Manufactured by:
Backyard Discovery
3305 Airport Drive, Pittsburg, KS 66762
800-856-4445
Basepoint Business Centre: Rivermead Drive,Westlea, Swindon SN5 7EX Phone: 0800-118-2476
TIMBERLAKE
J.P. Coenstraat 7, The Bridge, The Hague, 2595 WP, Netherlands Phone:08005678990
PLAYHOUSE
MODEL: # 65314
WARNING
Adult Assembly Required.
The assembly manual must be retained since it contains important information
Not suitable for children under two years due to sharp points and small parts.
FOR DOMESTIC USE ONLY. INTENDED FOR OUTDOOR USE.
For the most up to date assembly manual, to register your product, or to order replacement parts
Please visit www.backyarddiscovery.com
Para obtener instrucciones en español, visite www.backyarddiscovery.com
Made in China
INS-65314-A-TIMBERLAKE-ENG 8-23-23
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Backyard TIMBERLAKE
Summary of Contents for Backyard TIMBERLAKE
- Page 1 FOR DOMESTIC USE ONLY. INTENDED FOR OUTDOOR USE. Please visit www.backyarddiscovery.com For the most up to date assembly manual, to register your product, or to order replacement parts Para obtener instrucciones en español, visite www.backyarddiscovery.com Made in China INS-65314-A-TIMBERLAKE-ENG 8-23-23...
- Page 2 SELECTING THE CORRECT LOCATION FOR YOUR PLAY PRODUCT IS IMPORTANT FOR YOUR CHILDREN’S SAFETY AND THE PRODUCT’S LONGEVITY Dimensions: General Information: • The Timberlake has one layout option. Your set has been designed and engineered for Layout Ground Dimension children only and for residential use only.
- Page 3 Parts Identification Wood Components (NOT TO SCALE) J1 - COUNTER TOP SUPPORT - W4L04753 1"x2 3/8"x5 7/8" (24x60x150) K1 - TRIANGLE SUNBURST - W4L04871 5/8"x5 1/4"x10 3/8" (16x134x265) L1 - GABLE BOARD - W4L04755 5/8"x4 3/8"x25 3/8" (16x112x643) M1 - COUNTER TOP - W4L04754 5/8"x3 3/8"x23 5/8"...
- Page 4 Parts Identification Wood Components (NOT TO SCALE) (1) DP1 - DOOR ASSEMBLY - W2A01511 (1) WP7 - UPPER REAR CENTER WALL (1) WP2 - RIGHT FRONT CORNER PANEL - W2A01522 - W2A01525 (1) WP1 - LEFT FRONT CORNER PANEL - W2A01524 (2) WP6 - UPPER CENTER WALL - W2A01510 (2) WP5 - LOWER CENTER WALL...
- Page 5 Parts Identification Wood Components (NOT TO SCALE) (2) WP9 - HEADER ASSEMBLY - W2A01539 (2) RP1 - LOWER ROOF PANEL - W2A01513 (2) RP2 - UPPER ROOF PANEL - W2A01514...
- Page 6 Parts Identification Hardware SCREW PFH 8x1/2 - H100124 NUT BARREL WH 1/4x7/8 - H100140 (41) SCREW PFH 8x1 - H100085 (33) SCREW PFH 8x1 1/8 - H100088 (51) SCREW PFH 8x1 1/4 - H100087 BOLT WH 1/4x1 - H100137 (24) SCREW PFH 8x1 1/2 - H100086 SCREW PFH 8x2 - H100111 WASHER LOCK EXT 8x15 - H100139...
- Page 7 Parts Identification Accessories (NOT TO SCALE) PHONE KIT - A100132 FLOWER POT HOLDER - A6P00023 "A" REVISION TAG - A100314 (1) KNOB KIT - A6P00020 FAUCET KIT - A6P00024 BYD ID TAG (MEDIUM) AGES 2 TO 10 - A4M00528 STOVE KIT - A6P00025 SURFACE MOUNT BASIN - A6P00032 METAL TIE STRAP - A4M00517...
