Yale Code
Keyed YED210
Trusted Every Day
™
Install Your Lock
Follow the step-by-step Installation Guide in this manual (pages 8-19).
Installation should be completed with the door open
to easily gain access to both sides of the door.
Set Up and Use Your Lock
Create and store up to 20 entry codes, lock with one touch,
use Auto-Lock and more (pages 20-27).
YED210-MNL-0038 Rev B

Advertisement

loading
Need help?

Need help?

Do you have a question about the Code YED210 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Yale Code YED210

Summary of Contents for Yale Code YED210

  • Page 1 Yale Code ™ Keyed YED210 Install Your Lock Follow the step-by-step Installation Guide in this manual (pages 8-19). Installation should be completed with the door open to easily gain access to both sides of the door. Set Up and Use Your Lock Create and store up to 20 entry codes, lock with one touch, use Auto-Lock and more (pages 20-27).
  • Page 2 YED210-MNL-0038 Rev B...
  • Page 3 If printed from electronic file, measure ruler to check scale. Set print scale to 1:1. Door Checker Part 1 See Reverse for Part 2 Measure Clearance Measure Door Thickness Measure Backset Greater than A A, B or C Equals D or E Less than B or Less than A Doesn’t equal D nor E...
  • Page 4 If printed from electronic file, measure ruler to check scale. Set print scale to 1:1. Door Checker Part 2 See Reverse for Part 1 Measure Face Bore Measure Edge Bore and Strike Pocket Equals F or G Equals H Door (Edge Bore) Frame (Strike Pocket)
  • Page 5 Marking Template for 2-1/8” (54mm) Face Bore 1-3/4” (44.5mm) 2-3/4” (70mm) Center of 2-1/8” (54mm) Face Bore Door Thickness Backset Center of 1” (25mm) Edge Bore Centerline Center of 1” (25mm) Edge Bore 1-3/8” (35mm) 2-3/8” (60mm) Center of If printed from electronic file, measure ruler to check scale.
  • Page 6 Marking Template for 1-1/2” (38mm) Face Bore 1-3/4” (44.5mm) 2-3/4” (70mm) Door Thickness Backset Center of 1-1/2” (38mm) Face Bore Center of 1” (25mm) Edge Bore Centerline Center of 1” (25mm) Edge Bore Center of 1-1/2” (38mm) Face Bore 1-3/8” (35mm) 2-3/8”...
  • Page 7 In the Box Lock Hardware 1. Exterior Keypad 2. Interior Lock 3. Strike Plate 4. Adjustable Deadbolt & Key 5. Mounting Plate 6. Manual 7. Screws a. Strike Plate and Deadbolt Screws b. Black Screw Set c. Optional Security Strike Plate Screws YED210-MNL-0038 Rev B...
  • Page 8 Installation Guide Required Tools You Might Also Need 1. Phillips Head Screwdriver 2. Door Checker (tear off pages 3-4 of this manual) 3. Tape Measure 4. Drill 5. Marking Template (tear off pages 5-6 of this manual) 6. Pencil Door Checker Part 1 7.
  • Page 9 Remove Existing Deadbolt If you have a new door, please proceed to step 1b. If you have a deadbolt on your door, use the diagram to help you remove it. Frame Door Keep your old deadbolt until your new lock has been successfully installed. YED210-MNL-0038 Rev B...
  • Page 10 Check Door Measurements If your door doesn’t have holes, please proceed to step 1c. Tear off the Door Checker (pages 3-4) and follow the guidelines on both sides to If you need to make adjustments, go to measure each aspect of your door and frame. There are some cases when existing step 1c and find the closest match to each holes cannot be adjusted to be compatible.
  • Page 11 Make or Adjust Holes Skip this step if you have confirmed that the existing holes are compatible (step 1b). 1. Tear off the Marking Template (pages 5-6), and choose the preferred face bore 5. Drill holes in your door where marked. diameter (2-1/8”...
  • Page 12 Install Deadbolt Latch 1. Correct deadbolt length is based on the backset. Refer to measure- 3. Make sure UP arrow on the deadbolt is facing upwards. ments D and E on the Door Checker (page 3) to verify backset. 4. Deadbolt latch must be in an unlocked position. Note: If the deadbolt latch is extended, use a small flathead 2-3/8”...
  • Page 13 Install Exterior Keypad 1. Refer to measurement G on the Door Checker (page 4) to measure face bore hole. 5. Slide the keypad in place, making sure it’s on the If the hole is less than 2-1/8”, remove plastic adapter by applying pressure to the exterior part of your door.

