About Copeland

Copeland, a global provider of sustainable climate solutions, combines category–leading brands in compression,

controls, software and monitoring for heating, cooling and refrigeration. With best–in–class engineering and design

and the broadest portfolio of modulated solutions, we're not just setting the standard for compressor leadership;

we're pioneering its evolution. Combining our technology with our smart energy management solutions, we can

regulate, track and optimize conditions to help protect temperature–sensitive goods over land and sea, while

delivering comfort in any space. Through energy–effcient products, regulation–ready solutions and expertise,

we're revolutionizing the next generation of climate technology for the better.

To learn more, visit copeland.com

谷轮涡旋压缩机

智能控制模块

Copeland Compressor Electronics Module

中文 / English

User Manual

MARCH 2025

Need help?

Do you have a question about the Plus 5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Copeland Plus 5

Page 1 Copeland Compressor Electronics Module About Copeland Copeland, a global provider of sustainable climate solutions, combines category–leading brands in compression, controls, software and monitoring for heating, cooling and refrigeration. With best–in–class engineering and design and the broadest portfolio of modulated solutions, we’re not just setting the standard for compressor leadership;...
Page 2 报警代码定义和手机应用程序App连接后，您可以读取压缩机运行信息或者下载历史运行数据。通过手机应用程序，方便您实时查看压缩机运行状态以此判断该制冷系统或压缩机的健康情况，这也有助于缩短系统调试时间并帮助售后人员快速准确的排查故障。喷液和喷气增焓控制附件包当压缩机在运行时，模块每隔20秒存储一次运行数据，模块里的芯片大概能储存72小时(有效运行时间) 历史运行数据。压缩机停机时将不记录任何数据，旧的数据会被新的数据覆盖。建议下载历史数据时选油位管理择必要的时间段，下载全部的数据将花费您比较长的时间。模块安装第一步：在App商店搜索“Copeland Electronics Module”安装在您的手机上。苹果iOS系统手机可以直接在苹果应用商店下载安装。安卓系统手机目前支持在“腾讯应用宝”应用商店下载安装。现场改造接线图 Copeland Electronics Module 无线通讯声明第二步：打开手机蓝牙，寻找蓝牙并配对 “Copeland xxxxxxxx” (注：后 8位数字为模块标签上的序列号) 示例...
Page 3 IP20 IP20 模块接口定义: 接口描述 571-0106-00 571-0107-00 Plus 5 Plus 4 模块供电接口, 115-240 VAC, 50-60Hz • • T1/T2 571-0106-00, Plus 5 571-0107-00, Plus 4 连接马达三相火线 (出厂已接线) • L1/L2 /L3 接系统控制回路，与压缩机接触器线圈串联新一代冷冻涡旋ZF35-58KNE,ZFI51-82KNE, 喷液系列ZSI06-21KQ/E,ZFI09-30KNE和喷气 • M1/M2 接压缩机接触器线圈，开关信号和冷冻大涡旋ZB150-300KQE,ZFI96-180KQE 增焓系列ZFI09-30KNE,ZFI20-81KQE压缩机 •...
Page 4 LED 矩阵显示运行状态和查看历史报警 • • 读取压缩机运行信息 • • 下载历史数据 • • 对外通讯报警输出至蜂鸣器 • • 油位传感器蓝牙连接手机 • • PC 通讯和RS485 通讯 (开发中) • • EXV电子膨胀阀回油电磁阀蓝牙 (手机 App) T1/T2 模块供电 220V 报警输出接口 L1/L2/L3 马达三相火线 (Plus 5) A/B接系统开关信号 (Plus 4)
Page 5 谷轮涡旋压缩机智能控制模块拨码开关设定谷轮涡旋压缩机智能控制模块拨码开关设定 Plus 5 模块: 571-0106-00 Bit1拨码开关用于选择排气温度目标值； Bit2拨码开关控制启用或关闭油位管理功能； Bit3和Bit4拨码开关组合用于选择喷射模式和板换进出口过热度目标。拨码开关设定压缩机应用型号 Plus 5 模块: 571-0106-00 Bit 1 Bit 2 Bit 3 Bit 4 DPT 110°C + 喷液位置 Bit 1 Bit 2 Bit 3 Bit 4 涡旋排气口温度...
