- Page 1 OWNER´S MANUAL 3000.1...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction ..............................3 Package contents ............................3 Safety instructions............................4 Panels description Audio inputs and controls.................... 5 Power inputs and audio outputs ................6 Installation sequence ..........................7 Electrical Dimensioning .......................... 8 Audio inputs RCA inputs..........................8 Gain adjustment procedure ......................... -
Page 3: Introduction
INTRODUCTION Dear Consumer, Congratulations, you have just acquired a SounDigital product of the highest technology and quality, so we thank you for your trust. SounDigital products are made with raw materials of the highest quality standards, and the most modern processes, equipment and technology are used in their production. -
Page 4: Safety Instructions
Wear gloves, safety glasses firmly. Avoid fixing to metallic and all necessary PPE during parts of the vehicle, as this the installation of SounDigital procedure may cause ground amplifiers. looping (noise); THIS "WARNING" SIGN ALERTS THE USER OF IMPORTANT INFO. NOT FOLLOWING THESE INSTRUCTIONS MAY CAUSE INJURIES TO THE USER OR DAMAGE TO THE EQUIPMENT. -
Page 5: Panels Description
PANELS DESCRIPTION Audio inputs and controls Variable "BASS BOOST" control 50Hz (0dB ~ +12dB) Variable Gain control Variable "LOW PASS" filter control (80Hz ~ 20kHz) Variable "HIGH PASS" filter control (5Hz ~ 80Hz) OUTPUT Audio RCA connectors INPUT Blue "POWER ON" LED indicator Yellow "CLIP"... -
Page 6: Power Inputs And Audio Outputs
PANELS DESCRIPTION Power inputs and audio outputs Negative power supply connector (GND) Remote power supply connector (REM) Positive power supply connector (+12VDC) Negative speaker connector (-) Speakers output connectors Positive speaker connector (+) Minimum speaker load allowed (impedance) -
Page 7: Installation Sequence
INSTALLATION SEQUENCE BEFORE PROCEEDING WITH THE INSTALLATION, UNPLUG THE NEGATIVE TERMINAL FROM ALL OF THE BATTERIES, TO AVOID FIRE, DAMAGE TO THE AMPLIFIER AND THE USER HIMSELF. Warning! Ø Fix the amplifier so that the connectors can be easily accessed; Ø... -
Page 8: Electrical Dimensioning
ELECTRICAL DIMENSIONING AND AUDIO INPUTS ELECTRICAL DIMENSIONING For proper operation of your SounDigital amplifier, you need the proper dimensioning of the electrical system and the cables used. The table below shows the minimum section of GND cables, +12VDC cables and speaker output cables according to the power generated by the amplifier. -
Page 9: Gain Setting
GAIN SETTING GAIN SETTING Necessary equipament: Ø Set the variable "LOW" crossover in Ø Digital AC voltmeter; 20kHz; Ø Media with sine wave test tone Ø Set the variable "HIGH PASS" 60Hz recorded at 0db; crossover in 5Hz; Ø 1 / 8 " s c r e w d r i v e r ( f o r g a i n Ø... -
Page 10: Bass Boost Set Up
BASS BOOST AND CROSSOVER SET UP Using Bass Boost The Amplifier Bass Boost setting enables the user to boost the sound intensity at low frequencies of the sound system, where boost intensity can be adjusted. This is a semi-parametric equalizer type circuit with ''Q'' value for the fixed filter, with an intensity boost adjustment from 0 to +12dB (16 times), and a central frequency adjustment of the filter in 50Hz, making it versatile for several types of sound systems. -
Page 11: Audio Inputs
WIRING DIAGRAM "AUDIO on page 8. INPUTS" In case of connections with more than one battery, see the installation diagram on page 12 REMOTE Minimum impedance of use Model according to the model 1 Ω 1 Ω 2 Ω 2 Ω 4 Ω... -
Page 12: Battery Connection Diagram
BATTERY CONNECTION DIAGRAM When necessary the association of one or more battery banks to supply the necessary current to the amplifier, it is recommended to use batteries of the same brand, model, and if possible the same manufacturing lot so that the system has the maximum performance. -
Page 13: Amplifier Operational Leds
AMPLIFIER OPERATIONAL LEDS "POWER" LED indicator (blue) LED "POWER" Off ........Product off. "CLIP" LED indicator (yellow) LED "CLIP" Off .......... Product operating normally. LED "CLIP" Flashing ......Audio distortion indication. LEDs *Merely illustrative image. -
Page 14: Diagnostic Table
In the vast majority of cases, situations that at first glance appear to be a defect can be adjusted and resolved by yourself without the need to seek Authorized SounDigital Technical Assistance. If the problem persists after carrying out the corrective actions below, contact our nearest technical team. -
Page 15: Technical Specs
The values presented are based on measurements performed in Updates of information made in this document will always be SounDigital's laboratories. All the equipment used in the assays, tests, published and made available for consumer consultation, free of measurements and gauging of the technical parameters of SounDigital charge, on the brand's websites.