  • Page 14: Install Mounting Plate

    Install Mounting Plate 1. Route the wire cable into the designated slot in the mounting plate. 2. Slide tailpiece through the designated slot in the mounting plate. 3. Tighten screws with a screwdriver to secure the mounting plate. As you tighten the screws, make sure the mounting plate and the exterior keypad are straight.
  • Page 15 Attach Wire Cable to Interior Lock 1. Remove battery cover by pulling it upwards off the body of the interior lock. 2. Make sure the tab on the cable end and the marked line faces outward. 3. Push cable into the designated slot until you hear a click. YED210-MNL-0038 Rev B...
  • Page 16 Determine Lock Handing If your door is left handed, your thumbturn is on the left. If your door is right handed, your thumbturn is on the right. For your lock to function properly, we need to determine which Left Hand Right Hand direction to rotate the thumbturn.
  • Page 17 Install Interior Lock 1. Make sure thumbturn is positioned correctly for your hand of door. Refer to step 6 (page 16) for guidance on how to determine it, if needed. 2. Make sure the tailpiece is in a horizontal position. Slide the tailpiece through the designated slot on the back of the thumbturn.
  • Page 18 Test Thumbturn and Key If deadbolt latch does not lock or unlock with the key (from the outside) or the thumbturn (from the inside): • Ensure that the deadbolt latch is centered in the face bore hole; • Ensure that the tailpiece is inserted through deadbolt latch slot; step 3, point 3 (page 13) into the thumbturn slot;...
  • Page 19 Install Batteries* and Set Up an Entry Code 1. Before installing batteries, make sure the deadbolt latch is unlocked. 4b. Re-enter the code, then press the Yale logo. If the code matches the one from step 4a, the status LED will flash 2.
  • Page 20 Using Your Lock Exterior Keypad Interior Lock 1. Status LED Indicator To lock your door 2. Wake / One-Touch Locking Press 3. Toggle Features* a. Lock Handing b. Audio Mode c. Auto-Lock To unlock your door 4. Mode Button 5. Thumbturn Press Enter entry code Press...
  • Page 21 LED Alerts Factory Reset Press the Yale logo to wake up the lock, then press and hold the Mode Status LED turns steady yellow Initial Setup Mode button under the battery cover on the interior side until the status LED...
  • Page 22 See step 9, point 4 (page19) for instructions on how to set up your first entry code. You can store up to 20 entry codes that are 4-8 digits long. 1. With the door open, extend the deadbolt, and press the Yale logo, then 2b. Re-enter the code, then press the Yale logo. If the code...
  • Page 23 Delete Entry Codes 1. With the door open, extend the deadbolt, and press the Yale logo, then 2b. Re-enter the code, then press the Yale logo. If the code press the Mode button under the battery cover on the interior side matches the one from step 2a, the status LED will flash twice.
  • Page 24 · Automatically lock the deadbolt after its been unlocked for 30 seconds. One Touch Locking · Lock your door with one touch by pressing the Yale logo on the lock. · The keypad will be disabled for 60 seconds after five consecutive invalid codes.
  • Page 25 Lock Operations Troubleshooting · Press the Yale logo to activate the keypad. · Verify contact with the logo. Lock does not respond. · Check batteries are installed and oriented correctly in battery case. Replace batteries if needed. · Check that the keypad wire is fully connected and not pinched.
  • Page 26 · Verify that your entry code consists of 4 to 8 digits. Entry code will not register. · Entry code must be entered while the keypad is in Setup Mode. For the first entry code, press Yale logo to re-enter Setup Mode. For additional entry codes, see page 22.

  • Page 27: Hardware Troubleshooting

    Hardware Troubleshooting Deadbolt is jamming. In a jamming · After a jam, using the thumbturn or key to unlock the door may require additional pressure. After the deadbolt situation, the deadbolt will try to extend is in unlocked position, it should be smooth to operate. To avoid future jamming issues see the below three times before status LED flashes red, troubleshooting steps.
  • Page 28 24/7 Support: 1-855-213-5841 • US.YaleHome.com Yale® is a registered trademark and Yale Code™ is a trademark of Master Lock Company LLC and its affiliates. Other products’ brand names may be trademarks or registered trademarks of their respective owners and are mentioned for reference purposes only. ©Copyright 2024. All rights reserved.
