LevelPro — ProScan
®
Radar Level Sensor (80GHz)
Safety Information
■ De-pressurize and vent system prior to installation or removal
■ Confirm chemical compatibility before use
■ DO NOT exceed maximum temperature or pressure specifications
■ ALWAYS wear safety goggles or face-shield during installation and/or service
■ DO NOT alter product construction
Warning | Caution | Danger
Indicates a potential hazard. Failure to follow all warnings may lead to equipment damage, injury, or
death.
Note | Technical Notes
Highlights additional information or detailed procedure.
Hand Tighten Only
Over tightening may permanently damage product threads and lead to failure.
Personal Protective Equipment (PPE)
Always utilize the most appropriate PPE during installation and service of Truflo products.
Specifications
Measuring Performance
Minimum Range
Maximum Range
Resolution
Beam Angle
Response Rate
Measurement Accuracy
Repeatability
Housing & Mounting
Housing Material GFPP Body
Dimensions 93mm x 190mm
Installation 2" NPT
25-0724 © Icon Process Controls Ltd.
2 Series
®
8"
34' | 10m
0.04" | 1mm
8°
1.1 Sec
> 0.1% | 0.16" | 4mm
±0.11" | ±3mm
| PTFE Antenna
| 150lb ANSI Flange
Operating Conditions
Operating Frequency Band
Mains Power Supply
Communication Interface
Enclosure Protection
Vacuum | Pressure
Operating Temperature Range
316 SS+GFPP Body | PTFE Antenna Epoxy Coated CI + 316 SS Body
93mm x 207mm
WARNING
80 GHz
24 VDC 2-wire loop powered
4-20mA | RS485 | HART
NEMA 4X | IP66
-
14.5Hg | -362PSI
-40ºF – 250ºF | -40ºC – 121ºC
96.5mm x 221mm
| PTFE Antenna
