ZK-D4330
User Manual
Walk Through Metal Detector
ZK-D3180V
Date: January 2025
Doc Version: 1.0
English
Thank you for choosing our product. Please read the instructions
carefully before operation. Follow these instructions to ensure that the
product is functioning properly. The images shown in this manual are
for illustrative purposes only.
For further details, please visit our Company's website
www.zkteco.com.
User Manual
Contents 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZK-D3180V and is the answer not in the manual?

Questions and answers

Summary of Contents for ZKTeco ZK-D3180V

  • Page 1 ZK-D4330 User Manual User Manual Walk Through Metal Detector ZK-D3180V Date: January 2025 Doc Version: 1.0 English Thank you for choosing our product. Please read the instructions carefully before operation. Follow these instructions to ensure that the product is functioning properly. The images shown in this manual are for illustrative purposes only.
  • Page 2 Copyright © 2025 ZKTECO CO., LTD. All rights reserved. Without the prior written consent of ZKTeco, no portion of this manual can be copied or forwarded in any way or form. All parts of this manual belong to ZKTeco and its subsidiaries (hereinafter the "Company" or "ZKTeco").
  • Page 3 ZK-D3180V User Manual ZKTeco in no event shall be liable to the user or any third party for any incidental, consequential, indirect, special, or exemplary damages, including, without limitation, loss of business, loss of profits, business interruption, loss of business information or any pecuniary...
  • Page 4 User Manual About the Company ZKTeco is one of the world’s largest manufacturer of RFID and Biometric (Fingerprint, Facial, Finger-vein) readers. Product offerings include Access Control readers and panels, Near & Far-range Facial Recognition Cameras, Elevator/floor access controllers, Turnstiles, License Plate Recognition (LPR) gate controllers and Consumer products including battery-operated fingerprint and face-reader Door Locks.
  • Page 5: Table Of Contents

    4 PERFORMANCE AND TECHNICAL FEATURES ............ 20 5 DETECTION ZONES ..................... 21 5.1 ABOUT THE DETECTION ZONES ................21 5.2 ADJUSTMENT OF DETECTION ZONE’S SENSITIVITY .......... 22 6 CONTROL PANEL DESCRIPTION ................. 23 Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 4...
  • Page 6 8.10 LOG QUERY ......................39 8.11 SYSTEM SETTINGS ....................39 8.12 WEB SERVER ......................45 8.13 DEFAULT PARAMETERS ..................47 TROUBLESHOOTING ..................... 48 PACKING LIST......................49 WARRANTY CARD ....................50 Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 5...
  • Page 7: Overview

    Overview Introduction ZK-D3180V is a walk through metal detector designed for precise security detection. Featuring 18 detection zones with 500 adjustable sensitivity levels, it offers good accuracy to detect small threats while ensuring safe operation for for users, including pregnant women and pacemaker users.
  • Page 8: Components

    Alarm Indicator Post 5. Door Panel Integrated Embedded Monocular With Electromagnetic Camera Detection Zones Infrared Sensors 8. Waterproof and Fireproof 9. Power Interface Foot Cover (ABS Polymer) Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 7...
  • Page 9: Product Specifications

    Count, Channel, Date & Time, Battery Indicator 240*320 Photo Resolution Embedded monocular 2MP camera Camera >100,000 Storage of Records Automatic Detection Mode / Infrared Detection Mode (default) Detection Mode Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 8...
  • Page 10 -20°C to 55°C Operating Temperature -25°C to 60°C Storage Temperature <95% (non-condensing) Operating Humidity 5.7KHz to 9.6KHz Operating Frequency 2226*845*580 mm Dimensions (L*W*H) 2000*710*498 mm Lane Size (L*W*H) Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 9...
  • Page 11 Packaging (L*W*H) Gross Weight: 52kg Weight Net Weight: 47kg CE, FCC, ISO9001 Certifications ZKBio SIS / ZK Metal Detector Supported Software Remote Control Accessories Application Indoor Environment Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 10...
  • Page 12: Installation Setup

    If the detector alarms when someone passes through, that means there is/are some metal object(s) hidden in the body. The security guard can use a hand-held metal detector to accurately detect the hidden position according to the alarm zones. Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 11...
  • Page 13: Installation Site

