damage ‑ Supplies and parts without Return Program agreement terms may be reset and remanufactured. However, the manufacturer’s warranty does not cover any damage caused by non‑genuine supplies or parts.
  • Page 145 Maintain the printer Cleaning the scanner Open the scanner cover. Using a damp, soft, lint-free cloth, wipe the following areas: ADF glass pad ❖ Note - In some printer models, this location has an ADF glass instead of a pad. ADF glass pad ❖...

  • Page 146: Saving Energy And Paper

    Maintain the printer ❖ ADF glass ❖ Scanner glass Close the scanner cover. Saving energy and paper Configuring the power save mode settings Sleep mode ❖ From the home screen, touch Settings → Device → Power Management → Timeouts → Sleep Mode. Specify the amount of time that the printer stays idle before it enters Sleep Mode. Hibernate mode ❖ From the home screen, touch Settings → Device → Power Management → Timeouts → Hibernate Timeout. Select the amount of time that the printer stays idle before it enters Hibernate mode. Note - For Hibernate Timeout to work, set Hibernate Timeout on Connection to Hibernate. - The Embedded Web Server is disabled when the printer is in Hibernate mode.

  • Page 147: Moving The Printer To Another Location

    Maintain the printer Adjusting the brightness of the printer display From the home screen, touch Settings → Device → Preferences → Screen Brightness. Adjust the setting. Conserving supplies - Print on both sides of the paper. Note - Two-sided printing is the default setting in the print driver. - Print multiple pages on a single sheet of paper. - Use the preview feature to see how the document looks like before printing it.

  • Page 149: Chapter 12. Troubleshoot A Problem

    C300 User’s Guide Troubleshoot a problem...

  • Page 150: The Printer Is Not Responding

    Troubleshoot a problem The printer is not responding Action Step 1 The problem is Go to step 2. Check if the power cord is connected to the electrical outlet. solved. CAUTION : POTENTIAL INJURY To avoid the risk of fire or electrical shock, connect the power cord to an appropriately rated and properly grounded electrical outlet that is near the product and easily accessible.

  • Page 151: Unable To Read Flash Drive

    Troubleshoot a problem Unable to read flash drive Action Step 1 Go to step 2. Wait for the printer to Check if the printer is not busy processing another print, copy, finish processing the scan, or fax job. other job. Is the printer ready? Step 2 Go to step 3.

  • Page 152: Enabling The Usb Port

    Troubleshoot a problem Enabling the USB port From the home screen, touch Settings → Network/Ports → USB → Enable USB Port.

  • Page 153: Network Connection Problems

    Troubleshoot a problem Network connection problems Cannot open Embedded Web Server Action Step 1 Go to step 2. Turn on the printer. Check if the printer is on. Is the printer on? Step 2 Go to step 3. Type the correct printer Make sure that the printer IP address is correct.

  • Page 154: Issues With Supplies

    All life indicators are designed to function with supplies and parts and may deliver unpredictable results if third-party supplies or parts are used. Imaging component usage beyond the intended life may damage your Sindoh printer or associated components.
  • Page 155 Troubleshoot a problem For non-touch-screen printer models, if the printer does not print after pressing and holding X and simultaneously for 15 seconds, then reset the supply usage counter. From the control panel, navigate to: Settings → Device → Maintenance → Config Menu → Supply Usage And Counters For non-touch-screen printer models, press to navigate through the settings.

  • Page 156: Clearing Jams

    Troubleshoot a problem Clearing jams Avoiding jams Load paper properly - Make sure that the paper lies flat in the tray. Correct loading of paper Incorrect loading of paper - Do not load or remove a tray while the printer is printing. - Do not load too much paper. Make sure that the stack height is below the maximum paper fill indicator. - Do not slide paper into the tray. Load paper as shown in the illustration. - Make sure that the paper guides are positioned correctly and are not pressing tightly against the paper or envelopes.

  • Page 157: Identifying Jam Locations

    Troubleshoot a problem - Do not use paper that has been cut or trimmed by hand. - Do not mix paper sizes, weights, or types in the same tray. - Make sure that the paper size and type are set correctly on the computer or printer control panel. - Store paper according to manufacturer recommendations. Identifying jam locations Note - When Jam Assist is set to On, the printer might attempt to flush blank pages or pages with partial prints after clearing the jam.

