ROOMS TO GO PATIO ABOL CARINA Assembly Instructions

42" rnd coffee table

Advertisement

Quick Links

Manufactured for Rooms To Go
Thanks for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come
loose inside the carton during shipment. Identify and count all parts and compare with the Hardware List below
PARTS LIST
Item
A
B
C
D
E
F
Description
Qty
Table Top
1
4
Table Leg
Leg Collecting
1
Ring
Umbrella Cover
1
Bolt
4
(5/16-18*1.18")
Bolt
4
(5/16-18*1.38")
ASSEMBLY INSTRUCTIONS
ABOL CARINA 42" RND COFFEE TABLE
SKU 73100439
Item
G
H
I
J
K
L
M
Description
Qty
Flat Washer
8
Lock Washer
8
Nut
4
Nut Cover
4
Bolt Cover
4
1
Wrench
1
Allan Wrench

Advertisement

loading
Need help?

Need help?

Do you have a question about the PATIO ABOL CARINA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ROOMS TO GO PATIO ABOL CARINA

  • Page 1 ASSEMBLY INSTRUCTIONS ABOL CARINA 42" RND COFFEE TABLE Manufactured for Rooms To Go SKU 73100439 Thanks for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose inside the carton during shipment. Identify and count all parts and compare with the Hardware List below...
  • Page 2 1. Place the table top (A) upside down on a non-abrasive flat surface. Align the holes in table legs (B) with the holes in the table top (A), Loosely secure table legs (B) to the table top (A) with the bolt (E) through flat washer (G), lock washer (H) and nut (I).
