Manufactured for Rooms To Go
Thanks for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come
loose inside the carton during shipment. Identify and count all parts and compare with the Hardware List below
PARTS LIST
Item
A
B
C
D
E
Description
Qty
Table Top
1
4
Table Leg
Leg Collecting
1
Ring
Bolt
4
(5/16-18*1.18")
Bolt
4
(5/16-18*1.38")
ASSEMBLY INSTRUCTIONS
ABOL CARINA 24"X42" RECT. COFFEE TABLE
SKU 73000437
Item
F
G
H
I
J
K
L
Description Qty
Flat Washer
8
Lock Washer
8
Nut
4
Nut Cover
4
4
Bolt Cover
1
Wrench
1
Allan Wrench
Advertisement
Related Manuals for ROOMS TO GO PATIO ABOL CARINA 73000437
Summary of Contents for ROOMS TO GO PATIO ABOL CARINA 73000437
- Page 1 ASSEMBLY INSTRUCTIONS ABOL CARINA 24"X42" RECT. COFFEE TABLE Manufactured for Rooms To Go SKU 73000437 Thanks for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose inside the carton during shipment. Identify and count all parts and compare with the Hardware List below...
- Page 2 1. Place the table top (A) upside down on a non-abrasive flat surface. Align the holes in table legs (B) with the holes in the table top (A), Loosely secure table legs (B) to the table top (A) with the short bolt (D) through flat washer (F), lock washer (G) and nut (H).
