WiMiUS Q3 Manual

PACKAGE LIST

PRODUCT STRUCTURE

PRODUCT STRUCTURE

REMOTE CONTROL

REMOTE CONTROL

warning Note: Install 2 pieces of AAA batteries(not included) into the remote before using.

PROJECTOR SPECIFICATIONS

Model No.: Q3
Display Technology DLP Light Source LED
Software System Android 11 Projector Type Seale
Installation Type Front/Rear on Desk,
Front/Rearon Ceiling
Aspect Ratio 16:9/4:3
Product Size 12cm*12cm*2.8cm Product Weight 350g
Keystone Correction Auto vertical correction Focus Manual
Input Interface HDMI/USB*2/3.5mm audio output
Video Format H.264,H.265,Vp9,MPEG1,MPEG2,MPEG4,H.263,XVID,VP8, etc
Audio Format MP3,OGG,FLAC,APE, etc
Image Format jpg, png, bmp, etc

IMAGE ADJUSTMENT

Focus Adjustment


Slide pinion on the left of the device to adjust sharpness.

Projection Mode

Select [Settings] menu -- Select [Display] -- Select [Projection Mode], Press the projection position you need and press "OK" to confirm.

There are 4 modes: Front projection/Rear front projection/Front ceiling projection/Rear ceiling projection.
IMAGE ADJUSTMENT - Projection Mode

Auto Keystone Correction

Auto Keystone Correction.
Select[Settings]menu -- Select [Display] -- Select [Auto Keystone Correction], and press "OK" to confirm.

The projector can auto adjust the vertical plane to get the rectangle image. The tilted angle doesn't exceed ±30°.
IMAGE ADJUSTMENT - Auto Keystone Correction

Manual Keystone Correction

Select [Settings]menu -- Select [Display] -- Select [Manual Keystone], press "OK" to pick the point you want to adjust at first, and then press press "OK" to pick the point you want to adjust at first, and then press the arrow keys to set the value (Horizontal and Vertical±30°) needed as shown below.
IMAGE ADJUSTMENT - Manual Keystone Correction

Initial Angle Correction

Place the device on the horizontal plane and press the OK to correct it.
Don't move the device during the correction.

Zoom Mode

There are 2 modes of Aspect Ratio: 16:9 or 4:3.
IMAGE ADJUSTMENT - Zoom Mode - Step 1

Select [Settings] menu -- Select [Display] -- Select [Screen Scaling] -- Select [Screen Zoom], the projection screen can be zoomed 50%~100%, Press the button "" or "" to set the value needed.
IMAGE ADJUSTMENT - Zoom Mode - Step 2

Brightness & Color Adjustment

Select [Settings] menu -- Select [ Display] -- Select [Brightness & Colour], select the options you want to adjust.
IMAGE ADJUSTMENT - Brightness & Color Adjustment

Other Setting

Pointer Speed

Select [Settings] menu -- Select [General] -- Select [Pointer Speed], press "" or "" to adjust the mouse pointer move speed you need.
IMAGE ADJUSTMENT - Other Setting - Pointer Speed

Prevention of Accidental Contact

Select [Settings] menu -- Select [General] -- Select [Touch Setting], to choose the period you need, to prevent accidental operation.
Prevention of Accidental Contact

SETTING UP THE PROJECTOR

Select The Input Signal Source

HDMI: Choose the "" at the top of the home page.

When playing a video, you can press the "" button, to set the sound and mode of playback.
SETTING UP THE PROJECTOR - Step 1

USB: The device will detect the USB stick automatically. Click "APPS" on the homepage and select "File Maneger" on the page.
SETTING UP THE PROJECTOR - Step 2

WIRELESS CONNECTION

For IOS System (Airplay)

warning Attention: Your device and the projector should be in the same Home WiFi.

  1. Turn on the Network setting of the projector.
  2. Choose your Home WiFi to connect and enter the right password, then click "OK", please wait 3 seconds to establish the connection.
  3. Once connected, it will remember the password of the connected WiFi.
  4. Turn on the WiFi setting of your mobile device, then connect to the same Home WiFi.
  5. Then click 'Airplay" or 'Miracast" on the smartphone.
  6. Select'Q3-7817" from the search results to connect.
  7. Succeed.
    WIRELESS CONNECTION - For IOS System

For Android System (Miracast)

warning Attention: Your device and the projector should be in the same Home WiFi.

  1. Turn on the Network setting of the projector.
  2. Choose your Home WiFi to connect and enter the right password, then click "OK", please wait 3 seconds to establish the connection.
  3. Click "APPS" on the homepage and select "Miracast Receiver' on the page (or press the "E-share" button on the remote control and select "android Wireless").
  4. Turn on the WiFi setting of your mobile device, then connect to the same Home WiFi.
  5. Turn on the wireless screen mirroring function of your Android phone and select "Q3-7817" from the search results to connect.
  6. Succeed.
    WIRELESS CONNECTION - For Android System

Eshare

Use your phone as the wireless mouse, keyboard, and remote control, and transform the way you control and engage with large screen devices.

