Summary of Contents for HT QUICKLAN 6055
- Page 1 ENGLISH User manual Copyright HT ITALIA 2013 Release EN 2.00 - 02/05/2013 www.valuetronics.com...
- Page 2 QUICKLAN 6055 Table of contents SAFETY PRECAUTIONS AND PROCEDURES ............2 1.1. Preliminary instruction ......................2 1.2. During use ..........................2 1.3. After use ..........................2 GENERAL DESCRIPTION ................... 3 PREPARATION FOR USE ................... 4 3.1. ...
- Page 3 QUICKLAN 6055 1. SAFETY PRECAUTIONS AND PROCEDURES CAUTION For your own safety as well as that of the apparatus you are recommended to follow the procedures described in this instruction manual and carefully read all the notes preceded by the symbol .
- Page 4 QUICKLAN 6055 2. GENERAL DESCRIPTION QUICKLAN 6055 is an easy cable tester for LAN cables with RJ45 connector of whatsoever category. It’s able to detect cable failures and check wirings in UTP (Unshielded Twisted Pair) and STP (Shielded – screened shielded Twisted Pair) cables.
- Page 5 QUICKLAN 6055 3. PREPARATION FOR USE 3.1. INITIAL This instrument was checked both mechanically and electrically prior to shipment. All possible cares and precautions were taken to let you receive the instrument in perfect conditions. Notwithstanding we suggest you to check it rapidly (eventual damages may have occurred during transport).
- Page 6 QUICKLAN 6055 4. OPERATING INSTRUCTIONS 4.1. INSTRUMENT DESCRIPTION 4.1.1. Front panel CAPTION: 1. RJ45 input terminal 2. LCD display 3. UTP key 4. GO key 5. Arrow keys 6. ON/OFF key 7. STP key 8. Remote units #1 ~ #2 Fig.
- Page 7 QUICKLAN 6055 5. MEASUREMENTS 5.1. CABLING TEST VERIFY The wire mapping of RJ45 LAN cables is tested in accordance with its defined cabling layout. To test a cable perform the below operation: 1. Select the type of cable UTP or STP under test (see § 4.1.3).
- Page 8 QUICKLAN 6055 5.2. CABLING ERRORS Cabling error Description Visualization Mapping both conductors OPEN PAIR pair are interrupted (open) conductors REVERSED PAIR the same pair are reversed Two conductors are SHORTED CABLES short circuit between each other TRANSPOSED pairs (CROSSED) PAIRS...
- Page 9 QUICKLAN 6055 5.3. SPLIT PAIRS EXPLANATION NOTE A LAN cable contains 8 conductors, twisted two by two thus forming 4 pairs: 1-2, 3-6, 4-5, 7-8. The error “SPLIT PAIRS” consists in the exchange of two conductors belonging to different pairs. The pin to pin correspondence seems intact, but physically the conductors of two couples are split.
- Page 10 QUICKLAN 6055 6. MAINTENANCE 6.1. GENERAL INFORMATIONS 1. This model is a precision instrument. Whether in use or in storage, please do not exceed the specification requirements to avoid possible damages or dangers 2. Do not place this meter at high temperatures or humidity or expose it to direct sunlight 3.
- Page 11 QUICKLAN 6055 7. TECHNICAL SPECIFICATIONS 7.1. TECHNICAL SPECIFICATIONS Connectors LAN input connectors RJ45 Cables which can be tested Cable type UTP, STP Category CAT3, 5, 5E, 6, 6A, 7 Reference guideline: TIA/EIA 568B Max height of use: 2000m Length up to 200m (1) To perform the test “SPLIT PAIR”...
- Page 12 QUICKLAN 6055 8. SERVICE 8.1. WARRANTY CONDITIONS This instrument is guaranteed for one year against material or production defects, in accordance with our general sales conditions. During the warranty period the manufacturer reserves the right to decide either to repair or replace the product.