-
Page 8: Hardware Parts
PRE-ASSEMBLY STEP 1 - SORTING PARTS It is critical for ease of assembly that you take the time to sort and organize the wood and hardware. WOOD PARTS: • Organize wood parts by the three-digit, alpha-numeric number stamped on each board (ex. P01). •... - Page 9 PRE-ASSEMBLY STEP 2 - TOOLS REQUIRED Drill Attachments: Phillips Head Open End Wrenches 1/2" & 9/16" 1/8", 3/16", 3/8" & 7/16" Drill Bits 3/8" Drive Ratchet, 1/2" & 9/16" STD Sockets 1/2" & 9/16" Deep Sockets Phillips Screw Driver Cordless Drill or Electric Drill Rubber Mallet - Optional Claw Hammer...
- Page 10 PRE-ASSEMBLY STEP 3 - CHOOSE YOUR ASSEMBLY METHOD There are several types of assembly instructions available to you. 1. Printed Assembly Manual included with your set 2. BILT APP - 3D interactive instructions 3. Combination of the Printed Manual and BILT APP (Note: Step numbers can differ between the two methods)
- Page 11 Playhouse Assembly STEP 1: STAND THE (4) CORNER WALL ASSEMBLIES AS SHOWN BELOW. REAR NOTE THE PROFILE OF THE WALL BOARDS. THE TONGUE FACES TOWARD THE TOP OF THE PANELS. RIGHT LEFT FRONT...
- Page 12 (1) WP5 - LOWER CENTER WALL (1) WP6 - UPPER CENTER WALL - W2A01509 - W2A01510 STEP 2: SCREW PFH (10) LEFT REAR FRONT RIGHT SCREW PFH 8x1 (10 PLCS)
- Page 13 (1) WP7 - UPPER REAR CENTER WALL (1) WP8 - LOWER REAR CENTER WALL - W2A01523 - W2A01522 STEP 3: SCREW PFH (10) REAR LEFT FRONT RIGHT SCREW PFH 8x1 (10 PLCS)
- Page 14 (1) WP5 - LOWER CENTER WALL (1) WP6 - UPPER CENTER WALL - W2A01509 - W2A01510 STEP 4: SCREW PFH (10) RIGHT REAR LEFT SCREW PFH 8x1 FRONT (10 PLCS)
- Page 15 (1) DP1 - DOOR ASSEMBLY - W2A01511 STEP 5: FRONT RIGHT SCREW PFH 8x1 1/8 LEFT REAR SCREW PFH 8x1 1/8 (6 PLCS) 3/4"...
- Page 16 METAL TIE STRAP - A4M00517 STEP 6: SCREW PWH 8x3/4 FRONT 3/8" LEFT RIGHT METAL TIE STRAP SCREW PWH 8x3/4 (8 PLCS)
- Page 17 (2) WP9 - HEADER ASSEMBLY - W2A01512 STEP 7: SCREW PFH 8x2 1/2 (4 PLCS) SCREW PFH 8x2 1/2 RIGHT REAR LEFT FRONT...
- Page 18 N4 - TIE STRAP - W102424 5/8”x2”x3 1/8” (16x50x80) STEP 8: SCREW PFH 8x1 1/4 (32 PLCS) REAR SCREW PFH (32) 8x1 1/4 2" TYP LEFT RIGHT FRONT...
- Page 19 L1 - GABLE BOARD - W4L04755 5/8"x4 3/8"x25 3/8" (16x112x643) STEP 9: WASHER WASHER LOCK EXT LOCK EXT 6x15 8x15 BOLT WH 1/4x1 WASHER LOCK EXT 6x15 (4 PLCS) NUT BARREL WASHER LOCK EXT 8x15 WH 1/4x7/8 (4 PLCS) BOLT WH 1/4x1 (4 PLCS) NUT BARREL WH 1/4x7/8 (4 PLCS)
- Page 20 N5 - SUNBURST LEG - W4L04872 5/8"x2 3/8"x10 1/4" (16x60x260) K1 - TRIANGLE SUNBURST - W4L04871 5/8"x5 1/4"x10 3/8" (16x134x265) N6 - SUNBURST LEG - W4L04873 5/8"x2 3/8"x8 1/4" (16x60x210) STEP 10: SCREW PFH (20) 8x1 1/8 SCREW PFH 8x1 1/2 SCREW PFH 8x1 1/8 (8 PLCS) SCREW PFH 8x1 1/8...
- Page 21 (2) RP2 - UPPER ROOF PANEL - W2A01514 STEP 11: FLUSH SCREW PFH 8x1 1/2 SCREW PFH 8x1 1/2 (8 PLCS) RIGHT REAR LEFT FRONT...
