- Page 1 USER'S MANUAL 2000.4...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction........................Package Contents...................... Safety instructions....................... Assembling and disassembling the plastic cover........Description of the panels Audio inputs and controls............. Power and audio outputs............... Electrical sizing......................Audio input........................Installation sequence....................Connection diagram Four-channel setup................Three-channel setup................ Two-channel configuration............Gain Adjustment Procedure.................. -
Page 3: Introduction
Source) higher than 70%, which ensures lower battery consumption and less heating. Versatility of Application – The flat response in all frequencies of the SounDigital amplifiers allows them to be used in all automotive sound systems. They meet the demands with extreme quality. -
Page 4: Safety Instructions
To prevent injury to the user or damage to the amplifier, read all the safety instructions contained in this manual; If you feel insecure about installing the equipment, contact SounDigital technical support or a qualified professional in automotive sound installation;... -
Page 5: Assembling And Disassembling The Plastic Cover
ASSEMBLING AND DISASSEMBLING THE PLASTIC COVER The plastic covers have the function of giving finishing and hiding the amplifier's fixation screws. To remove and replace them, follow the instructions below. DISASSEMBLING THE COVER 1. Carefully pull the top flap outward, releasing the upper latches, as illustrated in the image. 2. -
Page 6: Description Of The Panels
DESCRIPTION OF THE PANELS RCA audio input CH1/CH2 Crossover Selector Switch High Pass - Full - Low Pass CH3/CH4 CH1/CH2 Variable gain control CH3/CH4 Power On" Indicator LED (Blue) -
Page 7: Power And Audio Outputs
DESCRIPTION OF THE PANELS Negative power connector (GND) Remote power connector (REM) Positive power connector (+12VDC) Positive audio output connector (+) Negative (-) audio output connector Conector de saída de áudio positivo (+) Positive audio output connector (+) Negative (-) audio output connector Positive (+) audio output connector Positive (+) audio output connector Negative (-) audio output connector... -
Page 8: Electrical Sizing
ELECTRICAL SIZING AND AUDIO INPUTS ELECTRICAL SIZING For a correct operation of your SounDigital amplifier, it is necessary to properly size the electrical system and the cables used. In the table below you can determine the minimum proper section of the grounding, positive + 12VDC, and audio output cables according to the amplifier power. -
Page 9: Installation Sequence
INSTALLATION SEQUENCE BEFORE INSTALLING ANY ELECTRICAL EQUIPMENT IN THE VEHICLE, DISCONNECT THE NEGATIVE (-) TERMINAL OF THE BATTERY TO AVOID FIRE, DAMAGE TO THE AMPLIFIER AND TO THE USER HIMSELF. CUIDADO! Fix the amplifier so that there is access to the connectors. Ø... -
Page 10: Connection Diagram
CONNECTION DIAGRAM 4-CHANNEL CONFIGURATION See "Audio Input" on page 8 3-CHANNEL CONFIGURATION See "Audio Input" on page 8... -
Page 11: Two-Channel Configuration
Disconnect the speakers from the Ø amplifier output; Download the media for regulation at https://soundigital.com/downloads/ Turn off or set to "0" all audio processing Ø (bass, treble, loudness, EQ, etc.); Set the volume of the main unit to approximately 3/4 of the total.total. -
Page 12: Crossover Adjustment
CROSSOVER ADJUSTMENT X-OVER "F" All frequencies will be played back "LP" Frequencies below 80Hz will be played "HP" Frequencies above 80Hz will be played Select the key in position "F" - All frequencies will be played as in "Figure 1"; Ø... -
Page 13: Technical Specification
TECHNICAL SPECIFICATIONS 2000.4 2000.4 2Ω 4Ω PARAMETERS Bridge RMS power @ 2Ω* 2 X 1000W Bridge RMS power @ 4Ω* 2 X 660W 2 X 1000W RMS power @ 1Ω* 4 X 500W RMS power @ 2Ω* 4 X 330W 4 X 500W Frequency response (-3dB) 10Hz ~ 22kHz... - Page 14 WWW.SOUNDIGITAL.COM SOUNDIGITALBRASIL SOUNDIGITAL...