  • Page 158: Paper Jam In The Standard Tray

    Troubleshoot a problem Paper jam in the standard tray Open door B. CAUTION : HOT SURFACE The inside of the printer might be hot. To reduce the risk of injury from a hot component, allow the surface to cool before touching it. Remove the jammed paper.

  • Page 159: Paper Jam In The Standard Tray

    Troubleshoot a problem Remove the jammed paper. Note - Make sure that all paper fragments are removed. Insert the manual feeder and the tray. Paper jam in the standard tray Open door B. CAUTION : HOT SURFACE The inside of the printer might be hot. To reduce the risk of injury from a hot component, allow the surface to cool before touching it.
  • Page 160 Troubleshoot a problem Open door E. Remove the jammed paper. Note - Make sure that all paper fragments are removed. Close the door. Remove the optional tray. Remove the jammed paper. Note - Make sure that all paper fragments are removed. Insert the tray.

  • Page 161: Paper Jam In The Standard Bin

    Troubleshoot a problem Paper jam in the standard bin Raise the scanner, and then remove the jammed paper. Note - Make sure that all paper fragments are removed. Lower the scanner. Paper jam in the manual feeder Remove the tray and the manual feeder.

  • Page 162: Paper Jam In Door B

    Troubleshoot a problem Remove the jammed paper. Note - Make sure that all paper fragments are removed. Insert the manual feeder and the tray. Paper jam in door B Open door B. CAUTION : HOT SURFACE The inside of the printer might be hot. To reduce the risk of injury from a hot component, allow the surface to cool before touching it.

  • Page 163: Fuser Area

    Troubleshoot a problem Fuser area Below the fuser area...

  • Page 164: Duplex Unit

    Troubleshoot a problem Duplex unit Close the door. Paper jam in the automatic document feeder Remove all original documents from the ADF tray. Open the ADF cover. move the jammed paper. Note - Make sure that all paper fragments are removed. Close the ADF cover.

  • Page 165: Paper Feed Problems

    Troubleshoot a problem Paper feed problems Envelope seals when printing Action Step 1 Go to step 2. The problem is 1) Use an envelope that has been stored in a dry solved. environment. Note - Printing on envelopes with high moisture content can seal the flaps. 2) Send the print job. Does the envelope seal when printing? Step 2 Contact customer...

  • Page 166: Tray Linking Does Not Work

    Troubleshoot a problem Tray linking does not work Action Step 1 The problem is Go to step 2. 1) Check if the trays contain the same paper size and paper solved. type. 2) Check if the paper guides are positioned correctly. 3) Print the document. Do the trays link correctly? Step 2 The problem is Go to step 3. 1) From the control panel, touch Settings → Paper → Tray solved.

  • Page 167: Jammed Pages Are Not Reprinted

    Troubleshoot a problem Action Step 3 Contact customer The problem is 1) Load paper from a fresh package. support. solved. Note - Paper absorbs moisture due to high humidity. Store paper in its original wrapper until you are ready to use it. 2) Print the document. Do paper jams occur frequently? Jammed pages are not reprinted Action 1) From the control panel, navigate to:...

  • Page 168: Printing Problems

    Troubleshoot a problem Printing problems Print jobs do not print Action Step 1 The problem is Go to step 2. 1) From the document you are trying to print, open the Print solved. dialog, and then check if you have selected the correct printer. 2) Print the document. Is the document printed? Step 2 The problem is Go to step 3.

  • Page 169: Job Prints From The Wrong Tray Or On The Wrong Paper

    Troubleshoot a problem Action Step 2 The problem is Go to step 3. The print job may contain a formatting error or invalid data. solved. Delete the print job, and then send it again. Are the documents printed? Step 3 The problem is Go to step 4. If you are printing from the Internet, then the printer may be solved.

  • Page 170: Slow Printing

    Troubleshoot a problem Slow printing Action Step 1 Go to step 2. The problem is Make sure that the printer cable is securely connected to the solved. printer and to the computer, print server, option, or other network device. Is the printer printing slow? Step 2 Go to step 3.

