ROBOT SYSTEM
SERIES 5150
Model 5924 – Signal Tower
The Signal Tower consists of three lights providing visual
signals of the Robot Controller states. Lights are stacked
one upon another, up to five modules. Each module is
easily programmable without any special wiring or tools.
An Acoustic Alarm, Model 39303, is available as an
option. A Control Relay, Model 5125, DC Power Supply,
Model 6360, and Connection Leads, Model 5259-C are
required to operate the Signal Tower. They are provided
in the Signal Tower Kit (with Control Relay), Model
5924-B.
Model 6309 – Storage/Work Surface
The Storage/Work Surface is a perforated metal plate,
38 x 584 x 584 mm (1.5 x 23 X 23 in), on which the
equipment is placed. Two work surfaces can be joined
using Spacers, Model 39035.
12
Model 6360 – DC Power Supply
The DC Power Supply converts the ac line voltage into
a 24-V dc voltage that is used to power the Signal Tower,
Model 5924. It is protected against short-circuits by an
automatic current/limit foldback circuit.
Model 6410-C – Air Compressor
The Air Compressor consists of motor, compressor, tank,
pressure regulator, and pressure gauge. The dischage
line of the Air Compressor is connected to an air
conductor hose ended by a quick-connect fitting that
plugs directly into the inlet port of the Pneumatic Feeder
Controller, Model 5149. This quiet air compressor is ideal
for class room and school laboratories usage.
