Microtest 7605 User Manual

Hipot tester
Hide thumbs Also See for 7605:

Advertisement

Quick Links

Download this manual
User Manual
Hipot Tester
7630/7605
S/W Ver
Firmware Ver
Date
1.4
Dec-2022

Advertisement

loading
Need help?

Need help?

Do you have a question about the 7605 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Microtest 7605

Summary of Contents for Microtest 7605

  • Page 1 User Manual Hipot Tester 7630/7605 S/W Ver Firmware Ver Date Dec-2022...
  • Page 2 Content Chapter 1 Safety Specification ..............5 1.1 Electrification and Electric Shock ..........5 1.2 Grounding ................. 5 1.3 Power ..................5 1.4 Connect the testing cable to the high voltage output terminal .. 5 1.5 Warm up ..................5 1.6 External control host ..............
  • Page 3 7.1 Instruction summary ............... 34 7.2 Command description ............. 36 Appendix 1 ....................44...
  • Page 4 All brands and trademark are the properties of Microtest Co., Ltd. Microtest Co., Ltd. and its affiliates shall not be liable for the damage, losses or costs incurred due to the accidental use, misuse or abuse by the product buyer or the third party;...
  • Page 5 Chapter 1 Safety Specification This tester outputs voltage as high as 5kVac/6kVdc for external testing; accidents will happen if this tester is used incorrectly or improperly. Therefore, in consideration of your own safety, please read the precautions described in this chapter carefully and memorize them in order to prevent accidents from occurring.
  • Page 6 1.6 External control host This tester can perform external control; make sure the operator is not touching the high voltage output terminal and DUT when performing such controls in order to avoid causing danger. 1.7 Machine malfunction If it is discovered that this tester has malfunctioned, for example: the voltage displayed on the voltmeter differs greatly from the voltage set, or there is no high voltage output but the high voltage output warning indicator remains on etc., cease usage immediately and contact our...
  • Page 7 Chapter 2 General description 2.1 Package and Accessories Standard accessories included with the HT-7630 high voltage tester package should include the following items: 1. HT-7630 high voltage tester *1 2. High voltage testing cable (red) *1 Low voltage terminal testing cable (black)*1 4.
  • Page 8 2.2 Front Panel 2.2.1 7630 Front Panel (1) Test key (with PASS light indicator): Press to start testing the system in READY mode, it lights up after being tested successfully. (2) Stop key (with FAIL light indicator): Press to stop the test and close the high voltage output in test mode.
  • Page 9 2.2.2 7605 Front panel (1) Test key (with PASS light indicator): Press to start testing the system in READY mode, it lights up after being tested successfully. (2) Stop key (with FAIL light indicator): Press to stop the test and close the high voltage output in test mode.
  • Page 10 (9) Power switch: Power on or off the host. High voltage output warning indicator: When there is voltage output (10) at the high voltage output terminal, this warning indicator will light up. Do not touch the high voltage output terminal when the high voltage warning indicator is on in order to avoid the danger of electric shocks.
  • Page 11 Opening the circuit of this port during testing will stop the test and prompt the message “INTER LOCK” (10) Exhaust outlet: Air exhaust for cooling (11) Serial number sticker: Indicates the serial number of your machine (12) High voltage test rod port: Connects to the high voltage test rod...
  • Page 12 Chapter 3 Basic operation description 3.1 Function block diagram Ready Config Setup File Baud Save As.. MODE Rate Lock Load File VOLT Auto Pass Reply Hold Time Del. File FREQ Trig New File Sound Wait Time Save File Pass Alarm To USB Word Mode...
  • Page 13 3.2 Standby screen description (1) Display the current test mode: Message “ACW” for AC voltage testing, “DCW” for DC voltage testing, “IR” for insulation impedance testing (2) Readings of the voltage, current (resistance in IR mode), and test time of the measurement output port now. It displays the current voltage and test time settings if no test is running now.
  • Page 14 (4) Display the first five test steps of the current file (5) The orange color framed step is the one under testing (DUT) now along with its specifications displayed. You may select the desired step by moving the cursor to it with arrow key. Press the ENTER key to set up the test items.
  • Page 15 LIMIT (below the lower limit of the set value), INTER-LOCK (high voltage safety lock start), ABORT (test suspension)), BREAKDOWN (Crash Point Detection), ARCING (Discharge Detection), VOLT ERR (Voltage Output Abnormal), OPEN (Destination Error), etc. If a multi- step test is performed, the final test will be added after the end of the test.