  • Page 171: Print Quality Problems

    Troubleshoot a problem Action Step 7 GContact customer The problem is 1) Make sure that the printer is not overheating. support. solved. Note - Allow the printer to cool down after a long print job. - Observe the recommended ambient temperature for the printer.
  • Page 172 Troubleshoot a problem Dark print ❖ Note - Before solving the problem, print the Print Quality Test Pages. From the control panel, navigate to Settings → Troubleshooting → Print Quality Test Pages. For non-touch-screen printer models, press to navigate through the settings. Action Step 1 Go to step 2. The problem is 1) Perform Color Adjust. solved. From the control panel, navigate to: Settings → Print → Quality → Advanced Imaging →...
  • Page 173 Troubleshoot a problem Action Step 5 Go to step 6. The problem is 1) Replace textured or rough paper with plain paper. solved. 2) Print the document. Is the print too dark? Step 6 Contact customer The problem is 1) Load paper from a fresh package. support. solved. Note - Paper absorbs moisture due to high humidity. Store paper in its original wrapper until you are ready to use it.
  • Page 174 Troubleshoot a problem Action Step 3 Go to step 4. The problem is 1) Perform Color Adjust. solved. From the control panel, navigate to: Settings → Print → Quality → Advanced Imaging → Color Adjust 2) Print the document. Do ghost images appear on prints? Step 4 Contact customer The problem is support. solved. 1) Open the front door, and then firmly push it down.
  • Page 175 Troubleshoot a problem Action Step 1 Go to step 2. The problem is 1) Perform Color Adjust. solved. From the control panel, navigate to: Settings → Print → Quality → Advanced Imaging → Color Adjust 2) Print the document. Does gray or colored background appear on prints? Step 2 Contact customer The problem is support.
  • Page 176 Troubleshoot a problem Action Step 2 The problem is Go to step 3. 1) Set the paper size. solved. From the control panel, navigate to: Settings → Paper → Tray Configuration → Paper Size/ Type 2) Print the document. Are the margins correct? Step 3 The problem is Contact customer su- 1) Depending on your operating system, specify the paper solved. pport. size from the Printing Preferences or Print dialog. Note - Make sure that the setting matches the paper loaded.
  • Page 177 Troubleshoot a problem Action Step 2 Go to step 3. The problem is 1) Depending on your operating system, increase toner solved. darkness from the Printing Preferences or Print dialog. Note - You can also change the setting on the printer control panel. Navigate to Settings → Print → Quality → Toner Darkness 2) Print the document. Is the print light? Step 3 Go to step 4.
  • Page 178 Troubleshoot a problem Action Step 8 Contact customer The problem is support. solved. 1) Open the front door, and then firmly push it down. 2) Pull out the print cartridge tray. 3) Remove, and then insert the print cartridges. 4) Insert the print cartridge tray, and then close the door. 5) Print the document. Is the print light? Missing colors ❖ Note - Before solving the problem, print the Print Quality Test Pages. From the control panel, navigate to Settings → Troubleshooting → Print Quality Test Pages. For non-touch-screen printer models, press to navigate through the settings.
  • Page 179 Troubleshoot a problem Action 1) Open the front door, and then firmly push it down. Contact customer The problem is support. solved. 2) Pull out the print cartridge tray. 3) Remove, and then insert the print cartridge of the missing color. 4) Insert the print cartridge tray, and then close the door. 5) Print the document. Are some colors missing on prints? Mottled print and dots ❖ Note - Before solving the problem, print the Print Quality Test Pages. From the control panel, navigate to Settings → Troubleshooting → Print Quality Test Pages. For non-touch-screen printer models, press to navigate through the settings.
  • Page 180 Troubleshoot a problem Action Step 3 Go to step 4. The problem is 1) Depending on your operating system, specify the paper solved. size and paper type from the Printing Preferences or Print dialog. Note - Make sure that the settings match the paper loaded. 2) Print the document. Is the print mottled? Step 4 Go to step 5.
  • Page 181 Troubleshoot a problem Paper curl ❖ Action Step 1 Go to step 2. The problem is 1) Adjust the guides in the tray to the correct position for the solved. paper loaded. 2) Print the document. Is the paper curled? Step 2 Go to step 3. The problem is 1) Depending on your operating system, specify the paper solved.