    The parameters that define the distance are determined by the installation environment and the parameters vary for different installation environments. The sources of electromagnetic radiation and electromagnetic interference are given below: Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 12...
  • Page 14: Parallel Installation

    Transformer, Ac Power Lines, Thyristor Control Circuit (High Power Switching Power Supply, Inverter Welder), Engine, Motor, etc. The ZK-D3180V metal detector reduces electromagnetic interference (EMI) using three approach: a multi-layer Faraday cage for physical shielding, active noise cancellation circuits, and advanced EMI filtering. These techniques work together to block external EMI signals, ensuring accurate detection and minimizing false alarms in different environments.
  • Page 15 Step 2: Connect the rear beam with the left and right door panels with bolts, as shown in the figure 3-2 below (note that the bolts are not tightened at this time). Figure 3-2 Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 14...
  • Page 16 Figure 3-3 Step 4: Open the left and right cover of the front beam, push out the lower cover, as shown in the figure 3-4 below. Figure 3-4 Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 15...
  • Page 17 Step 6: After covering the beam cover, connect the host to the front beam with bolts, and tighten the screws with two Torx Thumb Screws, as shown in the figure 3-6 below. Figure 3-6 Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 16...
  • Page 18 Walk Through Metal Detector and the barrier gate. The wiring circuit diagram is shown in the figure 3-8 below. Figure 3-8 Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 17...
  • Page 19 Step 9: Connect the front cross beam with the left and right door panels with bolts and tighten all the bolts, as shown in the figure 3-9 below. Figure 3-9 Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 18...
  • Page 20 Step 10: Lift and move the security gate to the designated working position, connect the side power cord, and press the power switch to enter the working state, as shown in the figure 3-10 below. Figure 3-10 Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 19...
  • Page 21: Performance And Technical Features

    Micro Processor Technology: The Microprocessor Control Unit generates the electro- magnetic waves for scanning. The scanning rate can be precisely controlled. Adjustable Sensitivity: ZK-D3180V detection zones have 1 to 500 sensitivity levels. Customizable metal mass threshold settings to exclude items, for instance, coins, keys, jewelry, buckle, etc.
  • Page 22: Detection Zones

    If the walkthrough metal detector detects metals of the size that reach or exceed the preset value, the alarm indicator of the detection zone turns on, and Copyright©2025 ZKTECO CO., LTD. All rights reserved.
  • Page 23: Adjustment Of Detection Zone's Sensitivity

    After implementing the above adjustments, the metal which smaller than the sample will not alarm, but the metal objects bigger than the sample can be detected accurately. Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 22...
  • Page 24: Control Panel Description

    Selects a menu item or decreases a value. OK Button Enters a menu item or save settings. Power Button Power on or off the device. Light Infrared remote signal receive terminal. Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 23...
  • Page 25: Remote Control Description

    Selects a menu item or increases a value. DOWN / RIGHT Selects a menu item or decreases a value. ENTER Menu key, confirmation key and adjustment value. Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 24...
  • Page 26: Operational Procedure

    For the first operation of the device, please enter the factory password of the device: 100000, and select "Confirm" after completion. When the prompt "Verify Succeed", the verification is completed. Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 25...
  • Page 27 [OK] button to set the value, press the [▲]/ [▼] button to switch, select "Confirm" and then press the [OK] button to save and exit. After entering the password successfully, you will enter the main menu interface as shown below: Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 26...
  • Page 28: Sensitivity Adjustment

    Mode, Relay Mode, and Custom ID etc. Sensitivity Adjustment Select Sensitivity on the Main Menu interface, and press OK to set the sensitivity level of each detection zone, as shown in the following: Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 27...
  • Page 29 1 to 500, the default value is 460. • Zone Sensitivity Select Zone Sensitivity on the Sensitivity interface and press OK to get into its setting interface, as shown in the following: Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 28...
  • Page 30: Zone Mode

    Select Zone on the Main Menu interface, and press OK to select the particular zone settings, as shown in the following: Operation: Press the [OK] button to enter the zone setting interface, then press the [▲]/ [▼] button Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 29...
  • Page 31 ZK-D3180V User Manual to select, press [OK] button to save and exit. Remark: Different independent zones, the Zone Sensitivity setting interface is as follows: Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 30...
  • Page 32: Channel Settings

    [⏎] button to exit to the upper menu without saving the current value. • Auto Setting Select Auto Setting on the Channel interface and press OK to get into its setting interface, as shown in the following: Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 31...
  • Page 33: Alarm Settings

