Packing List
In addition to this guide, the package includes the following items:
ECAT-2601 Module x 1
Technical Support
service@icpdas.com
www.icpdas.com
For Desktop Web
Technical support:
ECAT-2601 Series Quick Start
Resources
How to search for drivers, manuals and
spec information on ICP DAS website.
For Mobile Web
Model Name
Model Name
service@icpdas.com
Quick Start x1 (This Document)
V1.0, Jan. 2025
P1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ICP DAS USA ECAT-2601 Series
Summary of Contents for ICP DAS USA ECAT-2601 Series
- Page 1 ECAT-2601 Series Quick Start V1.0, Jan. 2025 Packing List In addition to this guide, the package includes the following items: ECAT-2601 Module x 1 Quick Start x1 (This Document) Resources How to search for drivers, manuals and Technical Support spec information on ICP DAS website.
-
Page 2: Connecting The Power And Host Pc
Connecting the Power and Host PC 1) Make sure your PC has workable network settings. Disable or well configure your Windows firewall and Anti-Virus firewall first, else the “Search Servers” on Chapter 5 may not work. (Please contact with your system Administrator) 2) Connect both the ECAT-2601 and your PC to the same sub network or the same Ethernet switch. -
Page 3: Wiring Notes
Installing Software on Your PC Install eSearch Utility, which can be obtained from the web site: https://www.icpdas.com/en/download/index.php?nation=US&kind1=&model=&kw=esearch Wiring Notes Wiring Notes for RS-485/422 Interfaces: Here, the RS-485 and RS-422 wiring is used as an example. RS-485 Wiring RS-422 Wiring RS-422 RS-485 GW-25xx... -
Page 4: Configuring Network Settings
Connecting the Modbus and EtherCAT Devices 1) Connect the Modbus Master (e.g., PC, PAC, PLC) via the Ethernet or COM1 port on ECAT-2601 module. 2) Connect the EtherCAT device (e.g., ECAT-2060, optional) to the EtherCAT port on ECAT-2601 module. (ETH3) 3) Supply power (PoE or +12~+48 VDC) to the ECAT-2601. - Page 5 Default Settings of ECAT-2601: IP Address Subnet Mask Gateway User Name Password 192.168.255.1 255.255.0.0 192.168.0.1 Admin Admin Contact your Network Administrator to obtain a correct network configuration (such as IP/Mask/Gateway). Enter the network settings and click “OK”. Note: The ECAT-2601 will use the new settings 2 seconds later. ...
- Page 6 User Name : Admin password : Admin 8) Enter the Username and password in the login password field. Technical support: service@icpdas.com...
- Page 7 Configuring the EtherCAT Port 1) Click the “EtherCAT” tab to display the “MainDevice Configuration” page. 2) Select the “Cycle Time” from the relevant drop down options. 3) Click “New” to sartup entry for SDO. Technical support: service@icpdas.com...
- Page 8 Self-Test 1) In the eSearch Utility, select the “Modbus TCP Master” item from the “Tools” menu to open the Modbus TCP Master Utility. 2) In the Modbus TCP Modbus Utility, enter the IP address of ECAT-2601 and click “Connect” to connect the ECAT-2601. 3) Refer to “Protocol Description”...