Page 6 谷轮涡旋压缩机智能控制模块报警代码定义谷轮涡旋压缩机智能控制模块报警代码定义故障故障类型故障代码描述 Plus 5 Plus 4 故障触发条件故障排除参考类型故障代码描述 Plus 5 Plus 4 故障触发条件故障排除参考代码屏幕代码屏幕长亮正常运行 • • Ω < 40Ω；马达温度传感器 1/ 检查传感器引线和模块连接是否正常停机保护30分钟后 • 闪烁短路...
Page 7 谷轮涡旋压缩机智能控制模块喷液和喷气增焓控制附件包谷轮涡旋压缩机智能控制模块喷液和喷气增焓控制附件包谷轮提供客户喷液和喷气增焓控制附件包， 1.8米线长和4.5米线长可选。 4.5米线长附件包应用于压缩机型号 ZFI09-30KNE 喷液控制附件包 ZFI36-39KQE ZFI50-59KQE ZFI68-81KQE ZFI96-140KQE ZFI20-26KQE 附件包组件组件料号组件料号应用于 562-0471-02 562-0471-04 562-0471-06 562-0471-08 562-0460-01 EXV电子膨胀阀控制模块压缩机型号阀体口径(识别号) 随压缩机 1.8米线长 4.5米线长 571-0107-00 571-0107-00 571-0107-00 571-0107-00 模托架 ZSI06-21KQE 074-1855-00 074-1855-00 562-0471-00 Ø1.3mm (TS113C03) 螺丝组件...
Page 8 谷轮涡旋压缩机智能控制模块油位管理谷轮涡旋压缩机智能控制模块油位管理谷轮新一代智能控制模块集成了先进的油位保护和回油管理功能，通过安装在压缩机底部油视镜接口回油电磁阀上的OW4油位传感器，实时监测压缩机中的油位，避免压缩机因缺油而导致的失效；在并联系统或配因谷轮不同平台压缩机设计的差异，以及不同客户制冷系统设计、现场安装和实际应用工况的差异，压置了油分的单机系统中，当电子模块检测到低油位时，回油电磁阀可快速响应，及时向压缩机补充所需缩机的补油频次会不同。目前市面上常规电磁阀大都不能满足油路中的使用要求，因此，谷轮为油路系的润滑油，这在很大程度上保障了整个制冷系统稳定可靠地运行，避免了客户端不必要的成本损失。统开发了一定制款电磁阀。 OW4油位传感器使用霍尔传感器来监测油位，磁性浮子会根据油位的变化改变其位置，霍尔传感器将该阀采用螺纹接口，方便客户维修更换，避免了在油路中焊接管路而引起潜在的安全性问题；该阀通过了磁场变化转换为等效信号，内置的控制板使用该信号生成与油位相关的PWM （脉宽调制）信号。谷轮严苛的可靠性验证，具有IP65高的防护等级和1百万次的使用寿命，大大增强了其在应用中的可靠性。在油路系统中，...
Page 9 谷轮涡旋压缩机智能控制模块模块安装谷轮涡旋压缩机智能控制模块现场改造新一代谷轮涡旋压缩机智能控制模块可应用于以下型号的压缩机现场维修更换，包括ZSI喷液控制模块， ZFI喷气增焓控制模块， ZFI低温大涡旋压缩机P47 智能模块和喷气增焓控制模块。 ZFI09-30KNE, ZFI20-39KQE, ZSI06-21KQE 对ZFI09-39和ZSI06-21系列涡旋压缩机,该模块安装一个单独的模块型号现场改造要点托架内，并固定在冷凝机组电控箱中；移除旧模块组件包括控制板，变压器，接线盒和排气温度传感器模块托架 • 用新模块，模块托架和排气温度传感器安装替换；该模块是通过压缩机接线盒或者模块托架盒内的2个爪型卡口安装 ZSI06-21KQE • EXV电子膨胀阀通用固定，拆卸模块只需掰离爪型卡扣即可。根据新的接线图接线，接线逻辑同之前 • 移除旧模块组件包括控制板，变压器，接线盒，排气温度传感器, • 喷气进口和喷气出口传感器用新模块，...
Page 10 谷轮涡旋压缩机智能控制模块接线图谷轮涡旋压缩机智能控制模块接线图单相压缩机 , 配plus 4模块三相压缩机 , 配plus 4模块 ZSI06-14KQE, ZFI09-16KNE ZSI06-21KQE, ZFI09-30KNE, ZFI20-81KQE...
Page 11 谷轮涡旋压缩机智能控制模块接线图谷轮涡旋压缩机智能控制模块接线图三相压缩机 , 配plus 5模块控制模块 ZF35-58KNE, ZFI51-82KNE, ZFI96-180KQE, ZB150-300KQE 76.5 45.5 模块托架 103.4 89.3 32.0 Ø5.50 2X1.00 单位: mm...
Page 12 Step 2: Enable Bluetooth connection on your device and search for the Copeland electronics module. Select and initiate pairing with “Copeland xxxxxxxx”. (Note: The last 8 digits refers to the serial number on each module seen on the module sticker)
Page 13 The module ZFI20-ZFI81KQE use this module (Plus 4 • Connect to motor and scroll discharge port temperature sensors (Plus 5 type) is installed in the compressor type) via its accessory kit package. • Connect to discharge line temperature sensor electrical box.
Page 14 (combined) Motor temperature overheat protection Recall Button • Locked rotor protection • DPT Sensor, Motor missing phase protection Motor Temp (Plus 5) 4 Bits Dip Switch • Reverse phase protection DLT Sensor (Plus 4) Advanced protection Communication TTL Port •...
