Plikc NEVE PRO User And Installation Manual page 3

Description
NEVE PRO is a digital on/off thermostat powered by batteries, controlling a clean contact in normally
open or closed exchange. It allows for managing and programming the operation of boilers, zone
valves, heat pumps, air conditioners, or other compatible systems to ensure the most comfortable
temperature inside a room and optimize energy consumption. The NEVE series is perfect for wall
mounting or covering a 503 box.
Through the "PrOG OFF" mode, the NEVE PRO can also be used as a simple on/off ambient ther-
mostat, without the need to set a program. While easy to connect, it is always recommended to have
the device installed by a qualified technician.
IMPORTANT: Carefully read the user manual before installation. Follow all the instructions and pre-
cautions outlined regarding the installation and use of the product.
Battery Usage Precautions
• Use only high-quality batteries of the size and voltage indicated, specifically 2 alkaline AA bat-
teries (1.5V). We recommend avoiding rechargeable batteries for this product.
• Make sure to insert the batteries with the correct polarity, as indicated in the designated com-
partment.
• Connecting the battery with incorrect polarity can damage the thermostat.
• Do not install two different types of batteries together, such as an alkaline and a zinc-carbon
battery, or a new battery with an old one.
4
Plikc S.r.l. - Via del Lago Terrione, 83 - 00165 Roma - info@plikc.com - www.plikc.com
Technical Specifications
• Three modes for weekly program settings:
• 5+2 - Two groups of days with a single program (MON-FRI and SAT-SUN).
• 7 days - A single group of days with a unique program (MON-SUN).
• 24 Hours - Ability to program each day of the week separately.
• Selectable thermostat/programming modes.
• Temperature measurement range: 0°C ~ 40°C.
• Set temperature range: 5°C ~ 35°C with 0.1°C increments.
• Temperature measurement accuracy: ± 1°C (at 20°C).
• Power supply: 2x AA alkaline batteries (1.5V).
• Switchable current: 6A (inductive load 2A), 230Vac.
• Nominal load: 6 (2)A, 230Vac.
• Low battery indicator: Flashing.
• Standby current: 40uA, illumination current ≤ 10 mA.
• Backlight color: Light blue.
• Buttons: Soft touch.
• Dimensions: 12.5 × 8 × 2.5 cm.
Plikc S.r.l. - Via del Lago Terrione, 83 - 00165 Roma - info@plikc.com - www.plikc.com 5
