- Page 1 INSTALLATION AND TECHNICAL INFORMATION GRID SERIES...
-
Page 2: Important Safety Instructions
ALLURE Architectural assumes no responsibility for claims arising from improper or careless installation or handling of its products. IMPORTANT SAFETY INSTRUCTIONS 1. Make sure power is turned OFF before installing. 2. Inspect fixture for any damages. If damaged, DO NOT install fixture and contact local ALS distributor immediately. ALLURE ARCHITECTURAL 2024 ALLURE ARCHITECTURAL... -
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS GRID INSTALLATION INSTRUCTIONS GRID c á c á ê É = P 1. Loosen the two nuts at the end of the fixture by rotating 2. Install the fixture to ceiling grid and tighten the two terminal nuts counterclockwise. - Page 4 INSTALLATION INSTRUCTIONS GRID 5. Connect the RJ45 connectors from the fixture to the output connector on the junction box. Please note one driver can support max 3 units. WHITE - NEUTRAL GREEN - GROUND BLACK - LOAD 6. Open the junction box, connect the L (Load), N (Neutral), G (Ground) 7.
-
Page 5: Custom Pattern
INSTALLATION INSTRUCTIONS GRID Grid fixtures can be installed in many configurations by replacing any of the cross tees between the main runners of the grid ceiling assembly. SQUARE PATTERN CUSTOM PATTERN A: End with B: End no Power Feed Power Feed Examples of configurations Possible positions for Grid light modules One-piece main runner cannot be replaced...
