ASSEMBLY INSTRUCTIONS
Quadro A Leg
Counter Table
COMPONENTS
A Table top x2
B Leg Quadro A ( Half leg cross beam ) x2
C Intermediate Leg Quadro A (Half leg cross beam ) x1
D Leg wood add on x6
E Leg bottom beam x3
*
F Upper beam x2
G Lower beam x2
H Plastic bracket x8
**
I Feets or Wheels x6
SCREWS
J M8x20MM CSK x12
K M8x20MM socket head x4
L M6x20MM socket head x8
M M6x30MM socket head x8
N Pins x4
O Corner pads x6
P Mushroom head M6x30 x6
Q Allen key x2
*
Colour of the beam is always
black, regardless desk frame colour.
Need help!
Call us on
1300 527 665
