ROOMS TO GO SSIO 5077 Assembly Instructions

Manufactured by SSIO for Rooms To Go
*** Caution. Please read all instructions carefully before starting assembly process. These parts are cumbersome
and heavy. Therefore, two people are recommended in order to prevent personal injury and ensure the parts are not
damaged during the assembly.
No. PARTS LIST
A
B
C
D
E
F
G
H
Step 1
Attach Left Stretcher (G) to Left Front Leg (B) and
Left Back Leg (D).
Attach Right Stretcher (H) to Right Front Leg (C) and
Right Back Leg (E).
G
D
E
CLEANING INSTRUCTION: Clear with a soft and warm water with a diluted mild detergent.
Follow with a soft cloth and clear water rinse. Then dry throughly with a soft cloth
Hardware pack location
5077 - AC ARM CHAIR - SKU#: 42650778
ASSEMBLY INSTRUCTIONS
SSIO 5077 - AC ARM CHAIR - SKU#: 42650778
1
Chair Seat Cushion
Left Front Leg
1
Right Front Leg 1
Left Back Leg
1
Right Back Leg
1
Center Stretcher
1
Left Stretcher
1
Right Stretcher
1
B
H
C
No. HARDWARE LIST
Lock Washer Ø5/16" x 13mm
1
Flat Washer Ø5/16" x 19mm
2
3
4
5
Step 2
Attach Legs in step 1 to Chair Seat Cushion (A).
A
D
E
H
MADE IN VIETNAM | Page 1 of 2
Version #1 - 2024/05/15
8
Bolt Ø5/16"-18 x 50mm
8
8
Allen Key 4mm
1
Screw Ø4 x 40mm 4
Screw Ø4 x 30mm 2
Phillips Screwdriver
1
(not included)
B
G
C
