DSPPA DSP0810 Manual

DSP0810
8" 100W Outdoor Waterproof Horn Speaker
The DSP0810 is a high-power long-range horn speaker with a coaxial design for treble and bass, featuring
professional-grade coaxial drivers. It features efficient sound transmission, strong penetration, and high
speech intelligibility. The enclosure is made of PP material, offering waterproof, corrosion-resistant
properties, making it suitable for various extreme climates and environments. This product is widely used in
stadiums, schools, training grounds, air raid warning systems, coastal beaches, and highways.
 Driver Unit: 8"×1, 1"×1, Rated Power 100W
 Signal Input:100V or 8Ω
 Frequency Response:110Hz-16KHz
 Sensitivity(1W/1M):96+3dB
 Max. SPL:116+3dB
 Coverage Angle:50x70
 Connector:2×Neutrik SpeakonNL4
 Product Size: 300×300×310mm
 Product Weight: 11kg
 Waterproof level: IP56