  • Page 16 (9) EXT-I/O: External expansion I/O board, if the field shows NULL, it means that no expansion I/O board is currently connected, if it shows EXIST, there is an expansion I/O board connected. (10) BOX UNIT: The number of scanner box, if the field shows NULL, it means that no scanner box is currently connected, if it shows 1~ 4, there is 1~ 4 scanner boxes connected.
  • Page 17 (4) Alarm Mode: The alert mode has the options of ALL (alert all), PASS (alert for qualified goods), FAIL (alert for failed goods), and OFF. (5) Instant: You have to press and hold the TEST key to run the test in this mode.
  • Page 18 3.5 Specification setup description (1) Figure 3-5-1 Setup 1 (1) STEP: Step ID. Each file can have up to 16 steps. Press the software key COPY to add the next step; press the software key DEL to delete the step where the cursor is positioned. Each file must have at least one step.
  • Page 19 (6) LO.: This is the lower limit of measurement. In case test readings exceed this limit, the test has failed and is ended immediately. For settings at a value 0, no lower limit will be judged. (7) Ramp: This is the time span for the voltage to rise from 0 to the target value ranging from 10S to 0.1S.
  • Page 20 operation is done; press the ENTER key to save the test value or the EXIT key to exit without saving it; the saved value will be deducted from each measurement to enable a more accurate test.
  • Page 21 3.6 Specification setup description (2) Figure 3-6-1 Setup 2 (1) OPEN: Open circuit detection sensitivity. Poor connection of the high voltage test wire to the DUT may lead to a lower measurement current and invalid qualified product results in the voltage test. Once this function is enabled (with non-zero settings) your machine will measure the DUT's capacitance with low voltage for about 200ms before the high voltage test begins.
  • Page 22 judged only after the capacitor is fully charged. The delay time starts counting only after voltage has reached the settings. Before that, your machine displays measurement without the upper and lower limit determination and enters judgment mode immediately after the delay time has expired.
  • Page 23 Figure 3-6-2 DCW/IR-TEST Figure 3-6-3 ACW-TEST 3.7 File management (FILE) Figure 3-7-1 File (1) Save As..: This option saves the setup file with a new file name (there can be up to 30 files saved in your machine). The “file save” page displays the existing files in your machine.
  • Page 24 Figure 3-7-2 Save File Name (2) Load File: This item reads the existing file. The “file access” page displays the existing files in your machine. In case a USB drive is connected, a USB icon shows in the upper right corner of the page. You may press the software key to select retrieving a file in the USB drive or internal memory.
  • Page 25 key COPY to start copying the selected files. You may press the software key ALL to select all files shown in the current page for copying. Please note that the ALL option is valid for files on the current page only. For files on the next page, do the same to copy them as shown in the diagram below.
  • Page 26 Chapter 4 Start testing 4.1 Before testing (1) Validate specification setup. (2) Validate the proper connection between your machine and DUT. (3) Validate that the message READY is prompted. (Figure 4-1-1) (4) Press the TEST key to start testing. (Figure 4-1-2) Figure 4-1-1 Ready Figure 4-1-2 Test button 4.2 Testing in progress...
  • Page 27 (4) Test time counting. For tests lasting longer than 100 seconds, their integral portion is displayed while the decimal portion is hidden; if it is longer than 999 seconds then it stops counting the time while the number 999 remains flashing on screen. Figure 4-2-1 Test Figure 4-2-2 H.V LED 4.3 Ending a Test...
  • Page 28 (2) Current/resistance measurements over the upper limit (HI-LIMIT). (3) Current/resistance measurements below the lower limit (LO-LIMIT). (4) Leak current over the maximum measurement (Break Down). (5) Arc is over the settings (Arcing). (6) Output safety switch is enabled (Inter Lock). (7) The terminal to be tested is open (OPEN).
  • Page 29 Figure 4-4-1 Fail Chapter 5 Remote control I/O description (Remote) The back panel of your machine comes with a remote control connector (REMOTE). Please connect the control wire to it to enable controlling your machine with an external signal. In cases like this, the test operator will not touch the high voltage output end to prevent personal injury.
  • Page 30 Name Function CTL1 Reserved CTL2 Reserved CTL3 Reserved CTL4 Reserved TESTING Test in progress PASS Determination PASS FAIL Determination FAIL HV-ON High voltage output in progress Earthing point of your machine TRIG Test trigger ABORT Test abortion RESET Reset your machine DC +5V output +12V DC +12Voutput...
