Inspecting Battery Condition
Inspecting Battery Condition and Cleaning
Proceed as follows to inspect and clean battery:
1. See Figure 3-3. Verify top of battery is clean and
dry. Dirt and electrolyte on top of the battery can
cause battery to self-discharge. Clean battery top
with a solution of baking soda (sodium bicarbonate)
and water (5 teaspoons baking soda per quart or
Liter of water). Rinse off battery with clean water
when solution stops bubbling
2. Clean cable clamps and battery terminals using a
wire brush or sandpaper to remove any oxidation.
3. Inspect battery screws, clamps, and cables for
breakage, and for loose connections and corrosion.
Tighten and clean as necessary.
4. Inspect battery posts for melting or damage caused
by over tightening.
5. Inspect battery for discoloration, raised top, or a
warped or distorted case, which may indicate bat-
tery has been frozen, overheated, or overcharged.
6. Inspect battery case for cracks or leaks.
7. Verify battery state of charge. See
of Charge.
8. Replace battery if necessary. See
Battery.
Verifying State of Charge
Verify the state of charge using a digital multimeter. Re-
charge and retest if state of charge is below manufactur-
er's recommendations. Replace battery if necessary.
Replacing Battery
Removing Battery
WARNING
Electrical shock. Disconnect battery ground
terminal before working on battery or battery
wires. Failure to do so could result in death
or serious injury.
WARNING
Accidental Start-up. Disconnect the negative battery ca-
ble, then the positive battery cable when working on unit.
Failure to do so could result in death or serious injury.
Proceed as follows to remove battery:
1. Remove negative battery cable (black) from nega-
tive (-) battery terminal.
Spark-Ignited Stationary Generators Owner's Manual
2. Remove positive battery cable (red) from positive
3. See
Figure 5-11.
4. Loosen two screws with nylon washers to release
Verifying State
5. Grasp battery strap (B), and lift battery from battery
Replacing
6. Remove rubber protective cover from positive (+)
Installing Battery
Accidental Start-up. Disconnect the negative battery ca-
ble, then the positive battery cable when working on unit.
Failure to do so could result in death or serious injury.
Proceed as follows to install battery:
1. Install rubber protective cover over positive (+) bat-
2. Grasp battery strap (B) and lift battery.
3. Set battery onto battery tray.
(W000164)
4. Tighten two screws with nylon washers to secure
(W000130)
(+) battery terminal.
Figure 5-11. Install rubber protective cover
over positive (+) battery terminal (A).
Figure 5-11. Remove / Install Battery
battery hold-down clamp from battery tray.
tray.
battery terminal.
WARNING
tery terminal (A).
hold-down clamp to battery tray.
Maintenance
B
A
001499
(W000130)