  1. Connect your device to Home WiFi.
  2. Use a browser to access "https://h.eshare.app" to download and install the app. the app.
  3. Open the Eshare app and click"Q3 7817" to connect.

BLUETOOTH SETTINGS

Connect Bluetooth Speakers

  1. Turn on your Bluetooth Speaker.
  2. Select [Settings] -- [Bluetooth ] to turn on the projector's Bluetooth
  3. Select your Bluetooth speaker to connect.
  4. Succeed.
    BLUETOOTH SETTINGS - Connect Bluetooth Speakers

SIGNAL LINES CONNECTION

WiMiUS Q3 projector has 3 interfaces, HDMI ports/USB ports/3.5mm headphone output. Please select the correct connecting port to connect your device (PC, Phone, DVD Player, Soundbar, USB, PS4, etc.)

Connecting with Laptop

  • Connect the projector with PC by HDMI cable.
  • Choose the media signal channel:"HDMI".

Connecting with MacBook or Mac Book Air

  • Choose the media signal channel:"HDMI".
  • Use a Type-C to HDMI adapter to connect your MacBook, or a Mini Display to HDMI adapter to connect with your MacBook Air (adapter not included).

Connecting with Sound bar

  • Use the 3.5mm audio cable coming with the projector to connect with sound bar.
  • Turn on the projector and the sound bar(choose AUX mode).
  • For more details, please contact the seller at support01@wimius.com.
    SIGNAL LINES - Connecting with Sound bar

Connecting with Fire TV Stick

  • Plug the TV stick into the HDMI port of the projector.
  • Choose the media signal channel:'HDMT.

Connecting with XBOX/PS4

  • Choose the media signal channel:"HDMI'.
  • Use HDMI cable to connect to XBOX/PS4.

App Download

Click "APPS" on the home page and select "App Store" on the page.

  1. Select your favourite app to download on the App Store homepage.
  2. Search for the app you want to download in the search bar.
    App Download

LANGUAGE SETTING

There are more than 50 languages to choose from, English, French, to choose from, English, French, German, Italian, Spanish, Japanese, etc.

  • Select [Settings] -- [System] -- [Language], choose the language you need.
    LANGUAGE SETTING

OTHER SETTING

Application Setting

  • In the other settings menu, you can find the "Application Setting" option, click it to view all installed applications and configure them.

Location: [Settings] -- [General] -- [App Settings].

Factory Reset Setting

  • Reset and delete all data

Location: [Settings] -- [System] -- [Factory Reset].
OTHER SETTING - Factory Reset Setting

System Info

Check the projector's software version number, serial number, memory and other information.
OTHER SETTING - System Info

DATE AND TIME SETTING

Setting Function
Time Zone Select your time zone
Date Select current date
Time Select current time

SYSTEM UPGRADE

When new software is available for upgrade, you can choose local upgrade or online upgrade.
SYSTEM UPGRADE

FAQ

There is no image on the black screen or a blue screen with no picture or sound.

  1. ls the channel set-up correct?
  2. Is there an input signal?
  3. ls the input cable plugged well?
  4. Under PC mode, is the refresh rate > 75KHz?
  5. The input device doesn't connect well with the projector.

Picture right, no sound.

  1. Please turn off the Dolby of the input device, and then it will have sound.
  2. The decoding system of the video is not supported by the projector.

Auto-off after working for a while.

  1. The projector ventilation is blocked.
  2. The voltage is not stable.
  3. The over-heat protection system.

WiFi connection is not stable?

  1. Please check whether the network of your phone is well
  2. Make the distance of the phone and projector within 1 meter.

Not compatible with your Bluetooth speaker?

  1. The projector may not be compatible with some kinds of Bluetooth speakers.
  2. Contact our after-sales email at support01@wimius.com immediately and tell us the brand and model of your Bluetooth speaker.

Black spot or white line on the picture
Contact our after-sales service support01@wimius.com immediately.

Why is the image out of focus no matter how I adjust it?

  1. Place the projector in line with the centre of the screen. (Or the offset angle should be within 15°)
  2. Use Automatic Keystone Correction or Manual Keystone to achieve a rectangular screen display.
  3. Use Manual Focus to adjust lens focus.

Can't access the website successfully to download the application?
Please contact us immediately at our after-sales email address: support01@wimius.com and tell us about the page prompt that appeared during your application download.

What if my order is past the platform return window? Why haven't I received a reply after 24 hours?
The WiMIUS support team will promptly assist with solutions, even if your order is past the platform return window. If no reply within 24 hours, it could be due to time zone differences or your email landing in the spam folder. Please contact us again, we'll ensure your query is addressed promptly.