  • Page 182 Troubleshoot a problem Print crooked or skewed ❖ Note - Before solving the problem, print the Print Quality Test Pages. From the control panel, navigate to Settings → Troubleshooting → Print Quality Test Pages. For non-touch-screen printer models, press to navigate through the settings. Action Step 1 Go to step 2. The problem is 1) Adjust the paper guides in the tray to the correct position solved. for the paper loaded. 2) Print the document.
  • Page 183 Troubleshoot a problem Solid color or black images ❖ Note - Before solving the problem, print the Print Quality Test Pages. From the control panel, navigate to Settings → Troubleshooting → Print Quality Test Pages. For non-touch-screen printer models, press to navigate through the settings. Action 1) Open the front door, and then firmly push it down. Contact customer The problem is support. solved. 2) Pull out the print cartridge tray. 3) Remove, and then insert the print cartridges. 4) Insert the print cartridge tray, and then close the door. 5) Print the document. Is the printer printing solid color or black images? Text or images cut off ❖...
  • Page 184 Troubleshoot a problem Action Step 1 Go to step 2. The problem is 1) Adjust the paper guides in the tray to the correct position solved. for the paper loaded. 2) Print the document. Are text or images cut off? Step 2 Go to step 3. The problem is 1) Depending on your operating system, specify the paper solved. size from the Printing Preferences or Print dialog. Note - Make sure that the setting matches the paper loaded.
  • Page 185 Troubleshoot a problem Action Step 1 Go to step 2. The problem is 1) Depending on your operating system, specify the paper solved. type from the Printing Preferences or Print dialog. Note - Make sure that the setting matches the paper loaded. - You can also change the setting on the printer control panel. Navigate to: Settings → Paper → Tray Configuration → Paper Size/Type 2) Print the document.
  • Page 186 Troubleshoot a problem Action 1) Open the front door, and then firmly push it down. Contact customer The problem is support. solved. 2) Pull out the print cartridge tray. 3) Remove, and then insert the print cartridges. 4) Insert the print cartridge tray, and then close the door. 5) Print the document. Is the print density uneven? Horizontal dark lines ❖ Note - Before solving the problem, print the Print Quality Test Pages. From the control panel, navigate to Settings → Troubleshooting → Print Quality Test Pages. For non-touch-screen printer models, press to navigate through the settings. - If horizontal dark lines keep appearing on the prints, then see the “Repeating defects”...
  • Page 187 Troubleshoot a problem Action Step 2 Go to step 3. The problem is 1) Load paper from a fresh package. solved. Note - Paper absorbs moisture due to high humidity. Store paper in its original wrapper until you use it. 2) Print the document. Do dark lines appear on prints? Step 3 Contact customer The problem is...
  • Page 188 Troubleshoot a problem Action Step 1 Go to step 2. The problem is 1) Depending on your operating system, specify the paper solved. type from the Printing Preferences or Print dialog. Note - Make sure that the setting matches the paper loaded. - You can also change the setting on the printer control panel. Navigate to Settings → Paper → Tray Configuration → Paper Size/Type 2) Print the document.
  • Page 189 Troubleshoot a problem Action Step 1 Go to step 2. The problem is 1) Depending on your operating system, specify the paper solved. type from the Printing Preferences or Print dialog. Note - Make sure that the setting matches the paper loaded. - You can also change the setting on the printer control panel. Navigate to Settings → Paper → Tray Configuration → Paper Size/Type 2) Print the document.
  • Page 190 Troubleshoot a problem Action Step 1 Go to step 2. The problem is 1) Depending on your operating system, specify the paper solved. type from the Printing Preferences or Print dialog. Note - Make sure that the setting matches the paper loaded. - You can also change the setting on the printer control panel. Navigate to Settings → Paper → Tray Configuration → Paper Size/Type 2) Print the document.
  • Page 191 Troubleshoot a problem Action 1) Using the Print Quality Test Pages, measure the distance Take note of the Take note of the distance, and then distance, and then between the repeating defects on the affected color page. contact customer contact customer 2) Check if the repeating defects match any of the following support. support. measurements: Print cartridges - 25.70 mm (1.01 in.) - 35.30 mm (1.39 in.) - 75.6 mm (2.98 in.) - 26.7 mm (1.05 in.) Fuser...

