ICON LevelPro ProScan 2 Series Quick Start Manual page 12

LevelPro — ProScan
®
Radar Level Sensor (80GHz)
STEPS
LCD Contrast
6
Percent Current
7
BK
Home Screen
8
Model Selection
ProScan 2 — Radar Level Transmitter
®
Connection Part Number
NPT PS28000
Flange PS28500
NPT
PS28000S
Flange PS28500S
25-0724 © Icon Process Controls Ltd.
2 Series
®
DISPLAY
▶
Sensor Unit
Temp. Unit
Language
LCD Contrast
Percent Current
OK
LCD Contrast
100
▶
Sensor Unit
Temp. Unit
Language
x3
LCD Contrast
Percent Current
OK
Percent Current
Closure
Open
▶
31.9157
31.916
11.489mA
28.0°C
LEVELPRO
Body Material
GFPP
GFPP
Epoxy Coated Cast Iron + 316SS
Epoxy Coated Cast Iron + 316SS
LCD Contrast
Adjust the display contrast as required
Percent Current
The Home Screen displays real-time level in either
Percentage (Open Mode) or Distance/Level Value
(Closure Mode).
Factory Default : Closure
Home Screen
in
0000
Antenna Material
PTFE Teflon
®
PTFE Teflon
®
PTFE Teflon
®
PTFE Teflon
®
OPERATION
12
