- Page 1 Modernlife Touchless 77786K-TF-0 ASIA TSA...
- Page 2 TOUCHLESS SENSOR OPERATION Manual button (Only full flushing) After the last flush, please wait 10 seconds at least for activating sensor again. Please hold your hand within 60mm above the sensor for 1~2 second When the batteries are low, the batteries box will beep 3times when activated. ...
- Page 3 Inside of tank Sensor for half flushing Sensor for full flushing Air pump Air bag for manual button Batteries box Fill valve Flush valve tower...
-
Page 4: Key Parts
Detecting hand → Signal to Air pump →Blow out air to flush valve Air tube connection (FULL FLUSHING) Air tube connection (HALF FLUSHING) Detecting hand → Signal to Air pump →Blow out air to flush valve Key Parts Touchless sensor Air pump box Manual button Full flushing... - Page 5 AIR TUBE CONNECTION (Manual button to Air pump ) AIR TUBE CONNECTION (Air pump to flush valve )
- Page 6 Plate Plate element Sensor_ element Object Positive charge increase Capacitive proximity sensor...
- Page 7 Power connector Connection to sensor (Half) Connection to sensor (Full) Air pump _ DC 3V Air pump...
- Page 8 Batteries _ Alkaline Battery 1.5V (D size) X 2 EA...
-
Page 9: Seat & Cover
SEAT & COVER AAA X 2EA Nightlight will turn on 40s when seat is in dark surrounding and sensing sound 2 x AAA batteries will work around 3~6 months. The nightlight will flash when batteries power is low. SCENT PACK will work around 1~3 months. Please order and replace SECNT PACK in time. ( 7731T-B-NA /7766T-B-NA/7729T-B-NA)
