- Page 1 OWNER´S MANUAL 800.4...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction ................................3 Package contents .............................. 3 Safety instructions.............................. 4 Technologies ® DTM ..............................5 I-Power Supply ........................... 5 Vibration Absorption System .................... 6 Reduced size ..........................6 Assembling and disassembling the plastic cover ................7 Panels description Audio inputs and controls.................... -
Page 3: Introduction
INTRODUCTION Dear Consumer, Congratulations, you have just acquired a SounDigital product of the highest technology and quality, so we thank you for your trust. SounDigital products are made with raw materials of the highest quality standards, and the most modern processes, equipment and technology are used in their production. -
Page 4: Safety Instructions
Wear gloves, safety glasses firmly. Avoid fixing to metallic and all necessary PPE during parts of the vehicle, as this the installation of SounDigital procedure may cause ground amplifiers. looping (noise); THIS "WARNING" SIGN ALERTS THE USER OF IMPORTANT INFO. NOT FOLLOWING THESE INSTRUCTIONS MAY CAUSE INJURIES TO THE USER OR DAMAGE TO THE EQUIPMENT. -
Page 5: Technologies
I-POWER SUPPLY SounDigital amplifiers are known for their low consumption of battery, and this feature was i m p r o v e d o n t h e E VOX 2 L i n e . T h e n e w... -
Page 6: Vibration Absorption System
TECHNOLOGIES VIBRATION ABSORPTION ® SYSTEM - VAS ® Technology reduces all impact caused by vibration on the electronic circuit board. This can include road vibration and even vibration caused by sound waves, increasing the reliability of our amplifiers. 5.8" REDUCED SIZE technology used amplifiers... -
Page 7: Assembling And Disassembling The Plastic Cover
ASSEMBLING AND DISASSEMBLING THE PLASTIC COVER The plastic covers are used to finish and hid the amplifier ’s fixing screws. To disassembl and assembl them, follow the instructions below. DISASSEMBLING OF THE PLASTIC COVER 1. Carefully pull out the top of the plastic cover to release the upside latches, as shown in picture 1. 2. -
Page 8: Panels Description
PANELS DESCRIPTION 11 6 CH1/CH2 Variable crossover control (45Hz ~ 850Hz) CH3/CH4 CH1/CH2 Audio input – High Level (To connect to the speaker output of the head unit) CH3/CH4 Audio inputs – RCA connectors CH1/CH2 Crossover switch key High Pass – Full – Low Pass CH3/CH4 CH1/CH2 Variable Gain control... -
Page 9: Power Inputs And Audio Outputs
PANELS DESCRIPTION 13 14 15 16 17 18 Positive speaker connector (+) Negative speaker connector (-) Positive speaker connector (+) Negative speaker connector (-) Positive speaker connector (+) Negative speaker connector (-) Positive speaker connector (+) Negative speaker connector (-) Positive power supply connector (+12VDC) Remote power supply connector (REM) Negative power supply connector (GND) -
Page 10: Installation Sequence
INSTALLATION SEQUENCE BEFORE PROCEEDING WITH THE INSTALLATION, UNPLUG THE NEGATIVE TERMINAL FROM ALL OF THE BATTERIES, TO AVOID FIRE, DAMAGE TO THE AMPLIFIER AND THE USER HIMSELF. Warning! Ø Fix the amplifier so that the connectors can be easily accessed; Ø... -
Page 11: Electrical Dimensioning
ELECTRICAL DIMENSIONING AND AUDIO INPUTS ELECTRICAL DIMENSIONING For proper operation of your SounDigital amplifier, you need the proper dimensioning of the electrical system and the cables used. The table below shows the minimum section of GND cables, +12VDC cables and speaker output cables according to the power generated by the amplifier. -
Page 12: Wiring Diagram
WIRING DIAGRAM 4 CHANNELS WIRING DIAGRAM (PER CHANNEL) (PER CHANNEL) (PER CHANNEL) (PER CHANNEL) All RCA inputs must be connected for the amplifier to work properly. If the signal source is a mono type, use a "Y" cable at the input. REMOTE +12V FUSE... -
Page 13: Two Channel Wiring Diagram
WIRING DIAGRAM / GAIN SETTING 2 CHANNELS WIRING DIAGRAM (BRIDGE) (BRIDGE) All RCA inputs must be connected for the amplifier to work properly. If the signal source is a mono type, use a "Y" cable at the input. REMOTE +12V FUSE +12V In case of connections with... -
Page 14: Crossovers Set Up
CROSSOVER SET UP "F" Set variable control in Full Range function; "LP" Set variable control in Low Pass function; "HP" Set variable control in High Pass function. Change the switch to "F" position (Full Range) - All the frequencies will be Ø... -
Page 15: Battery Connection Diagram
BATTERY CONNECTION DIAGRAM When necessary the association of one or more battery banks to supply the necessary current to the amplifier, it is recommended to use batteries of the same brand, model, and if possible the same manufacturing lot so that the system has the maximum performance. -
Page 16: Technical Specifications
The values presented are based on measurements performed in Updates of information made in this document will always be SounDigital's laboratories. All the equipment used in the assays, tests, published and made available for consumer consultation, free of measurements and gauging of the technical parameters of SounDigital charge, on the brand's websites.
