Identify all parts packed in the carton against the parts list. Remove all protective
materials. Place parts on a non-abrasive surface to avoid scratching.
Do Not Attempt Assembly If Any Parts Are Missing Or Damaged.
Warning: Please do not use acid or alkaline washing liquid to clean the product.
Assemble the product as shown below, step-by-step.
Part List
NO.
SKETCH
DESCRIPTION
A
Support tube
B
Table Top
C
D
Foot Glider
Assembly Instructions
MONTARA COCKTALL TABLE
SKU#73063124
QTY
Leg
2
2
1
4
NO.
SKETCH
DESCRIPTION
AA
(M6*20)
Steel Washer
BB
(Φ14*Φ6.5*1.5)
CC
DD
JWUA
GLA-63127-2648WKD
Made in China
QTY
Bolt
12
12
Bolt cap
12
1
Wrench
1
Advertisement
Table of Contents
Related Manuals for ROOMS TO GO MONTARA 73063124
Summary of Contents for ROOMS TO GO MONTARA 73063124
- Page 1 Assembly Instructions MONTARA COCKTALL TABLE SKU#73063124 Identify all parts packed in the carton against the parts list. Remove all protective materials. Place parts on a non-abrasive surface to avoid scratching. Do Not Attempt Assembly If Any Parts Are Missing Or Damaged. Warning: Please do not use acid or alkaline washing liquid to clean the product.
- Page 2 STEP 1 Hand tighten nut 3-4 revolutions only,Do not tighten all the bolts and nuts. STEP 2 Hand tighten nut 3-4 revolutions only,Do not tighten all the bolts and nuts.
- Page 3 STEP 3 Need two people turn the Table right side up.Adjust the pre-installed foot glider(D) at the end of each Table leg until the Table is level with the ground Securely, Your Table is ready for use.