  • Page 192: Color Quality Problems

    Troubleshoot a problem Color quality problems Modifying the colors in printed output From the home screen, touch Settings → Print → Quality → Advanced Imaging → Color Correction. In the Color Correction menu, touch Manual → Color Correction Content. Choose the appropriate color conversion setting. Object type Color conversion tables RGB Image - Vivid-Produces brighter, more saturated colors and may be applied to all incoming color RGB Text formats.

  • Page 193: The Print Appears Tinted

    Troubleshoot a problem What is manual color correction? When manual color correction is enabled, the printer employs user-selected color conversion tables to process objects. Manual color correction settings are specific to the type of object being printed (text, graphics, or images). It is also specific to how the color of the object is specified in the software program (RGB or CMYK combinations). To apply a different color conversion table manually, see “Modifying the colors in printed output” on page 188.

  • Page 194: Faxing Problems

    Troubleshoot a problem 10. Faxing problems 10.1 Caller ID is not shown Action Enable caller ID. The problem is Contact customer s solved. upport. From the home screen, touch Settings → Fax → Fax Setup → Fax Receive Settings → Admin Controls → Enable Caller ID. Does the caller ID appear? 10.2 Cannot send or receive faxes Action...

  • Page 195: Can Receive But Not Send Faxes

    Troubleshoot a problem Action Step 5 The problem is Go to step 6. Check if the printer is connected to an analog phone service or solved. to the correct digital connector. - If you are using an Integrated Services for Digital Network (ISDN) telephone service, then connect to an analog telephone port of an ISDN terminal adapter. For more information, contact your ISDN provider. - If you are using DSL, then connect to a DSL filter or router that supports analog use. For more information, contact your DSL provider.

  • Page 196: Can Send But Not Receive Faxes

    Troubleshoot a problem 10.4 Can send but not receive faxes Action Step 1 The problem is Go to step 2. Make sure that the paper source is not empty. solved. Can you receive faxes? Step 2 The problem is Go to step3. Check the ring count delay settings.

  • Page 197: Scanning Problems

    Troubleshoot a problem 11. Scanning problems 11.1 Cannot scan from a computer Action Step 1 The problem is Go to step 2. 1) Turn off the printer, wait for about 10 seconds, and then solved. turn it back on. 2) Resend the scan job. Can you send the scan job? Step 2 The problem is Contact customer 1) Make sure that the cables between the printer and the print...

  • Page 198: Poor Copy Quality

    Troubleshoot a problem Action Step 2 The problem is Go to step 3. Check the file you want to scan. solved. 1) Make sure that the file name is not already used in the destination folder. 2) Make sure that the document or photo you want to scan is not open in another application. 3) Resend the scan job. Is the scan job successful? Step3 The problem is Contact customer Check the file you want to scan.

  • Page 199: Scanner Does Not Close

    Troubleshoot a problem Action 1) Open the scanner cover. The problem is The problem is solved. solved. 2) Using a damp, soft, lint-free cloth, wipe the ADF glass pad. Note - In some printer models, this location has an ADF glass ins tead of a pad. 3) Close the scanner cover. 4) Scan the document. Do vertical streaks appear on scanned documents? 11.6 Scanner does not close Action Remove obstructions that keep the scanner cover open.

  • Page 200: Adjusting Scanner Registration

    Troubleshoot a problem Action Step 3 The problem is Contact customer 1) Turn off the printer, wait for about 10 seconds, and then solved. support. turn the printer on. 2) Copy or scan the document. Is the scanner responding? 11.9 Adjusting scanner registration From the control panel, navigate to: Settings → Device → Maintenance → Config Menu → Scanner Configuration → Scanner Manual Registration Touch Print Quick Test.

  • Page 201: Contacting Customer Support

    Troubleshoot a problem 12. Contacting customer support Before contacting customer support, make sure to have the following information: - Printer problem - Error message - Printer model type and serial number...

  • Page 203: Chapter 13. Notices

    C300 User’s Guide Notices...

  • Page 204: Noise Emission Levels

    The following measurements were made in accordance with ISO 7779 and reported in conformance with ISO 9296. Note - Some modes may not apply to your product. 1-meter average sound pressure, dBA Printing One-sided: 52 (C300) Two-sided: 52 (C300) Scanning 51 (C300) Copying...

  • Page 205: Temperature Information

    - Some modes may not apply to your product. Mode Description Power consumption (Watts) Printing The product is generating hard-copy output from electronic One-sided: 400 (C300) inputs. Two-sided: 275 (C300) Copy The product is generating hard-copy output from hard-copy 395 (C300) original documents.
  • Page 206 Notices Sleep Mode This product is designed with an energy-saving mode called Sleep Mode. The Sleep Mode saves energy by lowering power consumption during extended periods of inactivity. The Sleep Mode is automatically engaged after this product is not used for a specified period of time, called the Sleep Mode Timeout. Factory default Sleep Mode Timeout for this product (in minutes): By using the configuration menus, the Sleep Mode Timeout can be modified between 1 minute and 120 minutes.

Table of Contents

Save PDF
