Low Profile Canton TV Stand
Stock # BHF336158813001 (Black/Walnut)
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions
and parts list ready to provide the model name, part name or factory number:
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
# BHF336158813002 (Off white/Walnut)
ADULT ASSEMBLY REQUIRED
1-866-942-5362
www.whalenstyle.com
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2023-10-10
LOT NUMBER:
DATE PURCHASED:
Rev. 0001-A
/
/

Advertisement

loading
Need help?

Need help?

Do you have a question about the BHF336158813001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Better Homes and Gardens BHF336158813001

Summary of Contents for Better Homes and Gardens BHF336158813001

  • Page 1 LOT NUMBER: DATE PURCHASED: Low Profile Canton TV Stand Stock # BHF336158813001 (Black/Walnut) # BHF336158813002 (Off white/Walnut) ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our customer service number and have your instructions...
  • Page 2 IMPORTANT Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non-abrasive surface. You will need the parts identified on page 3 and 4 of this instruction manuals. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH DOWELS. EXCESS GLUE CAN BE WIPED OFF WITH DAMP CLOTH.
  • Page 3 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Panel B- Left Side Panel C- Partition Panel (Qty. 1) (Qty. 1) (Qty. 1) D- Right Side Panel E- Bottom Panel F- Bottom Front Skirting (Qty.
  • Page 4 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. (1) Cam Lock (2) Cam Bolt (3) M8 x 30 mm Wood Dowel (Qty. 20+1 extra) (Qty. 20+1 extra) (Qty.
  • Page 5 Assembly Instructions ② x 8 NOTE: Please do not fully tighten all screws and bolts until you finish assembling all parts. Once assembled, go back and fully tighten all screws and bolts. This will make the assembly easier. 1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty carton to avoid any scratch.
  • Page 6 Assembly Instructions ③ x 11 3. Glue eleven Wood Dowels (3) into the designated holes on the Bottom Panel (E), Skirtings (F and G) and Bottom Middle Support (H). Make sure that you use a small amount of glue with both ends of all dowels.
  • Page 7 Assembly Instructions The cam locks face inward. ① x 4 4. Orient and attach the Bottom Front Skirting (F) to the Bottom Panel (E) by engaging four Cam Locks (1). (Refer to page 2 on Cam Lock system operation supplement).
  • Page 8 Assembly Instructions ① x 1 5. Orient and attach the Bottom Middle Support (H) to the Bottom Front Skirting (F) by engaging one Cam Lock (1).
  • Page 9 Assembly Instructions ① x 3 6. Repeat the same procedure to attach the Bottom Back Skirting (G) at the opposite end.
  • Page 10 Assembly Instructions ④ x 2 7. Insert two 38 mm Screws (4) through the Bottom Back Skirting (G) and securely screw into the Bottom Middle Support (H).
  • Page 11 Assembly Instructions ② x 6 8. Securely screw six Cam Bolts (2) into the designated small holes on the Panels (B and D) with a Phillips screwdriver.
  • Page 12 Assembly Instructions ③ x 8 9. Glue eight Wood Dowels (3) into the designated holes on the Panels (B, C and D).
  • Page 13 Assembly Instructions ① x 6 10. Using the inserted wood dowels as a guide, align and attach the Both Side Panels (B and D) to the assembled Bottom Panel (E) and Bottom Back skirting (G) by engaging six Cam Locks (1).
  • Page 14 Assembly Instructions The moldings face in the same direction. ⑤ x 2 11. Algin and attach the Partition Panel (C) to the Bottom Panel (E) and secure them into place by inserting two 50 mm Screws (5).
  • Page 15 Assembly Instructions ② x 6 12. Securely screw six Cam Bolts (2) into the designated small holes on the Top Panel (A) with a Phillips screwdriver.
  • Page 16 Assembly Instructions ⑦ x 4 ⑧ x 2 13. Using the pilot holes as a guide, attach the Door Stoppers (8) to the Top Panel (A) with four 12 mm Screws (7).
  • Page 17 Assembly Instructions The door stoppers are located at the front of the unit. ② x 6 14. Align and attach the Top Panel (A) to the assembled vertical Panels (B, C and D) by engaging six Cam Locks (1).
  • Page 18 Assembly Instructions The flush surface faces outward. ⑨ x 8 ⑩ x 2 15. Using the pilot holes as a guide, fasten two Triangle Metal Plates (10) at the bottom joints between Side Panels (B and D) and Bottom Front Skirting (F) with eight 15 mm Pan Head Screws (9).
  • Page 19 Assembly Instructions 16. Screw two Floor Levelers (11) into the installed Triangle Metal Plates (10) and set to the correct height.
  • Page 20 Assembly Instructions Label location ⑥ x 21 17. Now, go back and securely tighten all the bolts and screws. Make sure that all the parts are tight and there are no gaps between the parts. This will help keep the unit square. 18.
  • Page 21 Assembly Instructions 20. Ask for assistance to lift the assembled unit upright and position it near the final location. 21. Insert the Shelf Pins (13) into the desired holes in the sides of each compartment. Make sure you place four shelf pins in the same level to level the shelf. Tilt and rest the Adjustable Shelves (I) onto the Shelf Pins (13) with the end notches of the Shelf fit onto the Shelf Pins properly.
  • Page 22 Assembly Instructions x 16 22. Extend two Hinges (L) and rest the hinge cups onto the cutouts of each Door (J). Secure the Hinges (L) in place by using two 15 mm Flat Head Screws (12) in each.
  • Page 23 Assembly Instructions 23. Fasten one Knob (M) to the front of each Door (J) with one 25 mm Bolt (15).
  • Page 24 Assembly Instructions Horizontal Depth Vertical Adjustment Adjustment Adjustment x 32 24. Using the pilot holes as a guide, pick up one Door (J) and attach the extended hinges to the Left Side Panel (B) with eight 15 mm Flat Head Screws (12). Make sure that both door hinges engage and function properly.
  • Page 25 Assembly Instructions x 12 27. Plug the Cam Lock Covers (14) onto the visible Cams Locks to conceal the Cams.
  • Page 26 Assembly Instructions Wooden stud Wall Short screw Nylon strap Wall Long screw Metal bracket Floor leveler Tools required (not included): Phillips screwdriver, stud finder, tape measure, pencil, power drill and 1/8” drill bit. 28. Ask for assistance to position the assembled unit at the desired location against a wall. If necessary, adjust the installed floor levelers to level the door and correct the tilting.
  • Page 27 Care and Maintenance  Use a soft, clean cloth that will not scratch the surface when dusting.  Use of furniture polishes is not necessary. Should you choose to use polishes, test first in an inconspicuous area.  Using solvents of any kind on your furniture may damage the finish. ...

  • Page 28: Quality Guarantee

    M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOG : Low Profile Canton TV Stand MODEL # BHF336158813001 / BHF336158813002 FITS UP TO MOST 177.8cm / 70in DIAGONAL FLAT PANEL TVS MAXIMUM LOAD 61.2 kg / 135 lb...