Page 15 Copeland Compressor Electronics Module Copeland Compressor Electronics Module Bit 1 dip-switch is used for selecting compressor discharge temperature control Plus 5 Module: 571-0106-00 target. Bit2 is enable or disable for oil level control. The combination of Bit 3 and Dip-switch setting Bit 4 is for injection control mode and vapor injection superheat target.
Page 16 Copeland Compressor Electronics Module Copeland Compressor Electronics Module Code fault Code fault Alarm Alarm Plus 5 Plus 4 Plus 5 Plus 4 Matrix Type Fault condition Trouble shooting reference Matrix Type Fault condition Trouble shooting reference...
Page 17 Copeland Compressor Electronics Module Copeland Compressor Electronics Module Copeland provides customers with full liquid injection and vapor injection control kits with 1.8m or Part number with 4.5m wire length 4.5m wire lengths. ZFI09-30KNE...
Page 18 The valve is designed with thread connection for ease maintenance and replacement, avoiding potential safety issue caused by welding in the oil circuit. The valve has passed Copeland reliability test OW4 oil level sensor uses a Hall-Sensor to measure the oil level. A magnetic foat changes its position with IP65 protection and 1 million cycles, which greatly enhanced the reliability in oil circulation system.
Page 19 Copeland Compressor Electronics Module Copeland Compressor Electronics Module The new generation Copeland compressor electronics modules are only intended to be used as feld retrofts for ZSI liquid injection control modules, ZFI vapor injection control modules, large ZFI scroll P47 ZFI09-30KNE, ZFI20-39KQE, ZSI06-21KQE CoreSense modules and vapor injection control modules.
Page 20 Wiring diagrams Wiring diagrams Copeland Compressor Electronics Module Copeland Compressor Electronics Module Single-phase compressor, plus 4 module Three-phase compressor, plus 4 module ZSI06-14KQE, ZFI09-16KNE ZSI06-21KQE, ZFI09-30KNE, ZFI20-81KQE...
Page 21 Wiring diagrams Wiring diagrams Copeland Compressor Electronics Module Copeland Compressor Electronics Module Three-phase compressor, plus 5 module Control Module ZF35-58KNE, ZFI51-82KNE, ZFI96-180KQE, ZB150-300KQE 76.5 45.5 Module Bracket 103.4 89.3 32.0 Ø5.50 2X1.00 Unit: mm...
Page 22 Statements about wireless / Contains Transmitter Module Changes or modifcations not expressly approved by Copeland could void the user's authority to operate the equipment. FCC ID: A8TBM70ABCDEFGH This device complies with Part 15 of the FCC Rules and Science and Economic Development Canada’s license-exempt RSS(s).

This manual is also suitable for:

Plus 4 571-0106-00 571-0107-00
