PANCONTROL PAN 200A+ Operating Manual

Operating manual
PAN 200A+
Intelligent digital clamp meter
C
ONTENTS
1. Introduction ............................................................................................ 1
2. Scope of delivery .................................................................................... 1
3. Safety Instructions .................................................................................. 1
4. Symbols Description ............................................................................... 2
5. Panel Description .................................................................................... 2
6. Symbols of the Display ............................................................................ 2
7. General Specifications ............................................................................ 2
8. Operating Instructions ............................................................................ 3
9. Maintenance ........................................................................................... 4
10. Guarantee and Spare Parts ..................................................................... 4
1. Introduction
Thank you for purchasing PANCONTROL. Since 1986, the PANCONTROL brand has
stood for practical, innovative and professional measuring instruments. We hope you
enjoy using your new product and we are convinced that it will serve you well for many
years to come.
Please read this operating manual carefully before using the device to become familiar
with the proper handling of the device and to prevent faulty operations. Please follow
all the safety instructions. Nonobservance cannot only result in damages to the device
but in the worst case can also be harmful to health.
The PAN 200A+ is an intelligent current measuring plier. It can automatically detect
incoming signals without the user having to select a measurement function or a
measuring range.
Functions: Alternating current, alternating voltage, DC voltage, frequency, resistance
and continuity test
2. Scope of delivery
After unpacking please check the package contents for transport damage and
completeness.
•
Measurement device
•
Test leads
•
Operating manual
3. Safety Instructions
To ensure the safe use of the device, please follow all the safety and operating
instructions given in this manual.
• Before using the device, make sure that test leads and the device are in good
condition and the device is working properly (e.g. by connecting to known voltage
sources).
• The device may not be used if the housing or the test leads are damaged, if one or
more functions are not working, if functions are not displayed, or if you suspect that
something is wrong.
• If the safety of the user cannot be guaranteed, the device may not be operated and
secured against use.
• While using this device, hold the test leads only behind the finger guards - do not
touch the probes.
• Never ground yourself while making electrical measurements. Do not touch any
exposed metal pipes, fittings etc., which could have a ground potential. Ensure that
your body is isolated by using dry clothes, rubber shoes, rubber mats or other
approved insulation materials.
• Operate the device in a way that it is not difficult to operate the network separators.
• Never connect the device to voltage or current sources that exceed the specified
maximum values.
• Do not use the device in any higher category than allowed.
• If the battery symbol appears in the display, replace the battery immediately.
• Always switch off the appliance and remove the test leads from all voltage sources
before opening the device to exchange the battery or the fuse.
• Never use the device with the rear cover removed or with the battery and fuse
compartment open!
• Do not use the device near strong magnetic fields (for e.g. welding transformer), as
this can distort the display.
• Do not use the device outdoors, in humid surroundings or in environments that are
subjected to extreme temperature fluctuations.
• Never use the device in an explosionprone environment.
• Do not store the device in places which are exposed to direct sunlight.
• Remove the battery if the device is not used for a long time.
• If changes or modifications are made to the device, the operational safety is no
longer guaranteed and the warranty becomes void.
