- Page 1 INSTALLATION AND TECHNICAL INFORMATION LUX SERIES...
-
Page 2: Important Safety Instructions
ALLURE Architectural assumes no responsibility for claims arising from improper or careless installation or handling of its products. IMPORTANT SAFETY INSTRUCTIONS 1. Make sure power is turned OFF before installing. 2. Inspect fixture for any damages. If damaged, DO NOT install fixture and contact local ALS distributor immediately. ALLURE ARCHITECTURAL ALLURE ARCHITECTURAL... -
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS QUICK MOUNT 1. Install Canopy J-Box (sold separately) at power feed location per final/ 2. Canopy Fittings may be installed directly into framing with appropriate record drawing. hardware. 3. Route Suspension Cable through Suspension Bullet. Ball end should 4. -
Page 4: Wiring Diagrams
INSTALLATION INSTRUCTIONS 5. Adjust fixture until it is level and at desired height. De-press top of 6. Cut excess cable. Cable Gripper to lower fixture. Keep fixture supported while lowering. 7. Mount canopy bracket to the J-box and make wiring connection. 8. - Page 5 INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS SURFACE MOUNT 1. Install J-Box (sold separately) at power feed location per final/ 2. Secure the first surface mount bracket to the ceiling with 2 screws at record drawing. desired location. 3. The second surface mount bracket needs to be installed according to the chart under “B”. ALLURE ARCHITECTURAL ALLURE ARCHITECTURAL 14750 East Nelson Ave #B...
- Page 6 INSTALLATION INSTRUCTIONS 5. Align the fixture’s brackets to the surface mounting brackets on the 4. Lift the fixture up toward the ceiling, and make the wire connection. ceiling, and insert the fixture in at an angle, and push it up until it is Ensure Power is OFF prior to connecting wiring.
