- Page 1 МV110-24.8AS Analog input module 8 channel User guide МV110-24.8AS_3-EN-144281-1.1 © All rights reserved Subject to technical changes and misprints akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
-
Page 2: Table Of Contents
7. Maintenance........................19 8. Transportation and storage ....................20 9. Scope of delivery........................21 Appendix A. Dimensions .......................22 Appendix B. Galvanic Isolation ....................24 akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de... -
Page 3: Introduction
If the supply voltage is lower than 20 V DC, the device cannot operate properly but will not be damaged. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de... - Page 4 To avoid damage to the device, keep the device in the warm environment for at least 1 hour before powering on. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
-
Page 5: Overview
POWER Power on Flashing Data exchange via RS485 interface RS485 FAULT Fault status Fig. 2.1 Front view of MV110-24.8AS akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de... - Page 6 Under the cover on the front panel of the module there is a 10-pole pin strip XP1 with the JP1 jumper (see Fig. 5.1 and Fig. 6.3). For factory settings restoration, see Section 6. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
-
Page 7: Specifications
% FS, per 10 °C of deviation from (20 ±5) °C within the permissible limits. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de... -
Page 8: Operating Conditions
Transportation and storage -25…+55°C Relative humidity up to 80% (at +25°C, non-condensing) Altitude up to 2000 m above sea level akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de... -
Page 9: Configuration And Operation
Network parameters 14.4 Baud rate, kbps 19.2 28.8 38.4 57.6 115.2 none PrtY Parity* none even akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de... -
Page 10: Signal Processing
Inputs are sampled cyclically. The measured values are converted into digital values, analyzed and processed in accordance with the set parameters. The results are saved in data registers (Table 4.3). akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de... -
Page 11: Sampling
If there is a measurement error, the last correctly saved value is transmitted. Table 4.2 Error Codes Error Comment Code Measurement correct Transmission in progress 0x0000 akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de... -
Page 12: Rs485 Network
(Hex) exit Cause of reset INT16 0x88 n.Err Last network error BYTE 0x90 Baud rate INT16 0x30 akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de... - Page 13 Error code INT16 0x11F 0x120…0x122 Measured value (FLOAT) FLOAT32 … … … read with a time mark +INT16 0x135…0x137 akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
-
Page 14: Installation
If the voltage is within the permissible limits the input current will be limited to 35 mA automatically. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de... - Page 15 When connecting current and voltage signals take into account an external additional voltage source. Fig. 5.2 Connection of 2-wire sensors akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
-
Page 16: Different Input Signals
If a sensor has a positive output you can use a common additional voltage source. In case of a negative output, a separate additional voltage source should be provided for each sensor. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de... -
Page 17: Factory Settings Restoration
8. The main window of the Configurator opens. Now the saved network parameters of the module can be read. 9. Open folder ‘Network parameters’ and note the values of the network parameters. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de... - Page 18 Baud rate 9600 Data bits Parity PrtY None Stop bits Sbit Address bits A.Len Address Addr Response delay, ms Rs.dL akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
- Page 19 6 Factory settings restoration Fig. 6.3 Jumper JP1 akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
-
Page 20: Maintenance
The device should be cleaned with a damp cloth only. No abrasives or solvent- containing cleaners may be used. akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de... -
Page 21: Transportation And Storage
Check the device for transport damage and completeness! Report the transport damage immediately to the shipper and akYtec GmbH! akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de... -
Page 22: Scope Of Delivery
9 Scope of delivery 9 Scope of delivery – Module MV110-24.8AS – Short guide akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de... -
Page 23: Appendix A. Dimensions
Appendix A. Dimensions Appendix A. Dimensions Fig. A.1 External dimensions Fig. A.2 Wall mounting dimensions akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de... - Page 24 Appendix A. Dimensions Fig. A.3 Replacement of terminal blocks akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
-
Page 25: Appendix B. Galvanic Isolation
Appendix B. Galvanic Isolation Appendix B. Galvanic Isolation Fig. B.1 Galvanic isolation of MV110–24.8AS akytec GmbH - Vahrenwalder Str. 269 A - 30179 Hannover - Germany Tel.: +49 (0) 511 16 59 672–0 - www.akytec.de...
