Instructions
Inverter Replacement Kit for LineLazer
ES 1000 and ES 2000
For replacement of the inverter on the LineLazer
use only. Not approved for use in explosive atmospheres or hazardous locations.
Important Safety Instructions
Read all warnings and instructions in this manual, related manuals, and on the equipment.
Be familiar with the controls and the proper usage of the equipment.
Save these instructions.
Related Manuals:
3A4603
Operation, Repair, Parts
™
™
ES 1000 and ES 2000. For professional
3A4746B
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LineLazer ES 2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Graco LineLazer ES 2000

Summary of Contents for Graco LineLazer ES 2000

  • Page 1 Instructions ™ Inverter Replacement Kit for LineLazer 3A4746B ES 1000 and ES 2000 ™ For replacement of the inverter on the LineLazer ES 1000 and ES 2000. For professional use only. Not approved for use in explosive atmospheres or hazardous locations. Important Safety Instructions Read all warnings and instructions in this manual, related manuals, and on the equipment.
  • Page 2 Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these sym- bols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific hazard sym- bols and warnings not covered in this section may appear throughout the body of this manual where applicable.

  • Page 3: Pressure Relief Procedure

    Pressure Relief Procedure Pressure Relief Procedure 2. Turn pressure control to lowest setting. Trigger all guns to relieve pressure. This equipment stays pressurized until pressure is manually relieved. To help prevent serious injury from pressurized fluid, such as skin injection, splashing fluid and moving parts, follow the Pressure Relief ti30323a Procedure when you stop dispensing and before...

  • Page 4: Inverter Replacement

    Inverter Replacement Inverter Replacement Removal 3. Remove two t-handle screws and lift off battery cover. NOTICE Wear the grounding strap provided with this kit to avoid damaging the circuit boards. 1. Perform Pressure Relief Procedure, page 3. 2. Remove suction set, bucket, and paint line from pump.
  • Page 5 Inverter Replacement 4. Unplug from wall. Disconnect negative battery cable 5. Disconnect power cable from inverter to sprayer first, then positive cable using a 1/2 inch socket. port. Remove battery. This will help balance the sprayer while working on it. Let unit sit for 30 minutes. Failure to disconnect all input power connections and let sit for 30 minutes can cause electric shock and possible damage to the PCB.
  • Page 6 Inverter Replacement 7. Remove control cover using 1/4 inch socket (ES 9. Remove voltmeter box using a 7/16 inch socket. 1000), or T25 torx driver (ES 2000) and unplug Disconnect wires from inlet plug on voltmeter box. transducer and potentiometer. Disconnect battery cable and inverter on/off cable from PCB 12V quick connect.
  • Page 7 Inverter Replacement 10. Cut cable tie holding positive cable to the frame. 12. Remove four bolts that attach inverter to frame Remove fuse and positive battery cable using a 1/2 using 3/8 wrench and 7/16 inch socket. Lift inverter inch socket. from unit and rotate 90°...
  • Page 8 Inverter Replacement 14. Disconnect quick-connect and disconnect the line 16. Remove inverter from sprayer. conductor on AC output using a small flathead screw driver. 15. Disconnect positive and negative ring terminals 17. Disconnect remaining wires from inverter. using a 1/2 inch socket from input DC studs on inverter.
  • Page 9 Inverter Replacement Installation 4. Connect quick-connect and connect the line con- ductor on AC output using a small flathead screw driver. 1. Connect wires to new inverter. 5. Install power input cover. 2. Rest inverter back on sprayer frame. 3. Connect positive and negative ring terminals from 6.
  • Page 10 Inverter Replacement 7. Using a flat head screwdriver, connect ground wire 9. Connect battery cable and inverter on/off cables to to frame. PCB 12V quick-connect. Connect wires to inlet plug on voltmeter box. Install voltmeter box using a 7/16 inch socket. 8.
  • Page 11 Inverter Replacement 10. Install inverter cover with five bolts using a 5/16 inch 12. Place front shroud on unit and secure with two socket. screws. 13. Connect power cable from inverter to sprayer. 11. Plug in transducer and potentiometer. Install control cover using 1/4 inch socket (ES 1000), or T25 torx driver (ES 2000).
  • Page 12 Inverter Replacement 14. Install battery. Connect positive battery cable first, 15. Install battery cover using two t-handle screws. then negative cable using a 1/2 inch socket. 16. Install suction set, bucket, and paint line from pump. Install gun mount. Instructions...

  • Page 13: Graco Standard Warranty

    With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.

  • Page 14: Graco Information

    For patent information, see www.graco.com/patents. TO PLACE AN ORDER, contact your Graco distributor or call 1-800-690-2894 to identify the nearest distributor. All written and visual data contained in this document reflects the latest product information available at the time of publication.
