INSTALLATION INSTRUCTIONS
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Observe all local plumbing codes.
2. According to rough-in dimensions, drain stub-out should be prearranged in the floor.
ROUGH-IN DIMENSIONS
INSTALLATION
Intended Finished Floor
1283920-2A-B
75423T
Hidden Floor Drain
Ø64
Ø41
Ø45
(600)
KOHLER
584
600
1
Drain pipe
To drain easily, the mounting position of
hidden floor drain must be at the lowest
area of the whole finished floor.
Determine the height of prearranged
stub-out according to the diameter of drain
pipe and the height of intended finished
floor.
75423T
1