    • Volume Select Volume on the Alarm setting interface, and press OK to enter the alarm volume settings interface, as shown in the following: Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 32...
  • Page 34 Operation: Press the [OK] button to enter the alarm delay duration setting interface, then press the [▲]/ [▼] button to increase or decrease the value, press [OK] button to save and exit to the upper Copyright©2025 ZKTECO CO., LTD. All rights reserved.
  • Page 35 Under normal circumstances, the alarm is generated when the amount of metal signal reaches the set sensitivity threshold, while it can pass normally when it is less than the Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 34...
  • Page 36 Single Zone personnel to precisely focus on the area for detection. Operation: Press the [OK] button to enter the alarm mode setting interface, then press the [▲]/ [▼] Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 35...
  • Page 37: Auto Testing

    Operation: Press the [OK] button to enter the partition test, then press [⏎] button to exit to the upper menu. • LED Test Select LED Test on the Alarm setting interface, and press OK to enter the lighting test. The test example is shown below. Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 36...
  • Page 38 Operation: Press the [OK] button to enter the voice test. Then continue to press the [OK] button to play 5 voice content one by one, press the [⏎] button to exit and return to the previous menu. Copyright©2025 ZKTECO CO., LTD. All rights reserved.
  • Page 39: Security Level

    Operation: Press the [OK] button to enter the application scenario setting, then press the [▲]/ [▼] button to select the scenarios, press [OK] button to save and exit. Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 38...
  • Page 40: Log Query

    It is used to set the relevant parameters of the system so that the device can maximize the user requirements in terms of function, display, etc. • Password Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 39...
  • Page 41 You can set the screen hibernation duration here, there are 0s, 10s, 20s, 40s, 60s and 120s optional. Note: The 0s means the screen will not hibernation. Operation: Press the [OK] button to enter the screen hibernation setting, then press the [▲]/ [▼] Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 40...
  • Page 42 Press [OK] button to set the value, select "Confirm" and press the [OK] button to save and exit. • Language Select Language on the System setting interface, and press OK to enter the language setting interface, as shown in the following: Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 41...
  • Page 43 Press [OK] button to save and exit to the upper menu. • Reset Select Reset on the System setting interface, and press OK to enter the restore factory settings interface, as shown in the following: Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 42...
  • Page 44 In this mode, an alarm is generated when the amount of metal Automatic signal reaches the set sensitivity threshold, and no counting Detection Mode statistics are performed. Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 43...
  • Page 45 Operation: Press the [OK] button to enter the relay mode setting interface, then press the [▲]/ [▼] buttonto select trigger setting, press [OK] button to save and exit. Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 44...
  • Page 46: Web Server

    (e.g. http://192.168.1.201). Enter the account and password, the default account is: admin, password: admin. After successful login, you can view the device basic information by clicking Dev Status. Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 45...
  • Page 47 Click TCP/IP to set the IP address of the device.(Note: If you modify the IP address of the device, then the web server link will be changed accordingly.) Click Server to set the server address and port. Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 46...
  • Page 48: Default Parameters

    Security Level High Application Area None Screen Hibernation 120s Language English Save Records Detect Mode Infrared Detection Mode Relay Mode None Custom ID 123456 IP Address 192.168.1.201 Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 47...
  • Page 49: Troubleshooting

    Make sure that the installation location is stable and free from physical movements. If the false alarm is not caused by the environment, reduce the sensitivity level of all zones. Change the frequency. Change the installation location. Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 48...
  • Page 50: Packing List

    Power Adapter 1 set Remote Control 1 pc Torx Thumb Screw 2 pcs Allen Screw 4 pcs Hexagonal Tool 1 pc Bolt 8 pcs User Manual 1 pc Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 49...
  • Page 51: Warranty Card

    This card will not be issued again if it is lost. Model Number Date of Acquisition User Post Code Address User’s Phone Number Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 50...
  • Page 52 ZK-D3180V User Manual Date of Maintenance Record of Maintenance Technician Copyright©2025 ZKTECO CO., LTD. All rights reserved. P a g e | 51...
  • Page 53 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone +86 769 - 82109991 +86 755 - 89602394 www.zkteco.com Copyright@2025 ZKTECO CO., LTD. All rights reserved.
