- Page 1 Sliding Door TV Unit 457/2170 Width - 117 cm Depth - 35 cm Height - 45.2 cm Issue 1 - 11/09/2015...
- Page 3 Left side Right side (117 x 35 cm) (28 x 26 cm) (28 x 26cm) Bottom Vertical partition Vertical partition (117 x 35 cm) (28x 30 cm) (28x 30 cm) Shelf Drawer front Drawer left side Drawer right side (44.2 x 29.8 cm) (45.7 x 18 cm) (30 x 11.6 cm) (30 x 11.6 cm)
- Page 4 Metal dowel x 10 ( 15x13 ) Locking nuts x 8 ( 12x13 ) Locking nuts x 2 ( 7x50 ) Hexagon bolt x 14 ( 6x30 ) Wooden dowel x 2 ( 8x30 ) Wooden dowel x 26 Runner x 1 ( 6.5x10.5 mm ) Screw x 4 ( 3.5x13 mm ) Screw x 6 ( 8x39 mm ) Screw x 4...
- Page 5 a: Fitting metal dowels Screw metal dowels into Top Panel 1 . Note: Insert metal dowels as far as shown. Do not over tighten. b: Fitting wood dowels Insert wood dowels F into Vertical Partitions 3 and 4 . Insert wood dowels F into Shelf 7 , Leg 14 and Leg 15 .
- Page 6 Fitting wood dowels Insert wooden dowels into the vertikal potitions Insert wood dowels F into Vertical Partitions 5 and 6 . Gently tap the dowels into the components with a hammer if necessary. Attaching runners b: Inserting runners Attach runners (G) to Position runner G Vertical partition panel (5) (6) using screw...
- Page 7 Attaching panels Attaching vertical Finished Front Position partition front edge pertition to the panel 5 and 6 shelf onto shelf with the finished front edge facing up. Finished front edge Finished front edge Front Finished front edge Rear Attaching panels Two people are Attach shelf panel needed here.
- Page 8 Step 5 Attaching side panels Attach Left side panel Attach Right side panel Position Left Side Right Side 4 onto Top Panel 1 Attach Locking nuts as shown. to the hole and use the allen key ( ) to turn locking nuts Insert two locking clockwise to lock.
- Page 9 Step 7 Installing doors Attach Sliding door x2 Fit one door 13 into Put the Sliding door x2 the groove on top fit into the groove line on top panel. panel 1 . Repeat with the remaining door on the other side. Step 8 Step 8 Installing back...
- Page 10 Step 9 Attaching legs Attach Leg Legs 14 and 15 to the bottom panel Bottom Panel 2 Attach ( 7x50 ) Hexagon bolt to the hole and use the allen key Attach Legs 14 to turn locking nuts 15 to Bottom Panel clockwise to lock.
- Page 11 Step 11 Drawer assembly ( 6x30 ) Wooden Insert a: Insert wood dowel into the drawer dowels into left side and drawer Drawer Left Side 9 right side and Drawer Right Side 10 . Metal b: Inserting dowel Gently tap dowels Metal dowel Insert into the components...
- Page 12 Step 11 (cont’d) Drawer assembly d: Slide Drawer a: Attach Drawer back Bottom into to the drawer sides the grooves. ( 8x39 mm ) Screw using e: Position Drawer Back over the assembly. Fix Drawer Back to the Drawer Sides with Screws b: Attach Runner using...
- Page 13 Step 12 Inserting drawers Insert the drawer into the unit, matching the rollers on drawer slides with the slots on the TV Unit runners. Step 15 Step 13 Fixing rear panels Fix rear panel Fit a Back Panel to back of TV stand Connector K using stabilizer and screw...
- Page 14 Step 14 Attaching Cap Fixing caps Attach cap with Cover Cover the screw heads with caps as shown. Assembly is complete.