  • Page 31 (6) H.V. ON: Conduct with Pin15 (COM) when your machine is outputting high voltage. Frequent uses: (Input signal) Control your machine for testing by using a normal open switch relay. (Output signal) Control the relay with the output signal. Please connect the relay coil to a regulator diode for safer application Chapter 6 RS-232/USB drive use description...
  • Page 32 6.2 Command format The RS-232 interface function of your machine is exercised by a command string in ASCII code for remote control and setup. Each command string is composed of the command code and its parameters, two commands are connected with a semicolon “;”, and appended with an end code.
  • Page 33 6.4 Connection cable and method 6.5 USB device interface specification Interface I/O USB Specification 2.0 Self-powered Transfer rate: MAX 12Mbps(Full Speed) Command string end code For receiving: LF or EOM For transmission: LF+EOM Vendor ID 0x1FC9 Product ID 0x811D...
  • Page 34 Chapter 7 Remote command 7.1 Instruction summary Common instruction *CLS *IDN? *OPC *OPC? *OPT? *RCL *SAV SCPI command :CONFigure :KLOCk <ON , OFF, 1, 0> :ALARm <ALL,PASS, FAIL,OFF> :PHOLd <50ms,100ms,500ms,1s,2s,5s,INFinity> :TGWAit <NRf> :TMODe <SINGLE,MULTI> :TMODe :MULTi :TSOUrce <AUTO,TRIG> :TMODe :MULTi :BREAk <FAIL,OFF>...
  • Page 35 :OFFSet IMAG <NRf> :OFFSet REAL <NRf> :OPEN <NRf> :DELAy <NRf> : STEP : COUNt? : STEP : DELete <numeric> : STEP : ADD <numeric> : STEP : CONDition <numeric> :MEASure :VOLTage? :CURREnt? :RESistance? :TIME? :OPERation :STEP <numeric> :FILE? :RESU? :STAR :STOP :SYSTem :AUREply...
  • Page 36 7.2 Command description Shared command Command Function *CLS Erase data in every register *IDN? Read the basic device data including the manufacturer, model, serial number, firmware release and output in comma delimited format *OPC Operation completion command *OPC? Query operation completion command: Return value 1 if operation completed;...
  • Page 37 :CONFigure: PHOLd <50ms,100ms,500ms,1s,2s,5s,INFinity> This command sets up the retaining time for PASS display Example: CONF: PHOL 100ms Example description: Set up PASS display time to 100mS Example: CONF: PHOLd? Return value: +1.00000E-01 <100ms> :CONFigure:TGWAit <NRF> This command sets up the test wait time after a trigger Example: CONF: TGWA 500mS Example description: Set up wait time after trigger to 500mS Example: CONF: TGWA?
  • Page 38 Example: CONF: TMOD: MULT: SIGN? Return value: TOTAL <output overall determination signal> :EDIT:STEP <numeric> This command sets up the step for editing. The following “EDIT” string headed command setting up step is specified by the command, e.g. after setting step 1 to be edited, all the following voltages or current values will be set to step 1.
  • Page 39 Example: EDIT: LOLI 0.5mA Example description: Set the lower determination limit to 0.5mA Example: EDIT: LOLI? Return value: +5.00000E-04 <0.5mA> :EDIT: RAMP < NRf > This command sets up the voltage rising time Example: EDIT: RAMP 0.5s Example description: Set the voltage rising time to 0.5s Example: EDIT: RAMP? Return value: +5.00000E-01 <0.5s>...
  • Page 40 Example: EDIT: ARC? Return value: 5 :EDIT: OFFSet IMAG < NRf > This command sets up the reset deduction value of imaginary current. Example: EDIT: OFFS IMAG 0.002mA Example description: Set up the reset deduction value of imaginary current to 0.002mA Example: EDIT: OFFS IMAG? Return value: +2.00000E-06 <0.002mA>...
  • Page 41 This command adds a test step. Example: EDIT: STEP: ADD 2 Example description: Add test step STEP2 :EDIT: STEP:CONDition? < numeric > This command queries the test step conditions Example: EDIT: STEP: COND? 2 Example description: Query test conditions of step 2. Return value: ACW,1.00kV,50HZ,26.00mA, 0.00mA, 0.1s, 1.0s,0, 0.00mA,OFF.
  • Page 42 : RESUlt? This command queries the test results. Example: RESU? Return value: 01,+9.01235E+00,+7.52562E-07,+1.19756E+07,2 with contents in the following sequence: test step ID, voltage measurement, current measurement, resistance measurement, determination results where determination results are predefined codes with the meanings defined in the table below: Code Description Test Aborted...
  • Page 43 : SYSTem: ALARm [:VOLUme]: PASS < numeric> This command sets up the volume of PASS alert Example: SYST: ALAR: PASS 1 Example description: Set the volume of PASS alert to1 Example: SYST: ALAR: PASS? Return value: 1 : SYSTem: ALARm [:VOLUme]: FAIL< numeric> This command sets up the volume of FAIL alert Example: SYST: ALAR: FAIL 5 Example description: Set the volume of FAIL alert to5...
  • Page 44 Appendix 1 -100 Command error -102 Syntax error -103 Invalid separator -108 Parameter not allowed -109 Missing parameter -112 Program mnemonic too long -113 Undefinded header(query a command only command or query command missing '?' -141 Invalid character data -211 Trigger ignored -221 Settings conflict...
  • Page 45 Remark 2022/12/16 Update Arc Sen. level...

This manual is also suitable for:

7630
