Questions, problems, missing parts?
Before returning to your retailer, call our customer service at 1-855-508-3883
Monday – Friday 8:00 a.m. – 5:00 p.m. CST
PACKAGE CONTENTS
ASSEMBLY INSTRUCTIONS
Please read and understand this entire manual before attempting to assemble, operate or install the product.
1. Install the mounting stake (C) into the solar panel mounting bracket(A), then slide the
mounting bracket(A) into the bottom of the solar panel unit(B). (Figure 1.)
2. Position the solar panel by gently pushing the mounting stake into the ground.
3. The solar panel requires 6hrs of light for full charge. It will have 6-8 operating hours from one full charge.
4. The solar panel includes ON/OFF and 8 functions (MODE). (Figure 2.)
1
A
C
B
SKU Number: 346-2131
32' 9-3/4'' Flexible Rope Light
Model Number: Z-SRL-RGB-10M
Z-SRL-WW-10M
B
Solar Panel
A
Mounting Bracket
C
Mounting Stake
2
B
M
ODE
ON/OFF
Ｐ Ｓ
Ｅ
MADE IN CHINA
346-2132
