Gas Plancha Grill
Model: TP74-73
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
INSTRUCTION MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the TP74-73 and is the answer not in the manual?

Questions and answers

Summary of Contents for Outsunny TP74-73

  • Page 1 IN241100607V01_UK 846-133V72 Gas Plancha Grill Model: TP74-73 IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY INSTRUCTION MANUAL...
  • Page 2: Exploded Drawing & Parts List

    EXPLODED DRAWING & PARTS LIST...
  • Page 3 Assembly Tighten the screws by hand only during the assembly process, because there must be a certain gap between the various components. Carefully adjust the newly inserted parts to achieve the best results. Two people are recommended to assemble.
  • Page 4 Warnings: Use outdoors only. Model TP74-73 are for table-top, and those model can not put on the combustible materials during use. Read the instructions before using the device. Accessible parts can become very hot. It is therefore essential to keep away from small children.
  • Page 5 1. Technical data Pin no: 1336DL004 Pin no: 1336DM008 1336-24 1336-24 9.6kW(G30:668g/h;G31:656g/h) 9.6kW(G30:668g/h;G31:656g/h) 9.6kW(G30:668g/h;G31:656g/h) Importer MH STAR UK LTD Address: Unit 27, Perivale Park,Horsenden lane South Perivale, UB6 7RH a) Select the regulator you want according to the device category and gas pressure in the table above. Example for propane gas: 37 mBar regulator and device category I3 +.
  • Page 6 2. Assembly steps Make sure to assemble the grill correctly. Each grill contains detailed assembly instructions, and each model has different assembly steps. Please follow the instructions below carefully to ensure that the grill is assembled correctly and safely. Caution: While we do our best to ensure that assembly is as simple as possible, the corners and edges of parts made of steel can cause cuts if improperly handled.
  • Page 7 Instructions for changing your gas cylinder Note: Turn off the switch on the gas cylinder (no tools are required) The gas cylinder must be less than 80 cm high and up to 35 cm wide. Instructions for connecting a gas cylinder a) Rotate the orange cap so that the arrow points to the gap in the hood.
  • Page 8 j) We advise you never to leave the gas grill unattended while in use. After using the gas grill, switch off the gas supply on the gas. k) The gas grill should be cleaned after use. Do not block the gas cylinder compartment vent. If the venti- lation opening is blocked, please clear it with a round rod (diameter 1.6 mm).
  • Page 9 7. Instructions for igniting Caution: The top lid must be open when the burner is lit. Do not bend your face directly over the gas grill when lighting. Your gas grill is lit using the following method: Ignition with pilot flame (main burner or main burner with side burner): All gas control elements of the gas grill must be in the "OFF"...
  • Page 10 9. Cleaning instructions We recommend servicing or cleaning your gas grill every 90 days, but at least once a year. This will extend the life of your gas grill. Your gas grill can be easily cleaned with minimal effort if you follow the tips below. -10-...
  • Page 11 If the above information does not solve your problem, please contact your local gas trader. a) Turn off the burner for 15 to 20 minutes. Make sure the device has cooled down before you continue. b) Regularly clean cooking grids by soaking them and washing them in soapy water. c) The inner surfaces of the grill housing lids must also be washed with hot soapy water.
  • Page 12 10. Safety instructions for the gas grill Place your gas grill on a level and stable surface away from flammable objects such as fences or over- hanging branches. Never use your gas grill indoors! Once lit, your gas grill must not be moved or left unattended. Keep children and pets at a safe distance from the gas grill.
  • Page 13 IMPORTER ADDRESS: Importador/REP: MH STAR UK LTD Spanish Aosom, S.L. Unit 27, Perivale Park, C/ Roc Gros, nº 15. 08550, Els Hostalets de Balenyà, Horsenden lane South Spain. Perivale, UB6 7RH B66295775 MADE IN CHINA HECHO EN CHINA Importé par/REP : MH France 2, rue Maurice Hartmann 92130 Issy-les-Moulineaux...