- Page 22 (2) RP1 - LOWER ROOF PANEL - W2A01513 STEP 12: SCREW PFH 8x1 1/2 SCREW PFH 8x1 1/2 (8 PLCS) RIGHT REAR LEFT FRONT...
- Page 23 N1 - SIDE WINDOW SHELF - W4L04751 5/8"x2 3/8"x18 7/8" (16x60x479) STEP 13: FLUSH SCREW PFH 8x1 1/4 REAR SCREW PFH 8x1 1/4 (2 PLCS) RIGHT LEFT FRONT...
- Page 24 N2 - REAR WINDOW SHELF - W4L04760 5/8"x2 3/8"x19 1/8" (16x60x485) STEP 14: FLUSH SCREW PFH 8x1 1/4 FRONT SCREW PFH 8x1 1/4 (2 PLCS) RIGHT LEFT REAR...
- Page 25 N1 - SIDE WINDOW SHELF - W4L04751 5/8"x2 3/8"x18 7/8" (16x60x479) STEP 15: FLUSH SCREW PFH 8x1 1/4 REAR FRONT RIGHT SCREW PFH 8x1 1/4 (2 PLCS)
- Page 26 Q1 - COUNTER TOP SUPPORT - W4L04752 1"x4 3/8"x5 7/8" (24x112x150) STEP 16: 5/8" SCREW PFH RIGHT SCREW PFH 8x2 (1 PLC) REAR...
- Page 27 J1 - COUNTER TOP SUPPORT - W4L04753 1"x2 3/8"x5 7/8" (24x60x150) STEP 17: SCREW PFH 8x1 1/4 13 3/4" FRONT SCREW PFH 8x1 1/4 (2 PLCS) 'J1' SUPPORT ATTACHES NEXT TO PLASTIC REAR CORNER MATERIAL. LEFT...
- Page 28 M1 - COUNTER TOP - W4L04754 5/8"x3 3/8"x23 5/8" (16x86x600) STEP 18: SCREW PFH FLUSH 8x1 1/4 SCREW PFH 8x1 1/4 (4 PLCS) LEFT FRONT...
- Page 29 "A" REVISION TAG - A100314 STEP 19: SCREW PWH 8x5/8 REAR LEFT SCREW PWH 8x5/8 (2 PLCS) FRONT RIGHT "A" REVISION TAG...
- Page 30 FAUCET KIT - A6P00024 STEP 20: SCREW PFH 8x1 1/2 REAR FRONT RIGHT SCREW PFH 8x1 1/2 (2 PLCS) 1" FAUCET KIT...
- Page 31 SURFACE MOUNT BASIN - A6P00032 STEP 21: SCREW PWH 8x5/8 REAR LEFT SCREW PWH 8x5/8 (2 PLCS) RIGHT FRONT 3/8" SURFACE MOUNT BASIN...
- Page 32 STOVE KIT - A6P00025 STEP 22: SCREW PFH 8x1 1/8 LEFT REAR SCREW PFH 8x1 1/8 (4 PLCS) FRONT RIGHT STOVE KIT 1 1/8"...
- Page 33 N3 - DOOR STOP - W4L04761 5/8"x2 3/8"x3 7/8" (16x60x100) STEP 23: SCREW PFH 8x1 1/4 2 5/16" SCREW PFH 8x1 1/4 (3 PLCS)
- Page 34 (1) KNOB KIT - A6P00020 STEP 24: RIGHT FRONT KNOB KIT REAR LEFT FACE PLATE SCREW PFH 8x3/4 (2 PLCS) LATCH SCREW PFH 8x1 (1 PLC)
- Page 35 PHONE KIT - A100132 STEP 25: SCREW PFH 8x1/2 REAR 24 5/8" LEFT RIGHT FRONT PHONE KIT SCREW PFH 8x1/2 (2 PLCS)
- Page 36 FLOWER POT HOLDER - A6P00023 STEP 26: SCREW PFH RIGHT FRONT FLOWER POT HOLDER (2 PLCS) REAR LEFT SCREW PFH 8x1 (8 PLCS)
- Page 37 BYD ID TAG (MEDIUM) AGES 2 TO 10 - A4M00528 STEP 27: SCREW PWH 8x7/16 REAR LEFT RIGHT FRONT SCREW PWH 8x7/16 (2 PLCS)
