Questions, problems, missing parts?
Before returning to your retailer, call our customer service at 1-855-508-3883 or
email us at: service@zoneledlighting.com Monday - Friday 9:00 a.m. - 5:00 p.m. CST
PACKAGE CONTENTS
HARDWARE CONTENTS:
A
Plas�c Screw Cover
x1
D
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install the product.
WARNING
·
Turn off electrical power at fuse or circuit breaker box before wiring product to the power supply.
Verify voltage is 120V before installing.
·
Make all electrical and grounded connections in accordance with the National Electric Code and any applicable local code requirements.
·
·
All wiring connections should be capped with UL listed wire connectors to ensure safety and compliance.
·
Suitable for use in temperatures ranging between -13° to 122° F (-25° C - 50° C).
CAUTION
•
Never connect fixture with power on.
•
Do not mount or support product in a manner that can cut the outer wire jacket or damage the wire insulation.
·
Avoid covering LED products with insulation, foam, or other materials that could prevent convection or conduction cooling.
Never connect a LED product directly to dimmer, occupancy sensors, timing devices, or other related control devices,
·
unless individual product specifications allow it.
·
LED products are polarity sensitive, ensure proper polarity before installation.
B
Moun�ng Cross Bar
E
x1
3000LM Dual Head Motion CCT
Stainless Steel Screw
x1
F
Wire Nuts
x2
SKU Number: 3569619
Security Light
Model Number: Z-3SH-MA-BLK
Z-3SH-MA-WH
HARDWARE SHOWN-NOT ACTUAL SIZE
C
Gasket (Installa�on op�onal)
x1
Moun�ng Screws
x2
3569620
Rev1_10302024
Advertisement
Related Manuals for Patriot Lighting Z-3SH-MA-BLK
Summary of Contents for Patriot Lighting Z-3SH-MA-BLK
- Page 1 SKU Number: 3569619 3569620 3000LM Dual Head Motion CCT Security Light Model Number: Z-3SH-MA-BLK Z-3SH-MA-WH Questions, problems, missing parts? Before returning to your retailer, call our customer service at 1-855-508-3883 or email us at: service@zoneledlighting.com Monday - Friday 9:00 a.m. - 5:00 p.m. CST...
- Page 2 PREPARATION Before assembly, installation or operation of product, make sure all pats are present. Compare parts with package contents list and diagram on previous page. lf any part is missing or damaged, do not attempt to assemble, install or operate the product. Contact customer service for replacement parts.
- Page 3 ADJUSTING YOUR LIGHT HEADS Your light heads can be adjusted by turning the individual light head to desired position horizontally or vertically. **SPECIAL ATTENTION: MOTION SENSOR SENSITIVITY** ● The sensor is affected by brightness, temperature, and moving objects. ● Do NOT install near other sources of light, as this can affect motion sensor detection. Significant temperature changes may cause sensor malfunctions, so avoid placing the sensor near vents, heat exhausts or AC units.
- Page 4 PRODUCT WARRANTY FIVE-YEAR LIMITED WARRANTY: If, during normal use, this PATRIOT LIGHTING lighting fixture breaks or fails ® due to a defect in material and workmanship within five (5) years from the date of original purchase, simply bring this lighting fixture with the original sales receipt back to your nearest MENARDS retail store.
