DOSS SoundBox H300 Manual

Packing content

1 x SoundBox H300
1 x USB-C charging cable
1 x User Manual

Specifications

Output power: 90W
DC power input: 5V 3A/9V 2A
Battery: 11.1V/4500mAh
Charging time: ≤6H
Playtime: Up to 20H (at 50% volume)
Bluetooth version: V5.3
Bluetooth range: Up to 86ft
Net weight: 8.77 pounds
Dimension: 7.2*8.5*9.8 inches
TF card/USB drive audio format: MP3/WAV/FLAC(Max capacity 256G)
Warranty: One-year limited

Important notes before using

To prolong the lifetime of the battery, fully charge the speaker before the first time using it.
The speaker will auto-power off after 15 minutes without audio input.
When all buttons can't be controlled, try to poke the Aux-in port with a paper clip to reset the speaker.
If you need any assistance while using this speaker, please feel free to contact customer service at support@dossav.com.

Buttons and control

LED indications

	Flashing blue	Bluetooth pairing
	Flashing red	Low Battery
	Solid blue	Bluetooth paired
	Solid red	Aux in mode
	Solid green	TF card mode
	Solid white	USB drive mode
	Solid white	Extra bass on
	Light off	Extra bass off
	Solid red	Charging
	Light off	Fully charged

Pairing your device via Bluetooth

Enable the Bluetooth feature on your device.
Find "SoundBox H300" on the Bluetooth device and connect it.
Once paired, you can see the status" connected " on your device.

Tips: Press to re-enter Bluetooth pairing if your device can't find "SoundBox H300" in 10 secs.

True Wireless Stereo mode

Turn on both speakers.
Select a speaker as the primary speaker and press the button.
Once paired, the LED of the primary speaker turns solid blue, while the second speaker turns slowly flashing blue.
Find "SoundBox H300" on your Bluetooth device and connect it.

Tips: Bluetooth, AUX-IN, TF card, and USB drive modes are all supported in TWS mode, you can press the "M" button to switch modes.

Use your unit with Echo Dot

You can connect the Dot to the speaker via Bluetooth.
Please follow the steps to set up via Bluetooth:

Download the Alexa app and follow the steps to set up the procedure to get the Dot connected to your home Wi-Fi network.
Switch the SoundBox H300 to Bluetooth mode.
Run the Alexa app, tap Menu, and then tap Settings.
Tap the Echo Dot in your list of Alexa devices, then tap Bluetooth.
The SoundBox H300 should appear in the list of Bluetooth devices. If not, please press the power button and try again.
Once listed, tap on the speaker to complete the pairing process.
To remove the device, return to Bluetooth > tap the name of the speaker > tap "Forget Device"

Note:
Voice command will not be able to turn on/off the speaker if you connect to it via Bluetooth.

Warning

DO NOT drop, hit or shake the speaker.
DO NOT disassemble, repair or modify the speaker by yourself.
DO NOT use cleaning products that contain benzene, solvents or alcohol.
DO NOT expose the speaker to excessive heat or direct sunlight for a long time.
DO NOT store the speaker in a place with humidity or dust.
DO NOT place heavy objects on top of the speaker.
DO NOT use the speaker near a microwave oven or wireless LAN products
